Start switch<IXE>
INSTRUMENT AND CONTROL FUNCTIONS

Handlebar switches

Left
1
1
2
3
4
2
3
5
ZAUM00**
1. Dimmer switch "%/&"
2. Turn signal switch "4/6"
6
3. Horn switch "*"
7
8
9
EAU12347 Right
1
ZAUM00**
1. Engine stop switch "#/$"
2. Start switch ","
Dimmer switch "&
Set this switch to "&" for the high beam
and to "%" for the low beam.
Turn signal switch "4
To signal a right-hand turn, push this
switch to "6". To signal a left-hand turn,
push this switch to "4". When released,
the switch returns to the center position.
To cancel the turn signal lights, push the
switch in after it has returned to the cen-
ter position.
Horn switch "*
Press this switch to sound the horn.
Engine stop switch "# # # # # /$ $ $ $ $ "
Set this switch to "#" before starting the
engine. Set this switch to "$" to stop
the engine in case of an emergency,
such as when the motorcycle overturns
or when the throttle cable is stuck.
2
Start switch ", , , , , "
Push this switch while applying the front
or rear brake to crank the engine with
the starter. See page 5-1 for starting in-
EAU12400
& & % %
& & /% % % "
structions prior to starting the engine.
EAU12460
4 4 /6 4 6 6 " 6
4 6
3-22 3-4
