Guardian CABLE CLIMBING SYSTEM Instruction Manual page 11

Step 3

Tension cable by tightening Tensioning Nut
until it is at least flush with bottom of Bracket
(see image below).
Step 4

Confirm final location of Tensioning Nut and
secure Tensioning Bar by tightening Upper
and Lower Lock Nuts with 5/8" wrench until
they make firm contact with Bracket (Upper) or
Tensioning Nut (Lower). Confirm Cable Clamp
nut torque after tensioning system.
Confirm all other components of the system are
installed correctly. System is ready for use.
T
10-15 ft-lb
(14-20 Nm)
Upper Lock Nut
Bottom of Tensioning Nut
must be at least flush with
bottom of Bracket.
Lower Lock Nut
Anchorage Connector Use
 WARNING!
used to support a MAXIMUM 1 Personal Fall Arrest
System (PFAS) for use in Fall Arrest applications.
 WARNING!
System and Fall Arrest Anchorage Connector
simultaneously.
 WARNING!
Connector for applications where the fall hazard is
not directly below the connector. Not for Leading
Edge work or applications that could result in side
loading or horizontal fall arrest forces. May be used
in Travel Restraint applications.
 WARNING!
lifelines to maintain access. Never store SRL
lifeline extended such as connected to a lower
rung of fixed ladder systems.
 WARNING!
Climbing System MUST be removed from service.
<------->

11
Anchorage Connector may be
Never use Cable Climbing
Never use Fall Arrest Anchorage
Always use a tag line on SRL
In the event of a fall, Cable
Anchorage
Connector
