Programming
Set Time
Follow the steps below to set the day of the week and current time:
1. Press the MENU button.
2. Press TIME.
3. Day of the week is flashing. Use the
select the current day of the week.
4. Press NEXT.
5. The current hour is flashing. Use the
select the current hour. When using 12-hour time, make sure
the correct a.m. or p.m. choice is selected.
6. Press NEXT.
7. Minutes are now flashing. Use the
select current minutes.
8. Press DONE when completed.
Programming
All our programmable thermostats are shipped with an energy saving default
program. You can customize this default program by following the
instructions in the set program schedule section starting on page 24.
Your thermostat can be programmed to have each day of the week
programmed uniquely (7 days), all the weekdays the same with a separate
program for Saturday and a separate program for Sunday (5+1+1), or
non-programmable. For the 7-day and 5+1+1 programming modes, there are
two time period options.
1. "4" Residential (WAKE, LEAVE, RETURN, SLEEP)
2. "2" Commercial (OCCUPIED, UNOCCUPIED)
This thermostat has a programmable fan feature, which allows you to run the
fan continually during any time period.
Programming
Set Program Schedule For Four Time Periods
(WAKE, LEAVE, RETURN, or SLEEP)
To customize your 5+1+1 Program schedule, follow these steps:
Weekday:
1. Select HEAT or COOL with the system switch.
Note: You have to program heat and cool each separately.
2. Press the MENU button (If menu does not appear first press
RUN).
3. Press SCHED. Note: Monday-Friday is displayed and the
WAKE icon is shown. You are now programming the
WAKE time period for that day.
4. Time is flashing. Use the
selection for the weekday WAKE time period.
Note: If you want the fan to run continuously during this time
period, select ON with the FAN key. If you want to use IAQ
mode during this time period, select IAQ with the FAN key.
5. Press NEXT.
6. The setpoint temperature is flashing. Use the
to make your setpoint selection for the weekday WAKE period.
7. Press NEXT.
8. Repeat steps 4 through 7 for the weekday LEAVE
time period, for the weekday RETURN time period,
and for the weekday SLEEP time period.
Saturday:
Repeat steps 4 through 7 for the Saturday WAKE time period, for the
Saturday LEAVE time period, for the Saturday RETURN time period,
and for the Saturday SLEEP time period.
Sunday:
Repeat steps 4 through 7 for the Sunday WAKE time period, for the
Sunday LEAVE time period, for the Sunday RETURN time period, and
for the Sunday SLEEP time period.
or
key to
or
key to
or
key to
or
key to make your time
or
Programming
Default Programming
Day of
Events
the Week
Wake
Leave
Weekday
Return
Sleep
Wake
Leave
Saturday
Return
Sleep
Wake
Leave
Sunday
Return
Sleep
Programming
To customize your 7 day Program schedule, follow these steps:
Monday:
1. Select HEAT or COOL with the SYSTEM key.
Note: You have to program heat and cool each separately.
2. Press the MENU button (If menu does not appear first, press
RUN).
3. Press SCHED. Note: Monday is displayed and the
WAKE icon is shown. You are now programming the
WAKE time period for that day.
4. Time is flashing. Use the
selection for that day's WAKE time period.
Note: If you want the fan to run continuously during this time
period, select ON with the FAN key. If you want to use IAQ
mode during this time period, select IAQ with the FAN key.
5. Press NEXT.
6. The setpoint temperature is flashing. Use the
to make your setpoint selection for that day's WAKE period.
key
7. Press NEXT.
8. Repeat steps 4 through 7 for that day's LEAVE time period,
for that day's RETURN time period, and for that day's
SLEEP time period.
Repeat steps 4 through 8 for the remaining days of the week.
A Note About Auto Changeover:
In Auto you have the ability to switch between Auto Heat or Auto Cool
by pressing the system key. This can be done once the current mode has
reached its setpoint. For example: if in Auto Heat, the heat setpoint must
be satisfied before the thermostat will allow you to switch to Auto Cool.
You can switch out of Auto by holding down the system key. To get back
into Auto, you must toggle the system key to Auto.
Factory Default Program
Setpoint
Time
Temperature
(HEAT)
6 AM
˚
˚
70
F (21
C)
8 AM
˚
˚
62
F (17
C)
6 PM
˚
˚
70
F (21
C)
10 PM
˚
˚
62
F (17
C)
˚
˚
6 AM
70
F (21
C)
8 AM
˚
˚
62
F (17
C)
˚
˚
6 PM
70
F (21
C)
˚
˚
10 PM
62
F (17
C)
˚
˚
6 AM
70
F (21
C)
8 AM
˚
˚
62
F (17
C)
˚
˚
6 PM
70
F (21
C)
˚
˚
62
F (17
C)
10 PM
or
key to make your time
Setpoint
Temperature
(COOL)
˚
˚
75
F (24
C)
˚
˚
83
F (28
C)
˚
˚
75
F (24
C)
˚
˚
78
F (26
C)
˚
˚
75
F (24
C)
˚
˚
83
F (28
C)
˚
˚
75
F (24
C)
˚
˚
78
F (26
C)
˚
˚
75
F (24
C)
˚
˚
83
F (28
C)
˚
˚
75
F (24
C)
˚
˚
78
F (26
C)
or
key
