- Page 1 DISHWASHER COS-DWD24FBR 24 IN. BUILT-IN DISHWASHER USER MANUAL IMPORTANT: READ AND SAVE THESE INSTRUCTIONS. FOR RESIDENTIAL USE ONLY. INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THIS UNIT FOR THE OWNER. OWNER: PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. Rev.23.10...
- Page 2 COSMO Appliances are designed according to the strictest safety and performance standard for the North American market. We follow the most advanced manufacturing philosophy.
-
Page 3: Table Of Contents
TABLE OF CONTENTS DISHWASHER SAFETY ................4 OPERATING REQUIREMENTS ...............8 Location Requirements ................8 Water Supply Requirements ..............8 PARTS AND FEATURES .................9 Filter System .....................10 Smart Wash System ................10 Adjustable Upper Rack ................11 START UP GUIDE ..................12 How your Dishwasher Cleans ............... 12 Before Using Your Dishwasher ............. -
Page 4: Dishwasher Safety
DISHWASHER SAFETY READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. - Page 5 WARNING/GROUNDING INSTRUCTIONS Improper connection of the equipment-grounding conductor can result In a risk of electric shock. Check with a qualified electrician or service representative if you are in doubt whether the appliance is properly grounded. Do not modify the plug if provided with the appliance.
- Page 6 WARNING • Items that are not dishwasher safe may melt and create a potential fire hazard. • Do not touch the heating element during or immediately after use. • Do not operate your dishwasher unless all enclosure panels are properly in place. •...
- Page 7 WARNING TIP OVER HAZARD • Do not use dishwasher until completely installed. • Do not push down on open door. • Doing so can result in serious injury or cuts. California Proposition 65 Warning WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. SUFFOCATION HAZARD •...
-
Page 8: Operating Requirements
OPERATING REQUIREMENTS ELECTRICAL REQUIREMENTS WARNING: Electrical Shock Hazard • Electrically ground dishwasher. • Connect ground wire to green ground connector in terminal box. • Do not use an extension cord. • Failure to follow these instructions can result in death, fire, or electrical shock. -
Page 9: Parts And Features
PARTS AND FEATURES A. Cup Shelf F. Upper Rack B. Middle Spray Arm G. Tub Gasket C. Lower Spray Arm H. Silverware Basket D. Rinse Aid Dispenser I. Lower Rack E. Detergent Dispenser J. Heating Element... -
Page 10: Filter System
SPECIFICATIONS Capacity 12 Place Settings 23 ⁄ " x 22 ¹¹⁄ " x 33 ¹¹⁄ " (600 x 576 x 855 mm) Dimensions (WxDxH) 71.4 lb (32.4 kg) Weight Unpacked Power Supply 120 volts, 60 Hz Rated Power Usage Wash motor 50 W Heater 840 W 20-80 psi (138 - 552 kPA) Water Feed Pressure FILTER SYSTEM... -
Page 11: Adjustable Upper Rack
ADJUSTABLE UPPER RACK The Adjustable Upper Rack feature allows you to load taller items in either the upper or lower rack. The upper rack of your dishwasher can be adjusted 2" (5.08 cm). Adjusting the clearance of the Upper Rack increases or decreases the clearance of the lower rack, as shown. -
Page 12: Start Up Guide
START UP GUIDE IMPORTANT: • Properly dispose of/recycle all packing material. • Read this entire User Manual. You will find important safety information and useful operating tips. HOW YOUR DISHWASHER CLEANS Your dishwasher cleans by spraying a mixture of hot water and detergent through the spray arms against soiled surfaces. -
Page 13: Controls
CONTROLS POWER CTL LOCK SANITIZE Hold 3 Sec to Cancel NOTE: When the door is closed. A. Power Press this button turn on or turn off the dishwasher. B. Cycles Press this button to select corresponding washing program code: Heavy, Normal, ECO, Express HEAVY Heavy cycle is for pots, pans, casseroles and dinnerware with dried-on or baked on soil. - Page 14 C. ADDITIONAL FEATURES CTL LOCK Use to lock all controls and prevent children from accidentally changing the dishwasher cycle or starting the dishwasher. Press and hold CTL LOCK for 3 seconds to either activate or cancel the Child Lock option. After the function is selected the lock icon will illuminate. If the the function is canceled, the lock icon will turn off.
- Page 15 HI TEMP Use to maintain the water temperature at 140°F (60°C) max during the wash portion of the cycle. INDICATOR LIGHTS Sanitized The Sanitized indicator light illuminates when the cycle using the Sanitize option is finished. The light turns off turns off when the door is opened and then closed or any button is pressed.
-
Page 16: Cycle And Option Charts
CYCLE AND OPTION CHARTS Depending on the Cycle selected, the Options available for selection will illuminate. Cycle times are approximate and will vary depending on the wash cycle and options selected. NOTE: Added Options can add more time and use more water. Hot Water is necessary to activate the dishwasher detergent and melt fatty food residue. -
Page 17: Dishwasher Loading
DISHWASHER LOADING PREPARE DISHES • Empty liquids from glasses and cups. • Remove leftover food, bones, toothpicks and other hard items from the dishes and discard. • It is not necessary to hand-rinse dishes before loading them into the dishwasher with the following exceptions: •... -
Page 18: Upper Rack
UPPER RACK The upper dishwasher rack is designed for cups, glasses, small plates, bowls and plastic items marked dishwasher safe. The upper rack can be easily adjusted 2" (5 cm) up or down to accommodate taller items in either in the top or bottom rack. ADJUST UPPER RACK IMPORTANT: •... -
Page 19: Load Upper Rack
LOAD UPPER RACK NOTE: The features on your dishwasher rack may vary from the drawings shown. 8 Place Setting 10 Place Setting 12 Place Setting 8 Place Setting(DOE) IMPORTANT: Make sure the items loaded in the upper rack do not interfere with the rotation of the middle spray arm located beneath the upper rack. -
Page 20: Lower Rack
LOWER RACK The lower rack is designed for plates, soup bowls, cookware and bakeware. The adjustable upper rack allows you to load items up to 12.6” in height in the lower rack. IMPORTANT: Items in the lower rack must be placed so that they do not interfere with the rotation of the spray arms, block the water inlet, or keep the water spray from reaching the detergent dispenser. - Page 21 LOAD LOWER RACK NOTE: The features on your dishwasher rack may vary from the drawings shown. • Do not load glasses, cups, or plastic items in the lower rack. • Load small items in the lower rack only if they are secured in place. •...
-
Page 22: Loading Silverware
LOADING SILVERWARE NOTES: • Do not load silver or silver-plated silverware with stainless steel. These metals can be damaged by contact with each other during washing. • Some foods (such as salt, vinegar, milk products, fruit juices, etc.), can pit or corrode silverware. - Page 23 For Best Results: • Load items with handles down, using the separators to prevent silverware from nesting. • Place small items such as baby bottle caps, jar lids, corncob holders, etc. in the section(s) with hinged cover(s). Close the cover to hold small items in place.
-
Page 24: Recommended Load Patterns
1. Spoons 2. Knives 3. Salad Forks 4. Forks 5. Large Spoons 6. Large Forks 8 Place Setting 10 Place Setting 12 Place Setting 8 Place Setting (DOE) -
Page 25: Dishwasher Use
DISHWASHER USE PROPER USE OF DETERGENT IMPORTANT: • Use automatic dish washing detergent only. Other detergents can produce excessive suds that can overflow out of the dishwasher and reduce washing performance. • Add detergent just before starting a cycle. • Store detergent tightly closed in a cool, dry place. Fresh automatic dishwasher detergent results in better cleaning. -
Page 26: Proper Use Of Rinse Aid
3. Press down on the top of the cover to secure. HOW MUCH DETERGENT TO USE The amount of detergent to use depends on the soil level of your load, the type of detergent used and the hardness of your water. •... - Page 27 To refill the rinse aid dispenser 1. Lift up the end tab of rinse aid 2. Fill the rinse aid dispenser cover to open. with liquid rinse aid until full. DO NOT overfill. NOTE: Use the viewing port when filling the rinse aid reservoir.
-
Page 28: Washing Special Items
WASHING SPECIAL ITEMS If you have doubts about washing a particular item, check with the dishware manufacturer to make sure it is dishwasher safe. Dishwasher Material Comments Safe Possible High water temperature and detergents Aluminum can affect finish of anodized aluminum. Unfinished aluminum will be discolored. -
Page 29: Dishwasher Care
Dishwasher Material Comments Safe Sterling Run a rinse cycle if not washing immediately. Silver or Prolonged contact with food containing salt, Silver Plate acid, or sulfide (eggs, mayonnaise, and seafood) can damage finish. Can rust. Wooden Wash by hand. Always check Ware manufacturer’s instructions before washing. - Page 30 CONTROL PANEL Clean the Control Panel gently with a lightly dampened cloth. CLEANING THE FILTERS Check and clean the filters regularly for best performance. 1. Remove the lower dishwasher rack. 2. Rotate the Cylinder filter counterclockwise a quarter turn and lift up to remove.
-
Page 31: Storing
DRAIN AIR GAP Check the drain air gap anytime your dishwasher isn’t draining well. Some state or local plumbing codes require the addition of a drain air gap between a built-in dishwasher and the home drain system. If a drain is clogged, a drain air gap prevents water from backing up into the dishwasher. -
Page 32: Troubleshooting
Prepare for Use: 1. Reconnect the water, drain and electrical power supply. 2. Turn on water and electrical power supply. 3. Fill detergent cup and run the dishwasher through a heated wash cycle. 4. Check the connections for leaks. TROUBLESHOOTING DISHWASHER NOT OPERATING PROPERLY PROBLEM POSSIBLE CAUSE... - Page 33 PROBLEM POSSIBLE CAUSE SOLUTION Unable to The water supplied to Run the water in the maintain a the dishwasher is not adjacent sink until it gets hot hot enough. rolling boil or before turning on the will not cook dishwasher. The dishwasher runs fast enough longer while heating...
- Page 34 PROBLEM POSSIBLE CAUSE SOLUTION Grinding, IMPORTANT: Clear glass is A hard object or hard to see in water and grating, powder detergent crunching or could result in a cut wound. granules have entered buzzing the wash module. Using care, remove the hard sounds object.
- Page 35 PROBLEM POSSIBLE CAUSE SOLUTION Food residue Detergent is too old. Detergent must be fresh to remains on be effective. Store detergent the dishes in a cool, dry area. (cont.) Detergent is caked in Do not allow detergent to sit the dispenser. for several hours in a wet dispenser.
- Page 36 PROBLEM POSSIBLE CAUSE SOLUTION Spotting and Detergent is too old. Detergent must be fresh and filming on dry to be effective. Store dishes (cont.) detergent in a cool, dry area. Home water pressure is Water pressure to the home too low to fill should be 20 to 80 psi (138 to dishwasher properly.
-
Page 37: Error Codes
DISHES DO NOT DRY COMPLETELY PROBLEM POSSIBLE CAUSE SOLUTION Dishes are Load the dishes and glasses Dishes not loaded chipped so they are stable and will not properly. strike together from washing NOTE: Some action. types of china Minimize chipping by moving and glassware Moving the rack in or the rack in and out slowly. -
Page 38: Warranty
LIMITED WARRANTY WARRANTY AND SERVICE TO RECEIVE WARRANTY SERVICE, YOUR PRODUCT MUST BE REGISTERED. TO REGISTER AND REVIEW FULL WARRANTY DETAILS, VISIT: WWW.COSMOAPPLIANCES.COM/WARRANTY SCAN TO REGISTER CUSTOMER SUPPORT TO CHAT WITH US LIVE FOR ASSISTANCE, VISIT: WWW.COSMOAPPLIANCES.COM/CHAT SCAN TO CHAT... - Page 39 IMPORTANT Do Not Return This Product To The Store If you have a problem with this product, please contact COSMO Customer Support at +1 (888) 784-3108 DATED PROOF OF PURCHASE, MODEL #, AND SERIAL # REQUIRED FOR WARRANTY SERVICE. IMPORTANT Ne pas Réexpédier ce Produit au Magasin...
- Page 40 MEMO...
- Page 41 MEMO...
- Page 42 APPLIANCES Cosmo is constantly making efforts to improve the quality and performance of our products, so we may make changes to our appliances without updating this manual. Electronic version of this manual is available at: www.cosmoappliances.com...
