PT4500-TMW
High Bright 15" Tally Teleprompter w/ 15" Widescreen SDI Talent Monitor
What's Included
1x
Teleprompter Base
1x
Hood Frame
1x
Silicone Hood w/ Canvas Shroud
1x
Counterweight
1x
Tall Riser
1x
Medium Riser
1x
DSLR Riser
2x
L-Shaped Hex Keys
2x
1/4-20 Camera Screws
1x
15 in. 4:3 Monitor
1x
15 in. SDI 16:9 Widescreen Monitor
1x
Power Adapter
1x
70/30 15 in. Glass
1x
Digital Copy of Prompter Pro4
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com
Quick Start Guide
Advertisement
Related Manuals for Ikan PT4500-TMW
Summary of Contents for Ikan PT4500-TMW
- Page 1 Quick Start Guide PT4500-TMW High Bright 15" Tally Teleprompter w/ 15" Widescreen SDI Talent Monitor What’s Included Teleprompter Base Hood Frame Silicone Hood w/ Canvas Shroud Counterweight Tall Riser Medium Riser DSLR Riser L-Shaped Hex Keys 1/4-20 Camera Screws 15 in. 4:3 Monitor 15 in.
- Page 2 Teleprompter Assembly Setup Step 1 Step 2 Place the teleprompter glass frame on a flat surface and remove the four Align and attach the teleprompter hood with the 8 screw pegs from the screws as shown. teleprompter frame. Step 3 Step 4 The metal frame is directional.
- Page 3 Step 5 Extendthe teleprompter hood open and attach teleprompter boot using the clips. It is suggested to align the seam with the bottom of the teleprompter hood. Step 6 Removethe monitor mounts from the teleprompter base using the included larger 4mm hex key to loosen from the 15mm rods. www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
- Page 4 Step 7 Attach the monitor mounts on the back of the monitor’s VESA compatible threads using the 4 included screws and provided 2mm hex key. Step 8 After the monitor mounts are attached, adjust the 15mm rods to accommodate the monitor. Leave about 1 inch of room for the teleprompter bracket. Make sure the 15mm rods go through both set of monitor mounts.
- Page 5 Foam Case To make your teleprompter more portable, we packed it in a reusable, high-quality foam. The shape and size of the foam was designed to fit into Ikan’s PT-CASE-V2. ** DO NOT THROW AWAY FOAM CASE** www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
-
Page 6: Monitor Ports
Monitor Ports Monitor Menu Settings Video Config Contrast (White Level) Brightness (Black Level) Tint (Chroma Hue) Chroma (Chroma Saturation) Sharpness (Detail) RGBSetup – Manually configure RGB Return System Config Menu Duration – Set duration of how long menu stays on screen Video Ratio –... -
Page 7: Optional Accessories
Watch our VIDEO TUTORIAL on how to assemble Ikan Professional Teleprompters ikancorp.com/15-in-videos/ Specifications 15 in. Teleprompter 15 in. Teleprompter Monitor 15 in. Widescreen Talent Monitor Medium: 3.74 in.| High: 5.31 in./ | DSLR: 6.29 Riser Plate Height Aspect Ratio Aspect Ratio 16:9 in./160mm... -
Page 8: Learn More
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company. • Damage caused by natural disaster, abnormal voltage, and environmental factors, etc. ©2024 Ikan International.All rights reserved. www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com... - Page 9 R: Connects the red tally light G: Connects the green tally light Y: Connects the yellow tally light NC: Stands for"Not Connected"Disregard these pins. Learn More More dynamic information at official website :www.ikancorp.com Support Contact email: support@ikancorp.com ©2024 Ikan International.All rights reserved. www.ikancorp.com|1.713.272.8822|sales@ikancorp.com...
