NXP Semiconductors DEMO9S08LC60 Quick Start Manual

DEMO9S08LC60

0. Introduction

This quick start guide will walk you through setting up your demo board, connecting it to the PC, and launching
the provided example. For more information, please read the demo board's user's manual.
Note: the MC9S08LC60 datasheet is available for download at www.freescale.com.
i

1. Run the Factory Programmed Example (Standalone Mode)

1. Ensure that both the "CLK ENA" jumpers are inserted.
2. Ensure that all of the "IO1" and "IO2" jumpers are inserted.
3. Ensure that all of the "LED ENA" jumpers are inserted.
4. Ensure that both the "g-Sel1" and "g-Sel2" jumpers select the "0" position.
5. Ensure that the "Sleep Mode# SEL" jumper selects the "1" position.
6. Ensure that the "POWER SEL" jumper selects the "USB" position.
7. Power on the board via a USB cable. Alternatively, you can power the Demonstration Board through a 12 V
DC plug-in power supply (not included in the kit). In this case, the "POWER SEL" jumper must select the
"UNREG" position.
8. The green "POWER" LED on the board should turn on.
9. Rotate the potentiometer. Its value will be shown on the display.

2. Host Mode

The same example above can be run from the host PC. To do this, the CodeWarrior Development Tools and the
SofTec Microsystems Additional Components must be installed first.

Install CodeWarrior Development Studio

To install the CodeWarrior Development Studio Special Edition, insert the CodeWarrior CD-ROM into your
computer's CD-ROM drive. A startup window will automatically appear. Follow the on-screen instructions.

Install SofTec Microsystems Additional Components

The SofTec Microsystems Additional Components install all of the other required components to your hard drive.
These components include:
The Demonstration Board's USB driver;
The software plug-in for CodeWarrior;
Examples;
Demonstration Board's user's manual;
Demonstration Board's schematic;
Additional documentation.
To install the SofTec Microsystems Additional Components, insert the SofTec Microsystems "System Software"
CD-ROM into your computer's CD-ROM drive. A startup window will automatically appear. Choose "Install
Quick Start Guide
Rev. 1.0
