BMC REACTHEALTH Siesta User Manual

Siesta Full Face Mask
User Manual

Components of the Siesta Full Face Mask

Panel
Cushion
Soft sleeves
Headgear
Components of the Siesta Full Face Mask
Siesta Full Face Mask
Thank you for choosing the Siesta Full Face Mask. The mask is designed to
minimize contact with your face, thus ensuring that you feel comfortable
during therapy. This user manual provides you with the information you need
for the correct use of your mask.
The mask is not made with natural rubber latex.

Intended use

The Siesta Full Face Mask channels airflow non-invasively to the patient from
a positive airway pressure device such as a continuous positive airway
pressure (CPAP) or bi-level system.
The Siesta Full Face Mask is:
•
To be used by adult patients (> 66 lb / 30 kg) for whom positive airway
pressure therapy has been prescribed.
•
Intended for single-patient reuse.
CAUTION: In the US, Federal law restricts this device to sale by or on the
order of a physician.

Before using the mask

WARNINGS

•
The vent holes must be kept clear.
•
This mask should only be used with CPAP or bi-level devices
recommended by a physician or respiratory therapist.
•
The mask should not be used unless the device is turned on. Once the
mask is fitted, ensure the device is blowing air.
•
Explanation of Warning: CPAP systems are intended for use with special
masks with connectors which have vent holes that allow continuous flow
of air out of the mask. When the CPAP machine is on and operating
properly, the fresh air from the CPAP machine flushes the exhaled air out
through the attached mask exhalation port. However, when the CPAP
machine is not operating, the fresh air supplied through the mask is
insufficient, and exhaled air will be re-inhaled. Rebreathing of exhaled air
for more than several minutes may, in some circumstances, lead to
suffocation. This warning applies to most models of CPAP systems.
•
At low CPAP pressures, the flow through the exhaled port may be
inadequate to clear all exhaled gas from the tube. Some rebreathing may
occur.
•
To minimize the risk of vomiting during sleep, the patient should avoid
eating or drinking three hours before using the mask. This mask is not
recommended if the patient is taking a prescription drug that may cause
vomiting.
•
Do not use the mask without the valve in place.
•
Not applicable for silicone-allergy user.
•
This mask should not be used on patients who are uncooperative,
unresponsive, or unable to remove the mask.
•
Follow all precautions when using supplemental oxygen.
Frame
Connector
Elbow
Valve
Clips
Swivel
•
Oxygen flow must be turned off when the PAP Device is not in operation,
so that unused oxygen does not accumulate within the PAP Device
enclosure and create a fire hazard.
•
Oxygen supports combustion. Oxygen must not be used while smoking
or in the presence of an open flame. Only use oxygen in a well-ventilated
room.
•
At a fixed flow rate of supplemental oxygen, the inhaled oxygen
concentration varies depending on the pressure settings, patient
breathing pattern, mask, point of application and leak rate.
•
The technical specifications of the mask are provided for your clinician to
check if it is compatible with the PAP Device. If it is used beyond
Technical Specifications or used with incompatible devices, the seal and
comfort of the mask may not be effective, and optimum therapy may not
be achieved. Leak or variation in the rate of leak, may affect the function
of the PAP device.
•
Stop using the Siesta Full Face Mask and consult your physician or sleep
therapist if you have ANY adverse reaction to the use of the mask.
•
Refer to your PAP Device manual for details on settings and operational
information.
•
Images shown here are indicative only. If there is inconsistency between
the image and actual product, the latter shall govern.

Getting the right cushion size

•
The following drawing describes the different features of the face and the
length of the face (H) you need to measure.
•
The masks are available in three different sizes.
•
Choose the appropriate size according to the table below.
H
Getting the right cushion size

Fitting the mask

Use a standard conical connector if pressure readings and/or supplemental
oxygen are required.
1 2
Pass the upper straps of Place the mask on the
the headgear through the face and extend the
slot of the mask arm as headgear to the back of
shown in the figure and the head. Please confirm
secure it, repeat the that the name on the
process with the lower back of the headgear
straps to join the faces outward when the
headgear clip. headgear is worn.
4 5
Extend the upper straps Repeat the process for
of the headgear as shown the lower-half of the
in the above figure until headgear as shown in the
the mask is fixed above figure until the
properly. mask is fixed properly.

Disassembling the mask

Notes:
•
The elbow assembly cannot be disassembled from the frame assembly.
•
The valve cannot be disassembled. Or it may cause damage, and its
installation would be difficult.
1 2
Undo and remove the
Remove the cushion from
upper-half headgear
the mask frame.
straps out of the slots in
the mask frame.
H (inch) Size
3.15 ≤ H ≤ 3.54 S
3.54 < H ≤ 3.94 M
3.94 < H ≤ 4.53 L
3
Bring the lower-half
straps beneath the ear
and insert the clips into
the fixed hook on the
lower part of the mask
frame.
6
Connect the air tubing
to the swivel. Then turn
on the device and
adjust the mask to the
correct position.
3
Remove the Swivel
from the Elbow.
