Arrow Storage Products SG102 Owner's Manual & Assembly Manual

Nominal size 10' x 2'
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
721760618
Owner's Manual
& Assembly Guide
Gloves must be worn
at all times to reduce
risk of injury!
Customer Service:
1-800-851-1085
assist@arrowsheds.com
BUILDING DIMENSIONS
†
Approx.
Storage
Size
10' x 2'
21 Sq. Ft. 138 Cu. Ft.
2
3,0 m x 0,6 m
2,0 m
* See Inside for Detailed Safety Information.
or
†
Size rounded off to the nearest foot
Exterior Dimensions
(Roof Edge to Roof Edge)
Area
Width
Depth
123 1/4"
30 3/4"
3,9 m 3
313,1 cm
78,1 cm
Model No. SG102
Base
Size
Interior Dimensions
(Wall to Wall)
Height
Width
Depth
87 7/8"
118 1/4"
25 1/2"
223,2 cm
300,4 cm
64,8 cm
www.arrowsheds.com
LX102
10' x 2'
121" x 28 1/4"
307,3 cm x 71,8 cm
For proper base construction see page 12
Door
Opening
Height
Width
Height
83 5/8"
55 1/2"
212,4 cm
141,0 cm
152,4 cm
01FV
Nominal Size
60"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SG102 and is the answer not in the manual?

Questions and answers

Related Manuals for Arrow Storage Products SG102

Summary of Contents for Arrow Storage Products SG102

  • Page 1 01FV 721760618 Owner’s Manual & Assembly Guide www.arrowsheds.com Model No. SG102 LX102 Gloves must be worn at all times to reduce 10’ x 2’ risk of injury! Nominal Size Customer Service: 1-800-851-1085 Base 121” x 28 1/4” assist@arrowsheds.com Size 307,3 cm x 71,8 cm...
  • Page 2 SAFETY PRECAUTIONS... Safety precautions MUST be followed at all times throughout the construction of your building! Practice caution with the tools being used in the Care must be taken when handling various pieces assembly of this building. Be especially familiar with of your building since many contain sharp edges.

  • Page 3: What You Need

    ASSEMBLY TIPS & TOOLS Watch the Weather Closely: Be sure the day you choose to install your building is dry and calm. Do NOT attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Use Teamwork: Two or more people are required to assemble your building.

  • Page 4: Frequently Asked Questions

    FREQUENTLY ASKED QUESTIONS How long will it take to assemble the building? Assembly time depends on a variety of factors, including roof design, tools available, DIY skill and the pace at which you work. Guidelines for each shed assembly are approximate AFTER completion of the base, and assume two or more people working on the assembly.
  • Page 5 What kind of base do I use? You can: •Use an Arrow Base Kit •Pour a concrete slab •Build a wood deck/fl oor (use exterior-grade plywood) •Use patio blocks •Build on crushed gravel, dirt or grass Arrow provides a base kit accessory that is an option for most building sizes. If you are building a wood deck/fl oor, an Arrow fl...

  • Page 6: Customer Service

    What if the rear wall angle and channels are too large to fi t inside of the rear wall panels? Check the dimensions of wall assemblies. They should be slightly smaller than the fl oor frames. Lay the assemblies on top of the rear fl oor frame and pull them up to the top of the wall panels causing the corner panels to stand erect and not lean inward.
  • Page 7 HARDWARE LIST... 07BB Hardware Views by Key No. Part Part Qty. Description List #2 Phillips #2 Phillips 11/32 Hex. 65103 Hex Nut (#8-32) 65923 Small Bolt (#8-32 x 3/8) (10 mm) 65004 Small Screw (#8AB x 5/16) (8 mm) 5/16 Hex. #2 Phillips 65109 Acorn Nut...
  • Page 8 PARTS LIST... 08BB Selected End Views by Key No. Part Part Qty. Description List 3719 Door Handle Brace 6085 Roof Beam Bracket 6227 Roof Beam Brace 6636 Gable Brace 9365 Front Wall Channel 10497 Horizontal Door Brace 5986 Rear Wall Angle 6014 Side Roof Trim 6108...
  • Page 9 ASSEMBLY BY KEY NO. 09BB Walls Floor...
  • Page 10 ASSEMBLY BY KEY NO. 10BB Roof Doors...

  • Page 11: Assembly Overview

    ASSEMBLY OVERVIEW 11BB Install Corners, Wall Angles, Door Build the Floor Frame Track, and Door Jamb Attach Gables and Roof Beams Install Wall Panels and Wall Channels Install Roof Panels, Ridge Cap, Side Install Doors Trim, and Corner Cap Shed is now complete.
  • Page 12 CONSTRUCTING A BASE... 12BB No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is recommended as an effective method of properly securing your building after assembly is complete. OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.).
  • Page 13 Step 1: Floor Frames You will need for this page: 8936 Rear Floor (QTY: 5) Frame Assemble the Rear Floor Frames. Bolts thru Top. Bolts thru Bottom. 8936 Overlap two (2) Rear Floor Frames as shown and secure with fi ve (5) bolts. Two (2) bolts must enter from bottom.
  • Page 14 Step 1: Continued You will need for this page: 119 3/8” 303,2 cm 9367 8934 Finished Length Front Floor Ramp (QTY: 8) Frame Overlap Length 7 3/8” 18,7 cm 9367 Overlap the Ramp and two (2) Front Floor 8934 Frames so that four (4) holes align at each end as shown.
  • Page 15 Step 2: Wall Frames You will need for this page: 5986 9917 Rear Angle Rear Channel (QTY: 2) 5986 9917 5986 Overlap two (2) Rear Wall Channels so that three (3) holes align as shown. Insert 9917 a bolt and nut through the center hole. Check that the fi...
  • Page 16 Step 3: 16BB Roof Beam Assembly You will need for this page: 6659 Roof Beam (QTY: 2) Place two (2) Roof Beams back-to-back with small holes on top. Fasten together using two (2) Bolts and Nuts. DO NOT FULLY TIGHTEN. End view of Roof Beam 6659 6659...

  • Page 17: Step 4: Door Track

    Step 4: Door Track You will need for this page: 6403 9366 Long Leg on top. (QTY: 4) Track Splice Door Track Door Slide Insert screws into bottom side only. The Gables will fasten to the Door Track using the holes on the top side. Position Slides as shown.
  • Page 18 Step 5: Floor Assembly 18BB You will need for this page: Assemblies from step 1: 8984 • Floor Frame Assemblies (2) Side Floor (QTY: 8) Frame Do NOT fasten your Floor Frames to your Base at this time. You will anchor your building after it is erected.
  • Page 19 Step 6: Corners 19BB You will need for this page: 6668 (QTY: 8) Corner Panel Use one person to support the Corner while Be cautious when maneuvering another secures the Panels. Do not leave the and placing Panels. Once Panels Corner unsupported until it is secure.
  • Page 20 Step 6: Continued 20BB You will need for this page: 6515 9373 (QTY: 22) (QTY: 4) Wall Panel Wall Panel Attach the Front Wall Panels to the Corner Panels with a screw in the top and bottom of each Panel and a bolt and nut through the middle hole of each Panel. Place screws through all holes along the bottom of the Front Wall Panels, but leave the hole closest to the Ramp open in each Front Panel as shown.
  • Page 21 Step 7: Wall Framing 21BB You will need for this page: Assemblies from Step 2 and Step 4: 6646 • Rear Wall Angle Assembly (1) • Door Track Assembly (1) (QTY: 22) Side Angle Wall Angles must face inside the building. Door Slides should be in Door Track at this time.
  • Page 22 Step 8: Wall Panels 22BB FASTEN TO WALL ANGLES You will need for this page: 6515 (QTY: 20) (QTY: 5) Wall Panel Lift the Panels into place and secure top and bottom of Panels with screws. Be sure to overlap ribs as shown on the FASTEN TO WALL CHANNELS (STEP 10) previous page.
  • Page 23 Step 9: Door Jambs 23BB You will need for this page: 9369 Door Jamb (QTY: 8) (QTY: 4) Secure Door Jambs with two (2) screws in the top and bottom of each Panel as shown. Insert two (2) bolts and nuts into the back side of each Panel as shown below.
  • Page 24 Step 10: Wall Channels 24BB You will need for this page: 9916 9365 Assemblies from Step 2: • Rear Wall Channel Assembly (1) Side Channel Front Chan. (QTY: 34) Install Rear Wall Channel by placing screws through all remaining holes in Wall Panels. Install Side Wall Channels by placing screws through all remaining holes in Wall Panels.
  • Page 25 Step 11: Gables 25BB You will need for this page: 6109 6108 6115 6114 6085 Large Left Large Right Small Left Small Right (QTY: 8) (QTY: 16) Bracket Gable Gable Gable Gable 69835 Green Edge Trim GABLES ARE STACKED TOGETHER (Plastic Piece) DURING SHIPPING...
  • Page 26 Step 11: Continued 26BB You will need for this page: 6636 (QTY: 14) (QTY: 3) Gable Brace Gable must fi t UNDER Side Wall Angle at corner. Working with one Gable at a time, attach the Rear Gables to the Rear Use bolts where Angles overlap.
  • Page 27 Step 11: Continued 27BB You will need for this page: 6636 (QTY: 18) (QTY: 2) Gable Brace Track Sup. Leave two (2) holes open on each side of the Gable peak to attach Track Support. Working with one Gable at a time, attach the front Gables to the Door Track with screws.
  • Page 28 Step 12: Roof Framing 28BB You will need for this page: 6659 Assemblies from Step 3: • Roof Beam Assembly (1) (QTY: 12) Roof Beam Tape should wrap around gap between Gables. Top View of Gables Seal the gap between the Gables using the weather stripping tape as shown.
  • Page 29 Step 12: Continued 29BB You will need for this page: 6227 Beam Brace (QTY: 4) In the front, attach the Roof Beam Brace to the Track Support with one (1) bolt and nut as shown and rotate to align with Roof Beam. Secure to Roof Beam with one (1) bolt and nut as shown.

  • Page 30: Step 13: Roof Assembly

    Step 13: Roof Assembly 30BB You will need for this page: 6532 (QTY: 24) (QTY: 28) Roof Panel If Roof Beam holes do not line up with Roof Panel holes, shift the building from left to right. If this does not help, your building may not be level. Shim the corners until holes line up.
  • Page 31 Step 14: Roof Trim 31BB You will need for this page: 6014 6868 (QTY: 4) (QTY: 12) Side Trim Ridge Cap Trim Cap (L) Trim Cap (R) Peak Cap Install Peak Caps and Ridge Cap using four (4) bolts and nuts as shown. Install Side Roof Trim and Right and Left Corner Caps using four (4) screws as Shown.

  • Page 32: Step 15: Door Assembly

    Step 15: Door Assembly 32BB You will need for this page: 10475 3719 6278 Door Handle Brace Vert. Brace (QTY: 3) (QTY: 2) Handle Do not fully tighten the bolts that hold on the Door Handle until the Vertical Door Brace is in place. Attach the Door Handle and Door Handle Brace to the Door with two (2) bolts and nuts as shown.
  • Page 33 Step 15: Continued 33BB You will need for this page: 10497 Horiz. Brace (QTY: 6) Door Guide Slide Horizontal Brace over Door edge and secure with one (1) bolt and nut in top and bottom. Secure the Door Guides and Lower Horizontal Door Brace as shown below.

  • Page 34: Door Adjustment

    Step 16: Door Install 34BB You will need for this page: Assemblies from Step 16: • Right Door Assembly (1) • Left Door Assembly (1) (QTY: 8) Gable From inside the building, place the bottom Door Slide of the Door into the Front Floor Frame track at about the half-open position.
  • Page 35 ANCHORING OPTIONS... IMPORTANT: • If you have swing doors, they must hang and swing level before anchoring building. • Anchor your building at this time. See below for details on anchoring. • If you have purchased a Floor Frame Kit, you should install it at this time. •...
  • Page 36 CARE & MAINTENANCE... Exterior Care: For a long lasting fi nish, clean and wax the exterior surface. We recommend washing with a mild soap solution. DO NOT use power washing to clean your shed. Using a spray automotive type wax periodically on the exterior is highly recommended if you are in a high humidity or coastal climate region.

  • Page 37: How To Order

    ARROW ACCESSORIES... ROOF STRENGTHENING FLOOR FRAME KITS (heavy snow load) KITS Extra roof beams and gable braces MODELS FB47410, FB5465, designed for added protection against FB106-A, FB109-A and FB1014-A heavy snow accumulation. Increases the strength of your roof. A simple fl oor frame system made of heavy-duty, hot-dipped BEFORE AFTER galvanized steel.

  • Page 38: Assembly Notes

    ASSEMBLY NOTES...
  • Page 39 ASSEMBLY NOTES...
  • Page 40 ASSEMBLY NOTES...
