Summary of Contents for LDA Audio Tech NEO8060
- Page 1 Front microSD card formatting How to format the microSD card in NEO8060's front panel Ref: D-0015449-EN-r02 Support handbook...
- Page 2 Front microSD card formatting 1. Description This handbook describes a possible solution for issues related to the NEO8060's front microSD memory card, because the PA and evacuation messages are stored in it. WARNING: After formatting the front SD, it is recommended to do a device reset to prevent possible ghost files.
- Page 3 Select the device and click “Import system”, then close the “Search devices” window. In the left column below the deployable item “Controllers”, click in NEO8060. Click over “Advanced” tab in the central column, as is shown in the picture below. Then you...
- Page 4 Front microSD card formatting 3. Formatting front SD card using NEOApp This option will be only available to authorized users upon request of access password. Please contact with support@lda-audiotech.com. Once access to the software is completed, press “System -> LDA Discover Tool” to search for the needed device in the network.
- Page 5 Front microSD card formatting The IP address can be typed down directly in the “Connection” section. Once the device is online, go to “Files/Firmware”.
- Page 6 Front microSD card formatting In the "Front SD card" section, click on the "Format SD" button. The following warning message will appear. Click "Aceptar". After formatting the front card, the following errors will occur: • ERROR_EVAC_MESSAGE_FAILURE • ERROR_ALERT_MESSAGE_FAILURE Reload the messages again to finish. You can use the manual available in the description of this document for help.
