- Page 1 User Manual EN54-16 and EN54-4 Voice Alarm and Public Address Certified System LDA ONE...
-
Page 3: Table Of Contents
Table of contents 1 INTRODUCTION.........................6 1.1 System characteristics....................6 1.2 System diagram ......................7 1.3 HW and FW versions....................8 1.4 User interface description.................... 8 1.4.1 Light indicators....................8 1.4.2 Alphanumeric display ..................9 1.4.3 Controls......................9 1.5 User profiles. Access level. Passwords ..............10 2 INSTALLATION INSTRUCTIONS .................. - Page 4 3.5 Multi-device distributed systems................30 3.5.1 Introduction..................... 30 3.5.2 Individual configuration of each unit............... 31 3.5.3 System setup - Discover operation..............31 3.5.4 Distributed system operation................31 3.6 Advanced configuration..................... 32 3.6.1 Advanced configuration variables..............32 3.6.2 Blocking PA sources in battery and emergency..........33 3.6.3 Equalizers.......................
- Page 5 SAFETY INSTRUCTIONS Please, read carefully these safety instructions. 1. Retain this User Manual for future reference. 2. The device must be connected to a bipolar mains switch according to the Low Voltage Directive, and must be easily accessible for disconnection. 3.
-
Page 6: Introduction
Each ONE unit consists of an EN54-16 system capable of controlling a maximum of 6 zones and delivering a maximum total power of 500W. In addition, it is possible to create larger systems by linking several ONE units, allowing the control of up to 60 zones with an overall power of up to 5000W. -
Page 7: System Diagram
ACSI bus and its devices. Optionally, a system can be made up of more than one unit. In this case, the first unit must have a redundant system link card (ONE-LOOP) installed in its expansion bay. For more information on the connection of these types of systems and their configuration, see respectively section 2.2.11 and section 3.5. -
Page 8: Hw And Fw Versions
1.3 HW and FW versions For the operation of the expanded ONE system, ONE devices must have a serial number over 20xxxxxx and have their firmware updated to version v02.00.01.00 or higher. You can check for firmware updates on the LDA support website. -
Page 9: Alphanumeric Display
a) PWR: “POWER” / “ENERGÍA”. Green On: when the device is powered from any of the possible power sources. b) EMG: “EMERGENCY” / “EMERGENCIA”. Red On: when the system is in an emergency operating status (voice alarm), either by manual or automatic activation from the CIE (Control and Indicating Equipment) from any of the available emergency inputs. -
Page 10: User Profiles. Access Level. Passwords
BCK: • Menu navigation: go up one level / go back. If pressed for 3 seconds, the unit will return to the initial screen and restart the access level (log-out). •... -
Page 11: Installation Instructions
8 screws located in the outer corners of the unit. For each pair of screws, remove the one closer to the front, where the support will be placed. Insert the clamping wings into the corresponding perforations, and place the screws that will fix the unit preventing it from falling. -
Page 12: Battery Installation
b) Disconnection switches These switches cut the power path of the mains and the battery. These switches help to avoid the danger of sparks when connecting the battery, and they can serve to restart the device completely. 2.2.2 Battery installation Before installing the battery, cut off the mains main power. -
Page 13: Fire Panel Interface
2.2.3 Fire Panel Interface The emergency activation interface is advised for interfacing with fire control and indicating equipment (ECI/CIE). All input connections are supervised for faults in the transmission line. This interface is made up of four sections. The connection is made using female euroblock connectors, supplied with the device. →... -
Page 14: Speaker Line Outputs
played. Disactivating the closure will stop message playback, and a reset operation will be required to return to idle or PA mode. c) Status outputs. EMG and FLT status outputs Dry contacts intended for connection to fire panels or other external monitoring devices. They will indicate if the device is in emergency or fault respectively when they are closed. -
Page 15: Audio Source Inputs
LDA support website. a) Backup amplifier: ONE has two amplifiers and an amplification output matrix system, each of the 6 ONE outputs can have 3 different sources: amplifier 1 (audio 1), amplifier 2 (audio 2) and mute (without audio). -
Page 16: Acsi Devices And Microphones Input
Figure 13: ACSI-IN port connected devices. In expanded systems, with several ONE units, this input will change its functionality in the device(s) that does not occupy the first position, becoming a connection between the different ONE devices. This mode of operation is discussed in detail in section 2.2.11. -
Page 17: System Expansion Output. Link-Out
2.2.7 System expansion output. LINK-OUT The LINK-OUT port provides the necessary interface for system expansion among various devices. This connection embeds serial communications bus for control data and 2 audio channels for the distribution of the global system sources, generated by the system main unit;... -
Page 18: Internal Connections
(LOOP) from the last computer on the network to the first one. The number of units that can be grouped in the same system will be limited by the ONE- LOOP card model installed, and they can reach a maximum of 10 devices. - Page 19 This will be the case between all the units except the last one, where the connection will be made from its LINK-OUT port to the LOOP port that provides the expansion card of the first unit.
-
Page 20: Configuration And Startup
3.2 Automatic Configuration. <Run Autosetup> The automatic setup feature saves much of the setup work of setting up an ONE system. Any configuration can be edited later manually. It is launched by pressing the OK →... -
Page 21: Advanced Mode Selection
3.2.3 Advanced mode selection By activating the advanced mode, the user will be asked if he wants to configure the speaker line outputs in A + B mode. The following sections explain the process that the unit will perform automatically. a) Speaker lines and zones. -
Page 22: Manual Configuration.
e) Backup amplifier The backup amplifier and the supervision of amplifiers are automatically activated. The unit will flag a fault if any of them stops working at any time, or if it does not offer the appropriate level of gain. f) Setup Report At the end of the process, the number of detected zones and lines and the number of installed ACSI devices are displayed on the screen. -
Page 23: Audio Outputs.
b) Input 3. Input 3 Input intended for background music. The menu includes the same functions as sources 1 and 2, except for the parameters that configure the activation mode (“Trigger Mode” submenu). c) Mixer input, Input 4 - MIX. The mixer is a tool allowing you to work with priority sources, such as microphones, without cutting the background music. -
Page 24: Speaker Lines Configuration.
c) VA Rec-Out: This control allows activating the “recording output” or “rec-out” mode. When active, pre-out output 4 will no longer be linked to a zone and will instead play live voice messages broadcast to the evacuating zones. (Ex: Manual messages in VAP-1 panels) 3.3.3 Speaker Lines configuration. -
Page 25: Import And Edit Messages.
NOTA: This parameter will be locked when the device belongs to a distributed system with more than one ONE device. To edit it, you must previously unlink the device fro m the system (see section 3.5). 3.3.5 Import and edit messages. -
Page 26: Pa/Va Microphones. Acsi Devices
• Monitor: It shows complete information for each bus address, indicating the device that is currently connected, the one that is installed and the status • Install: It allows you to install the ACSI devices for its supervision, choosing in each address of the bus which model we want to install. -
Page 27: Interface With The Fire Panel.
• MICs Config: Custom settings for installed microphones: ◦ Vumeter: It indicates the signal level of the ACSI input. (only take into account when the device is active) ◦ Volume: Input level adjustment tuner from -100 to + 12dB of each installed device. -
Page 28: Save And Charge Configuration.
40% above the value measured with the new and charged battery to ensure its autonomy. Ex: 50 mOhms for YUASA NP17-12I battery. a) Battery charger operation and monitoring. ONE-BC The monitor menu is available to assist the user in diagnosing the battery status. •... -
Page 29: Device Configuration.
• Run Discover: It executes the Discover operation that will constitute a new distributed system of several ONE units. This operation will only be allowed if the device launching this operation has a ONE-LOOP card installed. For more details, consult section 3.5. -
Page 30: User Management
◦ Loopback FLT: It establishes the supervision of the return link (from the last unit to the first one in the network). If this option is disabled, the system will stop monitoring this link, and it will not flag a fault if it is not operating. -
Page 31: Individual Configuration Of Each Unit
3.5.2 Individual configuration of each unit The system will be constituted as the grouping of each one of the units that compose it. These units must be previously configured separately, as if they were independent systems by themselves. The individual configuration of each unit can be achieved in two ways, the simplest will be by running the autosetup process where the unit will detect the connected lines, battery, etc. -
Page 32: Advanced Configuration
This also affects the RESET operation, which will reset the emergency status of the entire system (and units and zones members), executed from any of the ONE units; •... -
Page 33: Blocking Pa Sources In Battery And Emergency
There are two special statuses: battery powered unit operation or system emergency status. Upon entering one of these two statuses, the unit will review the routing of all its zones, blocking the use of sources that are not enabled. -
Page 34: Equalizers
3.6.3 Equalizers Adjusting the equalizers for each input and output consists in a common operation that is detailed as follows. Each band is a second order peaking filter. • Eq Enable: To enable or disable (bypass) the equalizer. • Eq Settings: ◦... -
Page 35: System Use
4 SYSTEM USE 4.1 Main screen. The home screen will display, at all times, important information as specified in the EN54 standard. The message PA/VA System <ready> will be displayed by default, but this message could change to <FAULT> or <EMERGENCY> depending on the current unit status. -
Page 36: Va System Monitor.
This screen condenses the information about the entire system, zone by zone, indicating faults and emergency status of each one of them. The external zones of distributed systems of several units will be as well shown here (see section 3.5), allowing navigation between all of them with left and right cursors. -
Page 37: Volume Settings.
4.3.1 Volume Settings. <Volume> It is possible to adjust the overall (master) volume and the input volume. The input adjustment range is -100dB to + 12dB. The overall volume can be bet ween -100dB and 0dB. The overall volume can also be adjusted directly from the main screen, using the up and down buttons. -
Page 38: Va System Monitor.
• Lower line: Up and down keys change the visible information between these options: ◦ Event description. ◦ Status: (only for the fault LOG) It indicates whether it is active or has been resolved. ◦ Date when the fault occurred. ◦... -
Page 39: Test
(“location” field). b) System General system information, whether it is a distributed system with more than one device or a single device. Here the “system UID” (unique identifier of the system) will be shown, as well as the number of zones and devices that make it up. In addition, a “Device Monitor”... -
Page 40: Maintenance Instructions
The system detects it thanks to a switch that is activated with one of the closing screws. The text “Open cover detected” will be displayed in the entry of the fault log. -
Page 41: Transmission Line With Cie
5.1.6 Link Each ONE device will supervise its connection with the rest of the devices in the system, for example ACSI devices that have been installed or other ONE devices in a distributed system. In the event of a link fault (LINK), the power supply of the failed units must be checked, as well as the status of the wiring of these connections. -
Page 42: Technical Specifications
6 TECHNICAL SPECIFICATIONS Model ONE-500 Power supply 100 - 240V~ 50/60Hz with integrated PFC Absorption 320W max - 100W at 1/8 output power - 40W AC standby Frequency response 80 – 20,000Hz +/-1dB Signal/Noise ratio SNR <90dB, A weighting (Main Amplifier) Distortion <1% following IEC 60268 -15dB. -
Page 43: En54-16 Functions
6.1 EN54-16 functions ONE system controller implements all the mandatory functions complying with the EN54-16:2008 standard. It also includes the following optional certified functionalities: 1. Audible advice 2. Phased evacuation 3. Manual mute of voice-activated alarm condition 4. Manual reset of voice-activated alarm condition 5. - Page 44 QUICK INSTALLATION GUIDE 1.- Open the lid. Remove the 5 marked screws: 2.- With the help of a flat screwdriver remove the necessary cable glands depending on the amount of cables to install. 3.- Make the connections inside: - Speaker lines: (Follow the order from 1 to 6 without leaving gaps, otherwise they will not be detected by the autosetup function) - Install the battery charger card and battery.
