Sanway Audio DA2504D Manual

Contents Specification
Contents Specification... ......... . .. .. .. . .. . . .. .. .. . 1
Important note. ............. .... . .. .. .. . . . .. .. .. . .. . 2
Control elements........ ....... .. .. .. .. . . . .. .. .. . . .. 3
Rear panel features introduction.... . . . .. .. . .. . . .. .. . .. 4
Rear panel features introduction... . . . .. .. .. . . . .. .. .. . . 5
Audio input and output connections. . . .. . .. .. . . .. . .. .. . 6
PC Interface.... .. .. ... .. ...... . .. . .. .. . .. . .. .. . .. . 7
PC Interface Network application. ... . .. .. . . . .. .. .. . .. . 8
DSP
MODEL:
Input:
Output:
PC Com Port:
Processor:
Dynamic range:
Frequency Response:
Distortion:
Signal to noise ratio:
crossover filter:
EQ:
Delay:
Display:
Store Settings:
AMPLIFIER
Model
Output Power
Ω
8 Stereo Power
Ω
4 Stereo Power
Ω
8 Bridged Monon Power
Frequenty Response
Ω
THD+N(Rated power,4 /KHz)%
Signal Noise Ration(dB)
Input Impedance
Output Connectors
Power Requirement
Dimension
Airframe
Weight
Weight(net)
Weight(gross)
SPECIFICATION
DA2504D
4 channel
4 channel
1 USB Com Port on front panel, 1 USB Com Port,2 RS485 Com Port on back panel (RJ-45)
48KHz Sampling frequency, 48-bit Fixed-Point DSP, 24-bit A/D and D/A converter
>110dB
±0.25dB, 20Hz --- 20KHz
< 0.01%, 20Hz - 20KHz @ +10dBu balanced input
>110dB
Each output channel can be independently set as LPF and HPF, The parameters can be adjusted,
Filter type:Butterworth, Bessel, Linkwitz-Riley; The Crossover Frequency:20Hz---20KHz,
Slope:12,18,24 or 48 dB/octave
Bandwidth:0.2 to 36 oct, Frequency:20 Hz to 20KHz, Gain: -24dB to +12dB, step:0.2 dB
0ms to 115ms
2 x 20 LCD
20 user program dynamic storage
Ω
20K
Speakon Connectors(NEUTRIK)
100-120V-50-60Hz or 200-240V-50-60Hz
DA2504D
4×250W
4×450W
2×800W
20Hz-20kHz ±0.5dB
0.10%
110dB
Ω
Balanced / 10k Unbalanced
483×44×325mm
5.7KG
7.2KG
