BMC REACTHEALTH Siesta User Manual

Siesta Nasal Mask
User Manual
Components of the Mask
Soft sleeves
Frame assembly
Cushion assembly
Headgear
Components of the Siesta Nasal Mask
Siesta Nasal Mask
Thank you for choosing REACT HEALTH's Siesta Nasal Mask.
The Siesta Nasal Mask is designed to minimize contact with your face,
thus ensuring that you feel comfortable during therapy. This user manual
provides you with the information you need for the correct use of your
mask.
The Mask is not made with natural rubber latex.
Intended Use
The Siesta Nasal Mask channels airflow non-invasively to the patient
from a positive airway pressure device such as a continuous positive
airway pressure (CPAP) or bi-level system.
The Siesta Nasal Mask is:
•
To be used by adult patients (> 66 lb / 30 kg) for whom positive
airway pressure therapy has been prescribed.
•
Intended for single-patient reuse.
CAUTION: In the US, Federal law restricts the sale of this device by or
on the order of a physician.
Before Using the Mask
WARNINGS
•
The vent holes must be kept clear.
•
This mask should only be used with CPAP or bi-level devices
recommended by a physician or respiratory therapist.
•
The mask should not be used unless the device is turned on. Once
the mask is fitted, ensure the device is blowing air.
Explanation: CPAP and bi-level devices are intended to be used
with special masks (or connectors) which have vent holes to allow
continuous flow of air out of the mask. When the device is turned on
and functioning properly, new air from the device flushes the
exhaled air out through the mask vent holes. However, when the
device is not operating, insufficient fresh air will be provided through
the mask, and the exhaled air may be rebreathed. Rebreathing of
exhaled air for longer than several minutes can, in some
circumstances, lead to suffocation. This applies to most models of
CPAP or bi-level devices.
•
This mask is made with silicone parts. Please do not use if the
Elbow
Connector
Frame
Short tube
Clips
Swivel
patient is allergic or sensitive to silicone.
•
This mask should not be used on patients who are uncooperative,
unresponsive, or unable to remove the mask.
•
Follow all precautions when using supplemental oxygen.
•
Oxygen flow must be turned off when the CPAP or bi-level device is
not in operation, so that unused oxygen does not accumulate in the
device enclosure and create a fire hazard.
•
Oxygen supports combustion. Oxygen must not be used while
smoking or in the presence of an open flame. Only use oxygen in
well ventilated rooms.
•
At a fixed flow rate of supplemental oxygen, the inhaled oxygen
concentration varies, depending on the pressure settings, patient
breathing pattern, mask, point of application and leak rate.
•
The technical specifications of the mask are provided for your
clinician to check if it is compatible with the flow generator. If it is
used beyond technical specifications or used with incompatible
devices, the seal and comfort of the mask may not be effective, and
optimum therapy may not be achieved. Leak or variation in the rate
of leak, may affect the function of the CPAP or bi-level device.
•
Stop using the Siesta Nasal Mask and consult your physician or
sleep therapist, if you have ANY adverse reaction to the use of the
mask.
•
Refer to your CPAP or bi-level device manual for details on settings
and operational information.
•
Remove all packaging before using the mask.
•
Images shown here are indicative only. If there is inconsistency
between the image and actual product, the actual product shall
govern.
Fitting the Mask
1 2
Attach the headgear Hold the mask over your
straps by threading them nose and pull the
through the slots in headgear over your head.
forehead frame and clips.
4 5
Adjust the upper headgear Adjust the lower headgear
straps evenly until they are straps evenly until they are
comfortable and secure, comfortable and secure,
and reattach the mask. and reattach the mask.
Disassembling the Mask
1 2
Undo and remove the Remove the Cushion
upper headgear straps out assembly from the Frame
of the slots in the Frame. assembly.
Cleaning the Mask
Notes:
•
The mask and headgear can only be cleaned by washing by hand.
•
The headgear may be washed without removing the clips.
•
When washing the mask, the Elbow and the Frame cannot be
disassembled from the Frame assembly.
CAUTIONS
•
Always follow cleaning instructions and do not use solutions
containing bleach, chlorine, alcohol,
antibacterial agents, or scented oils to clean any part of the system or
air tubing, otherwise may damage the mask.
•
Exposing any part of the system or tubing to direct sunlight or heat
may cause deterioration.
•
If any visible deterioration of a component is apparent (cracking,
crazing, tears, etc.), the component should be discarded and replaced.
3
Bringing the lower
headgear straps below
your ears, connect the
clips to the Frame
assembly.
6
Mask is worn as shown.
3
Remove the Short
tube from the Frame
assembly.
aromatics, moisturizers,
