Sculpt SEGUIN Aurore Installation & User Manual

Hide thumbs

Table Of Contents

SeGUin

Aurore, Topaze, Saphir & Jade

inStallation & USer GUide

1. SpecificationS and clearanceS

2. preliminary inStall GUide

3. inStall GUide

4. operation & maintenance

5. teSt reportS

6. Warranty

notice to inStaller:

these instructions must be left with the owner, who should keep them for future use.

Table of Contents

Need help?

Do you have a question about the SEGUIN Aurore and is the answer not in the manual?

Questions and answers

Summary of Contents for Sculpt SEGUIN Aurore

Page 1 SeGUin Aurore, Topaze, Saphir & Jade inStallation & USer GUide 1. SpecificationS and clearanceS 2. preliminary inStall GUide 3. inStall GUide 4. operation & maintenance 5. teSt reportS 6. Warranty notice to inStaller: these instructions must be left with the owner, who should keep them for future use.
Page 2 ComplianCe plate and serial number. the instructions in this manual are recommendations only, the distributor and manufacturer bears no liability to the interpretation of these instructions.
Page 3 Congratulations! thank you for choosing Sculpt fireplaces as your heater of choice. Your fireplace is the result of careful design, artisan engineering and safety tests. If it is properly installed, used and maintained, you may be sure that you will have an outstanding heating feature in your home for years to come.
Page 4 When in use some parts may become hot. A suitable fire guard is recommended where very young, elderly or infirm are concerned. the instructions in this manual are recommendations only, the distributor and manufacturer bears no liability to the interpretation of these instructions. © copyright 2019 Sculpt fireplaces collection...
Page 5: Specifications
1. SpecificationS Seguin aurore material Cast iron firebox with vermiculite lining dual damper Control combustion air & glass air wash control heating Capacity Up to 140m Kw output avg emissions 1.5g/kg Avg Efficiency door operation two secure swing door opening system minimum flue height 4.6m from the hearth...
Page 6 1. SpecificationS Seguin Saphir material Cast iron firebox with vermiculite lining dual damper Control combustion air & glass air wash control heating Capacity Up to 140m Kw output avg emissions 1.5g/kg Avg Efficiency door operation two secure swing door opening system minimum flue height 4.6m from the hearth flue dimensions...
Page 7 Seguin aurore free standing appliance and triple skin flue kit with Solid 8” casing were tested in two positions in a manner conforming to australian & new Zealand Standards 2918:2018, appendix B.
Page 8 1. SpecificationS Seguin Topaze material Cast iron firebox with vermiculite lining dual damper Control combustion air & glass air wash control heating Capacity Up to 160m Kw output 10.8kW avg emissions 1.3g/kg Avg Efficiency door operation two secure swing door opening system minimum flue height 4.6m from the hearth flue dimensions...
Page 9 1. SpecificationS Clearances & Hearth- Seguin Topaze this appliance and flue were tested with the following minimum clearances. The Seguin Topaze free standing appliance and triple skin flue kit with Solid 8” casing were tested in two positions in a manner conforming to australian & new Zealand Standards 2918:2018, appendix B. a minimum 1120mm deep X 940mm wide and 18mm thick non-combustible hearth should be installed, refer to aS/nZS 2918:2018 3.3 floor protector.
Page 10 1. SpecificationS Seguin Jade material Cast iron firebox with vermiculite lining dual damper Control combustion air & glass air wash control heating Capacity Up to 120m Kw output 7.4kW avg emissions 1.1g/kg Avg Efficiency door operation Secure swing door opening system minimum flue height 4.6m from the hearth flue dimensions...
Page 11 1. SpecificationS clearances & Hearth- Seguin Jade this appliance and flue were tested with the following minimum clearances. The Seguin Topaze free standing appliance and triple skin flue kit with Solid 8” casing were tested in two positions in a manner conforming to australian & new Zealand Standards 2918:2018, appendix B. a minimum 810mm deep X 770mm wide and 6mm thick non-combustible hearth should be installed, refer to aS/nZS 2918:2018 3.3 floor protector.
Page 12: Important Warning
2. preliminary inStall GUide it is the users duty to make themselves aware of and apply all national or more restrictive local standards and instructions (aS/nZS 2918:2018). iMPortant Prior to unpacking and installation ensure the appliance has not been damaged during transit. Please ensure you check the glass, the door, the air flow damper controls and the door locking mechanism.
Page 13 Sculpt Fireplaces & Seguin reserves the right to change these specifications without prior notice. aCCeptable VarianCe allowanCe Due to the production of these hand assembled and manufactured fireplaces, there is an acceptable allowance of 3-5mm variance of the unit, including the door frame.
Page 14: Install Guide
3. inStall GUide Firebox loCation Prior to proceeding with installation thoroughly investigate the materials composing the surrounding back walls, floor and ceiling of the desired position of the firebox. Combustible heat degrading materials, electric wiring or gas piping MUST NOT be located within the distance specified by the clearances (see specifications).
Page 15 3. inStall GUide ClearanCe Min 3000MM (in all DireCtions) venteD CoWl Cover Cone rooF Flashing triPle skin Flue rooF Cavity braCes to suPPort Flue Ceiling Ceiling Plate DroPPer box Min 150MM beloW Ceiling Flue inner (aCtive) Flue outer hearth* this diagram is not to scale, the author of this manual bears no liability to the misinterpretation of this diagram. *Refer to specifications on previous pages for dimensions and thickness.
Page 16: Flue System Installation
3. inStall GUide Flue systeM installation listed below are the general instructions for flue system installation. Please refer to these during the flue installation process. • inner active flue installed crimped/narrow end down • outer casing installed crimped/narrow end up (critical when exposed above the roof line). •...
Page 17: Commissioning The Appliance
3. inStall GUide ProCess For Flue systeM installation (Cont.) step 11. position and secure the ceiling plate with the screws and spacers. step 12. Clean the flue pipe to ensure all marks (finger or otherwise) are removed prior to proceeding. step 13.
Page 18: Installing The Heat Shield
3. inStall GUide installing the heat shielD 1. Unscrew the four screws at the back of the appliance and use these screws to attach the brackets. 2. Unscrew the screws from the brackets 3. align the heat shield to the brackets and screw in place...
Page 19 3. inStall GUide CoMbustion air (oPtional outDoor air kit) this appliance cannot operate in a de-pressurised room. the presence of a hood, mechanically controlled ventilation or another heating appliance requiring air in a well insulated dwelling may cause disturbances (incorrect combustion, smoke drawn back into the room, etc.). it is important that there is sufficient quantity of air that can be drawn from the room as it is needed to burn the wood.
Page 20: Ignition Instructions
operation & maintenance operation & user guide oPerating the WooD burner With the Door oPen exPoses you to MultiPle haZarDs (Falling eMbers, sMoke eMissions in the rooM, etC.). alWays oPerate the aPPlianCe With the Door CloseD. preCautions for the first ignition - Cure with 10 small fires The first ten fires should be light, moderate and not overly loaded with wood.
Page 21 The more air you will supply into the stove, the more intense your fire will be, but with a shorter time of combustion. on the contrary, a reduced quantity of air would increase the combustion with less heat output. air Controls for seguin aurore, saphir and topaZe Combustion air control Closed Combustion air control...
Page 22 operation & maintenance operation & user guide (Continued) establishing the first fire Before establishing the first fire, remove all labels or equipment parts located in the ash box or in the furnace. While building your first fire, keep the combustion rate at a moderate level to ensure that the sealant binds with the paint.
Page 23: Slow Burning
Stop fuelling the fire and let it burn out.
Page 24: Cleaning The Glass
operation & maintenance operation & user guide (Continued) maintenanCe the vitro-ceramic glass can withstand temperatures of up to 750°c. if the glass breaks following a handling error, it is not recommended to replace it using a material other than that supplied by the manufacturer. the original glass quality must be used to maintain any warranty of the wood stove.
Page 25: Chimney Fires
operation & maintenance maintenanCe (Continued) Chimney sweeping prior to using and installing into an existing chimney, it’s necessary to perform a chimney sweep and ensure it’s clear of any build up (cresote, bird’s nest, etc). chimney sweeps should be performed twice a year, including at least once during the period of use.
Page 26 operation & maintenance maintenanCe (Continued) Chimney fires (Continued) symptoms possible cause proposed course of action 1. Smoke comes from 1. air supply ventilation is choked 1. provide a clear ventilation shaft the fireplace 2. Size of chimney shaft or its length is not 2.
Page 27: Test Reports
AS/NZS 4014.1 and the average efficiency of the appliance for all burn rates was 63% conclUSion the Seguin aurore and Saphir solid fuel appliance complies with the requirements of aS/nZS 2918:2018 and joint australian & new Zealand Standard aS/nZS 4012/4013 (2014)
Page 28 5. teSt reSUltS test reports seguin topaZe free standing partiCulate emissions, power output & effiCienCy test teStinG laBoratory australian Solid fuel testing p/l manUfactUrer Seguin model Seguin Topaze iSSUe date 15th october 2019 inveStiGatinG officer Steve marland reSUltS the appliance particulate emissions factor was 1.3g/Kg of hard wood that complies to AS/NZS 4014.1 and the average efficiency of the appliance for all burn rates was 64% conclUSion...
Page 29 5. teSt reSUltS test reports seguin Jade free standing partiCulate emissions, power output & effiCienCy test teStinG laBoratory australian Solid fuel testing p/l manUfactUrer Seguin model Seguin Jade iSSUe date 12th august 2019 inveStiGatinG officer Steve marland reSUltS the appliance particulate emissions factor was 1.1g/Kg of hard wood that complies to AS/NZS 4014.1 and the average efficiency of the appliance for all burn rates was 68% conclUSion...
Page 30: Warranty Does Not Cover
& new Zealand Standards aS/nZS 2918:2018 or instructions are listed in this manual are not warranted any device or accessory not provided by Seguin or Sculpt fireplace collection are strictly forbidden and will result in a void of all warranties by the manufacturer and distributor...
Page 31: Warranty Card
6. Warranty warranty Card date of purChase plaCe of purChase date of installation ComplianCe CertifiCate no. model no. name and address of purChaser phone no. email address Please include a copy of your receipt and compliance certificate email or post warranty information to info@sculptfireplaces.com.au po Box, 1232 mornington, vic 3931 1300 851 304...
Page 32 ScUlpt fireplace collection may change or update this manual and anything described in it without notice. We will endeavour to ensure that information, materials and data on this site are complete, accurate and up-to-date.
Page 33: Final Words
Sculpt Fireplace Collection is proud to be the sole importer of Seguin, Axis and Bordelet fireplaces, with exclusive distribution rights throughout Australia and New Zealand.
Page 34 1300 851 304 info@sculptfireplaces.com.au po Box, 1232 mornington, vic 3931 edition 12.12.19...
