EEI-3575 TABLE

Thank you for purchasing the MODWAY Table.

Before you start, here are some helpful advice:

1. We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step

instructions.

2. Owing to the size and weight of the Table, we recommend that it is assembled by two adults, on a carpeted

or padded area, in the room that it is intended for. Approximate assembly time: 30 minutes.

3. Please do not use any tools other than those provided or recommended in these instructions.

4. Please do not throw away any of the packaging or the instruction until you have checked all the components

and hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe

and environmentally friendly way.

5. Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten

the components from time to time, so please save the tools that have been provided.

6. Please keep all pieces out of reach of children.

Components:

1. Frame

Customer Service 609-256-9000︱www.modway.com

Hardware:

2. Support

3. Base

Long Bolt M10*1010mm x1

Nut M10

Flat Washer M10

Spring Washer M10

Glass Top

Short Bolt M4*4mm

Allen Wrench M4

4. Top Panel

Page 1 of 4

Need help?

Do you have a question about the Raleigh EEI-3575 and is the answer not in the manual?

Page 1 EEI-3575 TABLE Thank you for purchasing the MODWAY Table. Before you start, here are some helpful advice: 1. We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions. 2. Owing to the size and weight of the Table, we recommend that it is assembled by two adults, on a carpeted or padded area, in the room that it is intended for.
Page 2 2. Insert the Long Bolt (A) with fixed Nut into the pre-drilled holes on the Frame (1) as shown. 3. Tighten Long Bolts (A) clockwise until secure by hand. STEP 2: Insert the Support (2) into the Frame (1) through Long Bolt (A) as shown by hand. Customer Service 609-256-9000︱www.modway.com Page 2 of 4...
Page 3 1 piece of Bolt (F) to the hole and use Allen Wrench (G) to tighten Bolt (F) as shown. Don’t tight Bolt (F) fully. 3. When Support (2) and Base (3) are fixed, please fully tighten Nut (B) and all Bolts (F ). Customer Service 609-256-9000︱www.modway.com Page 3 of 4...
Page 4 2. Carefully put Top Panel (4) on the Frame (1) as shown. Make sure the Top Panel (4) fits the Frame (1). Attention: If the Table is not stable, you may adjust it by alignment pin. Assembly is complete. Your Table is ready to enjoy now! Customer Service 609-256-9000︱www.modway.com Page 4 of 4...
