Vizualogic HindSight Chevy Avalanche Installation Manual

Chevy avalanche–2002-2004 chevy/gmc full-size pickup–1999-2004 chevy/gmc suburban/tahoe–2000-2004 gmc sierra–1999-2004 gmc yukon–2000-2004
Hide thumbs

Advertisement

Quick Links

Monitor Installation

1. Locate the driver's side or passenger side
visor-clip mount. (Fig. 2)
2. Route the Monitor Cable from the headliner
to the A/V Control Module via the A-pillar.
3. Insert the Monitor Cable into the opening
on the back-side of the Monitor Housing.
4. Connect the Monitor Cable to the LCD Monitor.
5. Screw the LCD Monitor onto the Monitor
Housing using the (2) provided screws.
6. Loosen the visor-clip mount screw.
7. Secure the (2) Monitor Housing rear-hooks to the headliner.
(Fig. 3)
8. Secure the (1) Monitor Housing front-hook to the visor-clip mount.
(Fig. 4 & 5)
Fig. 3
Backup Monitor System
Copyright © 2003 TMI Products, Inc.
All Rights Reserved
Corona, CA U.S.A.
1493 Bentley Drive • Corona, CA 92879 • 909-272-1996 • 800-624-7960 • Fax 909-272-1584
www.vizualogic.com
Fig. 2
Fig. 4
Fig. 5
060300
99-8019-001
Backup Monitor System
LCD Monitor &
CCD Color Camera
Chevy Avalanche–2002-2004
Chevy/GMC Full-size Pickup–1999-2004
Chevy/GMC Suburban/Tahoe–2000-2004
GMC Yukon–2000-2004
Installation Manual
10/03
GM Models
GMC Sierra–1999-2004
Fall 2003
