PT4500W-TRIPOD-TK
15" Widescreen Teleprompter, Tripod & Dolly Turnkey w/ Travel Case
OVERVIEW
Ikan's Turnkey Broadcast Solutions include everything you need for your professional camera setup. This solution includes a 15" widescreen
teleprompter, tripod, and dolly. All of our systems have been tested internally for payload compatibility.
The remaining payload capacity, after mounting the full 15" teleprompter system without the counterweight, can accommodate camera setups
up to 25.2 lbs. The tripod, without the teleprompter system, can accommodate cameras up to 44.1 lbs. This solution also includes a carrying
bag for the tripod.
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com
Quick Start Guide
What's Included
1 x GA102 Tripod Legs
1 x T30 Carrying Bag
1 x EI-7004B Dolly w/ Wheels & Cable Guards
1 x GH20 Fluid Head
2 x Pan Handles
1 x Base Plate
1 x Bottom Plate
1 x Base
1 x Glass Frame Holder Bracket
1 x 15 in. 70/30 Teleprompter Glass
1 x Hood Attachment Frame
1 x Teleprompter Hood Boot
1 x Silicone Teleprompter Hood
1 x Glass Holder
2 x 15mm Rod Clamps
2 x 15mm Rods
1 x Large Riser Camera Mount
2 x 3/8-16 D-Ring Screws
1 x Counterweight
1 x Large Riser
1 x DSLR/Mirrorless Riser
1 x Medium Riser
1 x Short Riser Plate
1 x SDI 15 in. Widescreen Teleprompter Monitor
1 x AC Adapter with Cord
1 x Teleprompter Glass
1 x PrompterPro Software (FREE with this teleprompter)
1 x Rolling Hard Case for Teleprompter System
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ikan PT4500W-TRIPOD-TK
Summary of Contents for Ikan PT4500W-TRIPOD-TK
- Page 1 1 x Rolling Hard Case for Teleprompter System OVERVIEW Ikan’s Turnkey Broadcast Solutions include everything you need for your professional camera setup. This solution includes a 15” widescreen teleprompter, tripod, and dolly. All of our systems have been tested internally for payload compatibility.
- Page 2 PT4500W-TRIPOD-TK 15” High Bright Beam Splitter Teleprompter Teleprompter Assmebly Setup Step 1 Step 2 Place the teleprompter glass frame on a flat surface and remove the four Align and attach the teleprompter hood with the 8 screw pegs from the screws as shown.
- Page 3 Step 3 Step 4 The metal frame is directional. Make sure the thicker side is on top and Put the washers on before tightening the screws. The washers and 4 the slimmer side is on the bottom. additional screws are inside a bag on the bottom foam. Step 5 Step 6 Extend the teleprompter hood open and attach teleprompter boot...
- Page 4 Step 7 Attach the monitor mounts on the back of the monitor’s VESA compatible threads using the 4 included screws and provided 2mm hex key. Step 8 After the monitor mounts are attached, adjust the 15mm rods to accommodate the monitor. Leave about 1 inch of room for the teleprompter bracket. Make sure the 15mm rods go through both set of monitor mounts.
- Page 5 Foam Case To make your teleprompter more portable, we packed it in a reusable, high-quality foam. The shape and size of the foam was designed to fit into Ikan’s PT-CASE-V2. ** DO NOT THROW AWAY FOAM CASE ** www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
-
Page 6: Monitor Ports
Monitor Ports Monitor Menu Settings Video Config Contrast (White Level) Brightness (Black Level) Tint (Chroma Hue) Chroma (Chroma Saturation) Sharpness (Detail) RGB Setup – Manually configure RGB Return System Config Menu Duration – Set duration of how long menu stays on screen Video Ratio –... -
Page 7: Specifications
TALLY – RJ45 Ethernet Port TALLY SWITCH – Switch between two Tally locations Specifications PT4500W Watch our VIDEO TUTORIAL on how to assemble Ikan Professional Telepromopters: Aspect Ratio 16:9 https://youtu.be/5TjIxzBc_Vc Maximum Brightness 1000 cd/m2 Screen Size (Diagonal) 15 in. Mount... -
Page 8: Learn More
Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company. • Damage caused by natural disaster, abnormal voltage, and environmental factors, etc. ©2022 Ikan International. All rights reserved. www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
