aXiS
I1000 | I1000DS
inStallation & USer GUide
1. preface
2. SpecificationS and clearanceS
3. preliminary inStall GUide
4. inStall GUide
5. operation & maintenance
6. teSt reportS
7. Warranty
8. final WordS
notice to inStaller:
these instructions must be left with the owner, who should keep them for future use.
1
Advertisement
Table of Contents
Related Manuals for Sculpt AXIS 1000
Summary of Contents for Sculpt AXIS 1000
- Page 1 aXiS I1000 | I1000DS inStallation & USer GUide 1. preface 2. SpecificationS and clearanceS 3. preliminary inStall GUide 4. inStall GUide 5. operation & maintenance 6. teSt reportS 7. Warranty 8. final WordS notice to inStaller: these instructions must be left with the owner, who should keep them for future use.
- Page 2 ComplianCe plate and serial number. the instructions in this manual are recommendations only, the distributor and manufacturer bears no liability to the interpretation of these instructions.
- Page 3 Congratulations! thank you for choosing Sculpt fireplaces as your heater of choice. Your fireplace is the result of careful design, artisan engineering and safety tests. If it is properly installed, used and maintained, you may be sure that you will have an outstanding heating feature in your home for years to come.
- Page 4 all fireplaCes in this manual Conform to australian and new Zealand standards as/nZs 2918;2001 domestiC solid fuel burning applianCes & as/nZs 4012/4013(2014). iMPortant *Heating capacity of the following appliances are a guide only and refers to areas with 2.4m ceilings and 6 or more star rated buildings.
-
Page 5: Installation Guide
1. preface installation guiDE axis i1000 & i1000Ds this wood heater must be installed according to standard trade practices(as per aS/nZS 2918:2001), according to the manufacturer’s instructions, in addition to local and national regulations (the most restrictive of the regulations are applicable). This appliance must be installed by a qualified and licensed professional. - Page 6 2. SpecificationS aXiS i1000 Single Sided material Solid steel firebox with fire bricks heating Capacity Up to 15 to 30 Squares* avg emissions 1.2g/kg Avg Efficiency glass door Secure Swing door opening system minimum flue height 3.6m internal flue sizes 200m inner outside air kit recommended for well insulated homes...
- Page 7 2. SpecificationS clearances & Hearth- axis i1000 Single Sided this appliance and flue were tested at the following clearances. the axis i1000 Single sided free standing appliance and flo-met universal 8” flue system with a painted solid casing between the appliance and ceiling conforming to joint australian/new Zealand Standards 2918:2001, appendix B.
- Page 8 2. SpecificationS aXiS i1000 dS double Sided material Solid steel firebox with fire bricks heating Capacity Up to 15 to 30 Squares* avg emissions 1.0g/kg Avg Efficiency glass door 2X Secure swing door opening systems minimum flue height 3.6m internal flue sizes 200mm inner outside air kit recommended for well insulated homes...
- Page 9 2. SpecificationS clearances & Hearth- axis i1000 dS double Sided this appliance and flue were tested at the following clearances. the axis i1000 double free standing appliance and flo-met universal 8” flue system with a painted solid casing between the appliance and ceiling conforming to joint australian/new Zealand Standards 2918:2001, appendix B.
-
Page 10: Important Warning
3. preliminary inStall GUide it is the users duty to make themselves aware of and apply all national or more restrictive local standards and instructions(aS/nZS 2918:2001). iMPortant Prior to unpacking and installation check that the appliance has not been damaged during transport. Ensure you check the glass, the door(s), the damper operation and the door locking mechanism before any work is carried out, as per local and national regulations and laws, this appliance Must be installed by a licensed professional as per australian and new Zealand standards 2918:2001. - Page 11 Sculpt Fireplaces & Axis reserves the right to change these specifications without prior notice. aCCeptable VarianCe allowanCe Due to the production of these hand assembled and manufactured fireplaces, there is an acceptable allowance of 3-5mm variance of the unit, including the door frame.
-
Page 12: Firebox Location
4. inStall GUide FirEbox loCation Prior to proceeding with installation thoroughly check the materials composing the surrounding back walls, floor and ceiling of the desired position of the firebox. Combustible heat degrading materials, electric wiring or gas piping MUST NOT be located within the distance specified by the clearances( pg 7,9).Ensure the flooring can support the weight of the appliance(see weight in specifications). - Page 13 4. inStall GUide ClEaranCE Min 3000MM (in all DirECtions) vEntED CoWl CovEr ConE rooF Flashing triPlE skin FluE rooF Cavity braCEs intErior rooF to suPPort FluE CEiling PlatE DroPPEr box Min 150MM bEloW CEiling FluE innEr FluE outEr bottoM lEngth oF FluE Must bE vEntED...
-
Page 14: Flue System Installation
4. inStall GUide FluE systEM installation listed below are the general instructions for flue system install, please refer to these during the flue installation process. • inner active flue installed crimped/narrow end down • outer casing installed crimped/ narrow end up (critical when exposed above the roof line). •... -
Page 15: Commissioning The Appliance
4. inStall GUide CoMMissioning thE aPPlianCE these instructions are to be kept by the user, the installer under any circumstances mUSt not dispose of this manual. following installation it is recommended the installer review any questions or queries the new user might have, this should include lighting the fire and explaining the various functioning components of the appliance. - Page 16 operation & maintenance CoMbustion air ContinuED this will make it possible to renew the air when the wood heater is in use and will guarantee that the correct pressure is maintained inside the room. ideally, this air intake should arrive under the wood heater.
-
Page 17: Lighting The Fire
operation & maintenance operation & user guide operating the wood burner with the door open exposes you to multiple haZards (falling embers, smoke emissions in the room, etC.). always operate the applianCe with the door Closed. preCautions for the first ignition - Cure with 10 small fires The first ten fires should be light, moderate and not overly loaded with wood. - Page 18 Misty or foggy weather may possibly favour back-flow of the smoke, which may be a health hazard. In this case only use the fireplace as is necessary. for safety reasons, assemblies of appliances and accessories not provided or recommended by axis or sculpt fireplaces are not permitted. unsuitable equipment may cause dysfunctions and disorder upon use).
-
Page 19: Cleaning The Glass
operation & maintenance iMPortant Warning storing any flammable materials (paper, linen, furniture, solvents, flammable liquids, spray containers, gas bottle, etc.) close to the fireplace is strictly forbidden. all these products should never be stored even for a short while in wood storages or recesses laid out under or near the appliance. -
Page 21: Test Reports
6. teSt reSUltS test reports axis i1000 free standing partiCulate emissions, power output & effiCienCy test teStinG laBoratory Hrl technology manUfactUrer axis model axis po-1000 Sf free Standing iSSUe date 09.04.2017 inveStiGatinG officer Steve marland reSUltS the appliance particulate emissions factor was 1.2/kg of hard wood that complies to AS/NZS 4014.1 and the average efficiency of the appliance for all burn rates was 66% conclUSion... -
Page 22: Warranty
& new Zealand Standards aS/nZS 2918:2001 or instructions are listed in this manual are not warranted any device or accessory not provided by aXiS or Sculpt fireplace collection are strictly forbidden and will result in a void of all warranties by the manufacturer and distributor... -
Page 23: Warranty Card
7. Warranty warranty Card date of purChase plaCe of purChase date of installation ComplianCe CertifiCate no. model no. name and address of purChaser phone no. email address Please include a copy of your receipt and compliance certificate email or post warranty information to info@sculptfireplaces.com.au po Box, 1232 mornington, vic 3931 1300 851 304... - Page 24 ScUlpt fireplace collection may change or update this manual and anything described in it without notice. We will endeavour to ensure that information, materials and data on this site are complete, accurate and up-to-date.
- Page 25 Sculpt is proud to be the sole importer of Seguin, Axis and Bordelet fireplaces, with exclusive distribution rights throughout Australia and New Zealand.
- Page 26 1300 851 304 info@sculptfireplaces.com.au po Box, 1232 mornington, vic 3931 edition 10.05.17...
