Summary of Contents for NXP Semiconductors DEVKIT-S12G128
- Page 1 DEVKIT-S12G128 QUICK START GUIDE (QSG) ULTRA-RELIABLE MCU INDUSTRIAL AND AUTOMOTIVE EXTERNAL USE...
- Page 2 Get to know the DEVKIT-S12G128 The DEVKIT-S12G128 is an ultra-low-cost development platform for S12 Microcontrollers. Features include easy access to all MCU I/O´s, a standard- based form factor compatible with the Arduino™ pin layout, providing a broad range of expansion...
- Page 3 Power Supply and Communications DESCRIPTION NAME VBAT J9-01 J9-02 J9-03 DESCRIPTION NAME J12-01 VBAT J12-02 J12-03 J12-04 DESCRIPTION NAME CANH J8-01 CANL J8-02 VBAT J8-03 J8-04 High-speed CAN interface EXTERNAL USE...
-
Page 4: Input/Output Connectors
J2-11 SPI_SCK2 J2-12 J2-13 J2-14 GPIO J2-15 AREF AREF J2-16 GPIO J2-17 GPIO J2-18 GPIO J2-19 GPIO J2-20 GPIO Arduino Compatibility The internal rows of the I/O headers on the DEVKIT-S12G128 are arranged to fulfill Arduino™ shields compatibility EXTERNAL USE... - Page 5 GPIO J4-09 PAD4 ADC4 J4-12 GPIO J4-11 PAD5 ADC5 J4-14 GPIO J4-13 PAD6 ADC6 J4-16 GPIO J4-15 PAD7 ADC7 Arduino Compatibility The internal rows of the I/O headers on the DEVKIT-S12G128 are arranged to fulfill Arduino™ shields compatibility EXTERNAL USE...
- Page 6 LINTX J6-12 J6-09 LINRX J6-10 J6-07 J6-08 CANRX J6-05 J6-06 CANTX J6-03 SPI_MOSI J6-04 SPI_CS Arduino Compatibility The internal rows of the I/O headers on J6-01 SPI_SCK J6-02 SPI_MISO the DEVKIT-S12G128 are arranged to fulfill Arduino™ shields compatibility EXTERNAL USE...
- Page 7 Default jumpers POSITION DESCRIPTION OPEN Enable LIN Master mode 1 - 2 VDD Power MCU linked to 3.3V 2 – 3 VDD Power MCU linked to 5.0V [DEFAULT] 2 - JP1 VDD Power MCU linked to USB 1 - 2 P5V0 reference is linked to P5V_SWUSB 2 –...
- Page 8 Programming interface and User Peripherals MICRO USB [J16] User – Push Button REFERENCE DESCRIPTION [SW3] PORT RESET [SW2] Potentiometer Rotary Potentiometer User – Push Button Push PWRSBC [SW4] Potentiometer [R44] Button RESET RGB LED [D9] PWRSBC GREEN LED power Indicator RESET RESET LED indicator BDM [J7]...
- Page 9 Connect the USB Cable Connect one end of the USB cable to the PC and the other end to the mini-B connector on the DEVKIT-S12G128 board. Allow the PC to automatically configure the USB drivers if needed. Using the Example Project The pre-loaded example project utilizes the RGB LED.
-
Page 10: Cautionary Notes
EMC Information on the DEVKIT-S12G128 board: • This product as shipped from the factory with associated power supplies and cables, has been verified to meet with requirements of CE and the FCC as a CLASS A product. - Page 11 Documentation and References Datasheet MC9S12GRMV1, MC9S12G Family Reference Manual and Data Sheet (REV 1.25) Application Notes AN4455, MC9S12G128/A240 Demonstration Lab Training - Application Notes (REV 0) Reference Manuals DRM134, DRM for Driver Information System on S12G128 - Reference Manual (REV 0) For more information please visit : www.nxp.com/s12g EXTERNAL USE...
- Page 12 Development Tools Ecosystem Compilers • Codewarrior S12 • Cosmic • Codewarrior • Cosmic Zap Programmers • P&E • Cyclone Pro Programmer Debugger • CW & P&E S12 Debugger • Cosmic Zap Debugger • iSYSTEM winIDEA Support Tools: • FREEMASTER run time debugger and for instrumentation/calibration EXTERNAL USE...
- Page 14 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: DEVKIT-S12G128...
