Specifications - EWC Controls EWT-755WHO Installation Manual

Programming
Custom Programming
Custom Program
Day of
Events Time
the Week
Wake
Leave
Weekday
Return
Sleep
Wake
Leave
Saturday
Return
Sleep
Wake
Leave
Sunday
Return
Sleep
39

Specifications

Specifications
The display range of temperature ... 41˚F to 95˚F (5˚C to 35˚C)
The control range of temperature.... 44˚F to 90˚F (7˚C to 32˚C)
Load Rating............................................... 1 amp per terminal, 1.5 amp
Swing (cycle rate or differential) ...... Heating is adjustable from 0.2˚ to 2.0˚
Power source ...........................................18 to 30 VAC, NEC Class II, 50/60 Hz
Operating ambient ............................... 32˚F to +105˚F (0˚C to +41˚C)
Operating humidity .............................. 90% non-condensing maximum
Dimensions of thermostat ................. 4.7" W x 4.3" H x 1.1" D
Frequency ................................................ 916 MHz
Base module
Load rating ............................................... 1 amp per terminal, 1.5 amp
Power source ........................................... 18 to 30 VAC, NEC class II, 50/60 Hz
43
(Fill out before starting the process)
Setpoint
Temperature Temperature
(HEAT)
maximum all terminals combined
Cooling is adjustable from 0.2˚ to 2.0˚
for hardwire
Battery power from 2 AA Alkaline
batteries
maximum all terminals combined
Programming
Set Program Schedule For Four Time Periods
If you intend to use additional Remote Sensors in addition to the
Main Thermostat you must install, link and name all of the remotes in
Setpoint the system before you begin the scheduling process.
To customize your 5+1+1 Program schedule, follow these steps:
(COOL)
Weekday:
1. Select HEAT or COOL with the System Key.
Note: You have to program heat and cool each separately.
2. Press the MENU button (If menu does not appear first, press
RUN SCHED).
3. Press SET SCHEDULE. Note: Monday-Friday is displayed, and the
WAKE icon is shown. You are now programming the WAKE time
period for the weekday setting.
4. Time is flashing. Use the
selection for the weekday WAKE time period.
Note: If you want the fan to run continuously during this time period,
select ON with the FAN key. AUTO will cycle the fan when there is a
call for heat or cool. IAQ will cycle the fan intermittently based on the
IAQ tech settings.
5. Press Next.
6. The setpoint temperature is flashing. Use the
make your setpoint selection for the weekday WAKE period.
7. At any point use the ZONE button to select the remote you want to
be in control for that time period. If you want the system to average
all remotes, select System Average.
Note: This setting only applies if you are using multiple remote sensors.
8. Press Next.
9. Repeat steps 4 through 8 for the weekday LEAVE time period, for
the weekday RETURN time period, and for the weekday SLEEP time
period.
Specifications
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
FCC RF Exposure Statement
The device shall be used in such a manner that the potential for human
contact normal operation is minimized. This equipment complies with FCC
radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of
20cm between the radiator and your body. This device and its antenna(s)
must not be co-located or operating in conjunction with any other antenna
or transmitter.
(WAKE, LEAVE, RETURN, SLEEP)
or key to make your time
or key to
40
44
