I1000 | I1000DS IB ZERO CLEARANCE
inStallation & USer GUide
1. preface
2. SpecificationS and clearanceS
3. preliminary inStall GUide
4. Zero clearance aSSemBly
5. inStall GUide
6. operation & maintenance
7. teSt report
8. Warranty
notice to inStaller:
these instructions must be left with the owner, who should keep them for future use.
1
Advertisement
Table of Contents
Related Manuals for Sculpt AXIS Series
Summary of Contents for Sculpt AXIS Series
- Page 1 aXiS I1000 | I1000DS IB ZERO CLEARANCE inStallation & USer GUide 1. preface 2. SpecificationS and clearanceS 3. preliminary inStall GUide 4. Zero clearance aSSemBly 5. inStall GUide 6. operation & maintenance 7. teSt report 8. Warranty notice to inStaller: these instructions must be left with the owner, who should keep them for future use.
- Page 2 Congratulations! ComplianCe plate and serial number. thank you for choosing Sculpt fireplaces as your heater of choice. Your fireplace is the result of careful design, artisan engineering and safety tests. If it is properly installed, used and maintained, you may be sure that you will have an outstanding heating feature in your home for years to come.
-
Page 3: Specifications
**See warranty pg. 29 of the manual. the instructions in this manual are recommendations only, the distributor and manufacturer bears no liability to the interpretation of these instructions. ***refer to pg. 7 for further details about the clearances & hearth. © copyright 2019 Sculpt fireplaces collection... - Page 4 2. SpecificationS 2. SpecificationS clearances & Hearth- axis i1000iB SinGle Sided aXiS i1000iB double Sided this appliance and flue were tested with the following minimum clearances. the axis i1000iB and Z/c box was tested in a combustible enclosure in a manner conforming to aS/nZS 2918:2001, appendix B.
-
Page 5: Important Warning
2. SpecificationS 3. preliminary inStall GUide clearances & Hearth- axis i1000iB doUBle Sided this appliance and flue were tested with the following minimum clearances. it is the users duty to make themselves aware of and apply all national or more restrictive local the axis i1000iB double sided and Z/c box was tested in a combustible enclosure in a manner standards and instructions (AS/NZS 2918:2018). - Page 6 Sculpt Fireplaces & Axis reserves the right to change these specifications without prior notice. aCCeptable VarianCe allowanCe Due to the production of these hand assembled and manufactured fireplaces, there is an acceptable allowance of 3-5mm variance of the unit, including the door frame.
-
Page 7: Install Guide
4. Zero clearance aSSemBly 5. inStall GUide ZEro ClEaranCE assEMBly guiDE ContinuED.. FirEBox loCation step 4: assemble baCK panel Note: This step applies to Single Sided appliances only. Prior to proceeding with installation thoroughly investigate the materials composing the surrounding assemble the back panel to the back of the top, sides and base back walls, floor and ceiling of the desired position of the firebox. -
Page 8: Commissioning The Appliance
5. inStall GUide operation & maintenance CoMMissioning thE aPPlianCE CoMBustion air (outDoor air kit) (ContinuED) these instructions are to be kept by the user, the installer mUSt not under any circumstances dispose of this manual. following installation it is recommended the installer review any questions or queries It is preferable to connect to outdoor air in order to optimise combustion control. - Page 9 5. inStall GUide - SinGle Sided 5. inStall GUide - doUBle Sided WinDriM CoWl WinDriM CoWl Min CoWl ClEaranCE 3000MM Min CoWl ClEaranCE 3000MM vEntED vEntED (in all DirECtions) (in all DirECtions) CovEr ConE CovEr ConE rooF Flashing rooF Flashing triPlE skin FluE triPlE skin FluE intErior rooF...
-
Page 10: Flue System Installation
5. inStall GUide 5. inStall GUide axis ash gratE installation FluE systEM installation the axis ash Grates are made up of 2 parts. By slipping the smaller grate inside the larger grate listed below are the general instructions for flue system install, please refer to these during the flue (see Figure 1) the primary airflow can be adjusted to supply combustion air directly to the embers installation process. -
Page 11: Ignition Instructions
operation & maintenance 5. inStall GUide axis ash gratE installation (ContinuED) By sliding the ash Grate back, the primary airflow can be adjusted. figure 3 shows the ash Grate in the operation & user guide fully-closed position. oPErating thE WooD BurnEr With thE Door oPEn ExPosEs you to MultiPlE haZarDs (Falling EMBErs, sMokE EMissions in thE rooM, EtC.). - Page 12 Before reloading, make sure use.
- Page 13 operation & maintenance operation & maintenance operation & user guide (Continued) maintenanCe (Continued) flue & fireboX iMPortant Warning flues should be professionally cleaned and checked twice a year, including at least once during the peak Storing any flammable materials (paper, linen, furniture, solvents, flammable liquids, spray containers, period of use and more if required.
-
Page 14: Test Results
7. teSt reSUltS operation & maintenance test reports maintenanCe (Continued) CHimneY fires (Continued) aXis i1000 single sided inbuilt partiCulate emissions, power output & Suggested course of action in case of chimney fires: effiCienCY test 1. Put out the fire by carefully removing the glowing logs and fully close the fireplace door. 2. -
Page 15: Warranty Card
Sculpt fireplace collection are strictly forbidden and will result in a void of all warranties by the manufacturer and distributor... -
Page 16: Final Words
Sculpt Fireplace Collection is proud to be the sole importer of Seguin, Axis and Bordelet fireplaces, with exclusive distribution rights throughout Australia and New Zealand. - Page 17 1300 851 304 info@sculptfireplaces.com.au po Box, 1232 mornington, vic 3931 edition 04.07.19...
