Vulcan-Hart VHL2D Specifications

(Shown on optional cabinet base)
SPECIFICATIONS:
Direct steam, Super Steamer, Vulcan-Hart Model No. (VHL2D)
(VHL3D). 6 psi pressure steam cooker. Cooker body is 8
gauge satin finish type 304 stainless steel exterior. Doors have
a removable aluminum alloy inner liner with full perimeter
gasket and sealed by turning a "T" type handle. The door
cannot be opened while the steamer is on. Automatic timed
compartment controls with 60 minute timer (add suffix "S" to
model number). Lift out stainless steel wire Adapt-A-Pan
1
supports eight 2 / ", six 4", or four 6" deep food pans (one for
2
2 compartments)(two for 3 compartments) and one manual
pull out shelf. Cooker mounted on a 2" diameter welded
stainless steel tubing leg stand with 6" adjustable flanged feet,
for floor anchoring. Direct steam supply at 10 to 50 PSI with a
flow of (2 compts., 80 lbs. steam/hr.) (3 compts., 115 lbs.
steam/hr.).
Exterior dimensions:
VHL2D: 36"w x 33"d x 58"h (61"h with cabinet base).
VHL3D: 36"w x 33"d x 66"h (76"h with cabinet base).
U L listed. Classified by U L to NSF Std. #4.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32575 (10-03)
TM
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
VHLD SERIES
SUPER STEAMER, DIRECT STEAM
TWO OR THREE COMPARTMENT MODELS
VHL2D (S) (P) 2 compartments
VHL3D (S) (P) 3 compartments
STANDARD FEATURES
Direct steam supply at 10 to 50 PSI with a flow of (2 compt.
- 80 lbs. steam/hr.) (3 compt. - 115 lbs. steam/hr.)
6 psi pressure steam cooker.
Cooker body is 8 gauge satin finish type 304 stainless steel
exterior. Doors have a removable aluminum alloy inner
liner with full perimeter gasket and sealed by turning a
"T" type handle. The door cannot be opened when steamer
is on.
Automatic timed compartment controls with 60 minute
timer. (Add suffix "S" to model number.)
Lift out stainless steel wire Adapt-A-Pan™ supports eight
2 1 / ", six 4" or four 6" deep food pans (one for 2
2
compartments)(two for 3 compartments) and one manual
pull out shelf.
Cooker mounted on a 2" diameter welded stainless steel
tubing leg stand with 6" adjustable flanged feet for floor
anchoring.
One year limited parts and labor warranty.
OPTIONS
28" high cabinet with stainless steel front full height doors,
slip-off stainless steel side and aluminized rear panel with
6" adjustable legs with flanged feet for anchoring.
TM
Pre-Vent , automatic load compensated timed, combina-
tion pressure and free venting cooking with automatic
exhaust. (Add suffix "P" to model number).
Correction package:
a. Cabinet door with hasp (lock by others).
b. Security type tamper resistant fasteners.
c. Control cover (lock by others).
Control circuit step down transformer to 120V, if higher than
120 volt.
Second year extended limited parts and labor warranty.
ACCESSORIES
Stainless steel back panel.
Manual sliding shelf (Qty. ____).
Removable 12 x x20 sliding shelf (Qty. ____).
Adapt-A-Pan™ support (Qty. ____).
C.S.I. Section 11420
