- Page 1 SANWAY AUDIO http://www.china-sanway.com http://www.china-sanway.com Contents ...
-
Page 2: Important Note
SANWAY AUDIO http://www.china-sanway.com http://www.china-sanway.com Important Note WARNING NOTICES SAFEGUARDS Electrical energy can perform many useful funtions, This unit has been engineered and manufactured to assure your personal safety. Imporoper use can result in potential electrical shock or fire hazards. In order not to defeat the safeguards, observe the following precautions for its installation, use and servicing. -
Page 3: Control Elements
SANWAY AUDIO http://www.china-sanway.com http://www.china-sanway.com Control elements ... - Page 4 SANWAY AUDIO http://www.china-sanway.com http://www.china-sanway.com Rear panel features introduction 2 channel version DIP switches XLR connectors for 4channel version Mains input 200V- 240V shown with Neutrik for adjusting key inputs and loop thru shown with Neutrik or 1 00V- 120V Speakon output features Speakon output operation...
- Page 5 SANWAY AUDIO http://www.china-sanway.com http://www.china-sanway.com Rear panel features introduction ． ...
-
Page 6: Audio Input And Output Connections
SANWAY AUDIO http://www.china-sanway.com http://www.china-sanway.com Audio input and output connections BALANCED INPUT CONNECTIONS The XLR input connectors are electronically balanced, and wired according to the IEC 268 standard ( pin 2= hot ). XLR input connectors should be wired follows: Pin 1 Ground/Shield Pin 2 Hot (+) Audio input-4-channel models Pin 3 Cold (-) -
Page 7: Output Mode
