SANWAY AUDIO http://www.china-sanway.com http://www.china-sanway.com Important Note WARNING NOTICES SAFEGUARDS Electrical energy can perform many useful funtions, This unit has been engineered and manufactured to assure your personal safety. Imporoper use can result in potential electrical shock or fire hazards. In order not to defeat the safeguards, observe the following precautions for its installation, use and servicing.
SANWAY AUDIO http://www.china-sanway.com http://www.china-sanway.com Control elements ...
Page 4
SANWAY AUDIO http://www.china-sanway.com http://www.china-sanway.com Rear panel features introduction 2 channel version DIP switches 4channel version XLR connectors for Mains input shown with Neutrik 200V- 240V for adjusting key inputs and loop thru shown with Neutrik or 1 00V- 120V Speakon output features Speakon output operation...
SANWAY AUDIO http://www.china-sanway.com http://www.china-sanway.com Audio input and output connections BALANCED INPUT CONNECTIONS Audio input-4-channel models When linking the same source signal to several input channels, be aware that there is a limit to the number of channels an output source can "drive". A typical output sourse (e.g.
SANWAY AUDIO http://www.china-sanway.com http://www.china-sanway.com Output Mode Stereo Mode Before setting the mode, please turn off the amplifier and slide the mode select switch to below (Picture 1). In this mode, Channel 1 an Channel 2 operate independently (Just traditional stereo amplifier).
Page 8
SANWAY AUDIO http://www.china-sanway.com http://www.china-sanway.com Professional Power Amplifier Specifications HT-10Q MODEL Output Power 8R Stereo Power 4×1300W 4R Stereo Power 4×2200W 2R Stereo Power 4×2500W 8R Bridged Monon Power 2×4400W 4R Bridged Monon Power 2×5000W 20Hz-25kHz ±0.5dB FREQUENTY RESPONSE 0.10% THD+N(Rated power,4ohm/1KHz)% Signal Noise Ration(dB) 110dB 20Kohm Balanced / 10kohm Unbalanced...
