Programming

Programming
Set Time
(If using programming)
Follow the steps below to set the day of the week and current time:
1. Press the Menu button.
2. Press Set Time.
3. Day of the week is flashing. Use the
select the current day of the week.
4. Press Next.
5. The current hour is flashing. Use the
select the current hour. When using 12-hour time, make sure
the correct a.m. or p.m. choice is selected.
6. Press Next.
7. Minutes are now flashing. Use the
select current minutes.
8. Press Done when completed.
Programming
All our programmable thermostats are shipped with an energy saving default
program. You can customize this default program by following the
instructions in the set program schedule section starting on page 38.
Your thermostat can be programmed to have each day of the week
programmed uniquely (7 days), all the weekdays the same with a separate
program for Saturday and a separate program for Sunday (5+1+1), or
non-programmable.
A Note About Programmable Fan:
The programmable fan feature will run the fan continuously during any
time period it is programmed to be on. This is the best way to keep the
air circulated and to eliminate hot and cold spots in your building.
37
Programming
Set Program Schedule For Four Time Periods
Saturday:
1. Repeat steps 4 through 6 for the Saturday WAKE time period,
LEAVE time period, RETURN time period, and for the Saturday
SLEEP time period.
Sunday:
1. Repeat steps 4 through 6 for the Sunday WAKE time period, LEAVE
time period, RETURN time period, and for the Sunday SLEEP time
period.
41
or key to
or key to
or key to
Temporary & Permanent Hold Feature
Temporary Hold: The thermostat will display HOLD and
Run Schedule on the bottom of the screen when you press the
or
setpoint temporarily for 4 hours. The program setpoint will then
replace the temporary setpoint.
Permanent Hold: With a temporary hold set, If you press the HOLD
key at the bottom of your screen, you will see HOLD appear next to
the setpoint temperature in the display. The thermostat will now
permanently stay at this setpoint and can be adjusted using the
To Return To Program: Press the Run Schedule key at the bottom of
the screen to exit temporary and permanent holds.
Filter Change Reminder
If your installing contractor has configured the thermostat to remind
you when the air filter needs changed, you will see CHANGE FILTER
in the display when your air filter needs changed. The reminder will
be shown in the display after your system has run long enough to
require an air filter change.
To reset the timers for Prosync, user must hold the "Run Schedule"
button (2nd button down on the left) on either the main screen, or
the related timer tech settings.
Programming Programming
Default Programming
Factory Default Program
Day of
Events Time
the Week
Wake
Leave
Weekday
Return
Sleep 10 PM
Wake
Leave
Saturday
Return
Sleep 10 PM
Wake
Leave
Sunday
Return
Sleep 10 PM
Programming
key. If you do nothing, the temperature will remain at this
or keys.
Setpoint
Temperature Temperature
(HEAT)
6 AM ˚ ˚
70 F (21 C)
8 AM ˚ ˚
62 F (17 C)
˚ ˚
6 PM
70 F (21 C)
˚ ˚
62 F (17 C)
˚ ˚
6 AM 70 F (21 C)
8 AM
˚ ˚
62 F (17 C)
˚ ˚
6 PM 70 F (21 C)
˚ ˚
62 F (17 C)
˚ ˚
6 AM
70 F (21 C)
8 AM ˚ ˚
62 F (17 C)
˚ ˚
6 PM 70 F (21 C)
˚ ˚
62 F (17 C)
Setpoint
(COOL)
˚ ˚
78 F (26 C)
˚ ˚
85 F (29 C)
˚ ˚
78 F (26 C)
˚ ˚
82 F (28 C)
˚ ˚
78 F (26 C)
˚ ˚
85 F (29 C)
˚ ˚
78 F (26 C)
˚ ˚
82 F (28 C)
˚ ˚
78 F (26 C)
˚ ˚
85 F (29 C)
˚ ˚
78 F (26 C)
˚ ˚
82 F (28 C)
