AXIS
I1000 | I1000DS FREESTANDING
INSTALLATION & USER GUIDE
1. PREFACE
2. SPECIFICATIONS AND CLEARANCES
3. PRELIMINARY INSTALL GUIDE
4. INSTALL GUIDE
5. OPERATION & MAINTENANCE
6. TEST REPORTS
7. WARRANTY
8. FINAL WORDS
NOTICE TO INSTALLER:
These instructions must be left with the owner, who should keep them for future use.
1
Edition: 26/10/2022
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sculpt AXIS I1000
Summary of Contents for Sculpt AXIS I1000
- Page 1 Edition: 26/10/2022 AXIS I1000 | I1000DS FREESTANDING INSTALLATION & USER GUIDE 1. PREFACE 2. SPECIFICATIONS AND CLEARANCES 3. PRELIMINARY INSTALL GUIDE 4. INSTALL GUIDE 5. OPERATION & MAINTENANCE 6. TEST REPORTS 7. WARRANTY 8. FINAL WORDS NOTICE TO INSTALLER: These instructions must be left with the owner, who should keep them for future use.
- Page 2 The instructions in this manual are recommendations only, the distributor and manufacturer bears no liability to the interpretation of these instructions. Please ensure to download the latest version of this manual from our website: www.sculpt replaces.com.au/installation-manuals/ © Copyright 2021 Sculpt Fireplaces Collection...
- Page 3 Follow @sculpt replacecollection on Instagram, SculptFireplaceCollection on Facebook and be sure to post your latest masterpiece installed with the hashtag #sculpt res. We hope we’ve helped make you the envy of your friends this winter and for years to come.
- Page 4 When in use some parts may become hot. A suitable re guard is recommended where very young, elderly or in rm are concerned. The instructions in this manual are recommendations only, the distributor and manufacturer bears no liability to the interpretation of these instructions. © Copyright 2021 Sculpt Fireplaces Collection...
-
Page 5: Specifications
2. SPECIFICATIONS AXIS I1000 Single Sided Material Solid steel rebox with rebricks Heating Capacity Up to 15 to 30 Squares Avg Emissions 1.2g/kg Avg E ciency Glass Door Secure swing door opening system Minimum Flue Height 4.6m Flue Dimensions 197mm, 250mm, 200mm... - Page 6 Clearances & Hearth- Axis I1000 Single Sided This appliance and ue were tested at the following clearances. The Axis I1000 Single sided free standing appliance and 8” ue system with a painted solid casing between the appliance and ceiling conforming to joint Australian/New Zealand Standards 2918:2001, Appendix B.
- Page 7 2. SPECIFICATIONS AXIS I1000 DS Double Sided Material Solid steel rebox with rebricks Heating Capacity Up to 15 to 30 Squares Avg Emissions 1.0g/kg Avg E ciency Glass Door 2X Secure swing door opening systems Minimum Flue Height 4.6m Flue Dimensions...
- Page 8 This appliance and ue were tested at the following clearances: The Axis I1000 Double Sided free standing appliance and 8” ue system with a solid casing between the appliance and ceiling conforming to joint Australian/New Zealand Standards 2918:2001, Appendix B.
-
Page 9: Important Warning
3. PRELIMINARY INSTALL GUIDE It is the users duty to make themselves aware of and apply all national or more restrictive local standards and instructions (AS/NZS 2918:2018). IMPORTANT Prior to unpacking and installation ensure the appliance has not been damaged during transit. Please ensure you check the glass, the door(s), the damper operation and the door locking mechanism Before any work is carried out, as per local and national regulations and laws, this appliance MUST be installed by a licensed professional as per AS/NZS 2918:2018. - Page 10 It is strongly recommended that the licensed trade professional who is performing the installation of this appliance, completely read and comprehend all instructions in this manual prior to proceeding. Sculpt Fireplaces & Axis reserves the right to change these speci cations without prior notice. ACCEPTABLE VARIANCE ALLOWANCE Due to the production of these hand assembled and manufactured replaces, there is an acceptable allowance of 3-5mm variance of the unit, including the door frame.
-
Page 11: Install Guide
4. INSTALL GUIDE FIREBOX LOCATION Prior to proceeding with installation thoroughly investigate the materials composing the surrounding back walls, oor and ceiling of the desired position of the rebox. Combustible heat degrading materials, electric wiring or gas piping MUST NOT be located within the distance speci ed by the clearances (pg. - Page 12 FLUE OUTER BOTTOM LENGTH OF FLUE MUST BE VENTED AXIS I1000 BENCH *MIN 250MM HEARTH MIN 9MM THICK *The appliance must be elevated a minimum of 250mm above the hearth (on a non combustible surface). If the heater is placed directly onto the hearth, the hearth dimensions required will be greater. Please refer to AS/NZS 2918:2018 as per the minimum for a non-tested appliance.
-
Page 13: Flue System Installation
4. INSTALL GUIDE FLUE SYSTEM INSTALLATION Listed below are the general instructions for ue system install, please refer to these during the ue installation process. • Inner active ue installed crimped/narrow end down • Outer casing installed crimped/narrow end up (critical when exposed above the roof line). •... -
Page 14: Commissioning The Appliance
4. INSTALL GUIDE COMMISSIONING THE APPLIANCE These instructions are to be kept by the user, the installer under any circumstances MUST NOT dispose of this manual. Following installation it is recommended the installer review any questions or queries the new user might have, this should include lighting the re and explaining the various functioning components of the appliance. - Page 15 OPERATION & MAINTENANCE COMBUSTION AIR CONTINUED This will make it possible to renew the air when the wood heater is in use and will guarantee that the correct pressure is maintained inside the room. Ideally, this air intake should arrive under the wood heater.
- Page 16 OPERATION & MAINTENANCE OPERATION & USER GUIDE OPERATING THE WOOD BURNER WITH THE DOOR OPEN EXPOSES YOU TO MULTIPLE HAZARDS FALLING EMBERS, SMOKE EMISSIONS IN THE ROOM, ETC. . ALWAYS OPERATE THE APPLIANCE WITH THE DOOR CLOSED. PRECAUTIONS FOR THE FIRST IGNITION - CURE WITH 10 SMALL FIRES The rst ten res should be light, moderate and not overly loaded with wood.
- Page 17 OPERATION & MAINTENANCE OPERATION & USER GUIDE CONTINUED IGNITION INSTRUCTIONS (continued) After an extended time of non-use, it is recommended that the rebox be checked and cleaned by a professional to ensure there is no obstruction in the ue and no blocking of the manoeuvring members (damper) before ignition.
- Page 18 For safety reasons, assemblies of appliances and accessories not provided or recommended by Axis or Sculpt Fireplaces are NOT PERMITTED. Unsuitable equipment may cause dysfunctions and disorder upon use. EXTINGUISHING THE FIRE Stop fuelling the re and let it burn out.
-
Page 19: Slow Burning
OPERATION & USER GUIDE CONTINUED IMPORTANT WARNING Storing any ammable materials (paper, linen, furniture, solvents, ammable liquids, spray containers, gas bottle, etc.) close to the replace is strictly forbidden. All these products should never be stored even for a short while in wood storages or recesses laid out under or near the appliance. - Page 20 MAINTENANCE CONTINUED FLUE & FIREBOX Flues should be professionally cleaned and checked twice a year, including at least once during the peak period of use and more if required. A professional should also check seals, door ropes, ba e plates and all consumable parts of the rebox and ue to ensure the unit is in safe working order.
- Page 21 Buy new spares from the dealer in use (grate, ba e board, need to be replaced (not covered by (dealers information can be found on the rear panel, side panels, warranty - see warranty terms and website: https://sculpt replaces.com.au/ glass plate, seals) conditions) stockists/)
-
Page 22: Test Reports
66% CONCLUSION The Axis I1000 solid fuel appliance complies with the requirements of AS/NZS 4012/4013(2014). AXIS I1000 DS FREE STANDING PARTICULATE EMISSIONS, POWER OUTPUT & EFFICIENCY TEST TESTING LABORATORY Australian Solid Fuel Testing P/L MANUFACTURER... -
Page 23: Warranty Does Not Cover
Australian & New Zealand Standards AS/NZS 2918:2018 or instructions are listed in this manual are not warranted Any device or accessory not provided by AXIS or Sculpt Fireplace Collection are strictly forbidden and will result in a void of all warranties by the manufacturer and distributor... -
Page 24: Product Registration Card
DATE OF PURCHASE PLACE OF PURCHASE DATE OF INSTALLATION COMPLIANCE CERTIFICATE NO. MODEL NO. NAME AND ADDRESS OF PURCHASER PHONE NO. EMAIL ADDRESS Please include a copy of your receipt and compliance certi cate EMAIL PRODUCT REGISTRATION INFORMATION TO info@sculpt replaces.com.au... - Page 25 Whilst every e ort is taken to avoid errors, SCULPT FIREPLACE COLLECTION cannot accept responsibility for the accuracy of any statement, extract or information contained within this manual nor can any of its contributors who have submitted material for inclusion. SCULPT FIREPLACE COLLECTION may change or update this manual and anything described in it without notice.
-
Page 26: Final Words
Sculpt is proud to be the sole importer of Seguin, Axis and Bordelet replaces, with exclusive distribution rights throughout Australia and New Zealand. - Page 27 THIS PAGE INTENTIONALLY LEFT BLANK...
- Page 28 1300 851 304 info@sculpt replaces.com.au sculpt replaces.com.au Edition: 26/10/2022...
