- Page 1 HULALA ITEM NO.BCYJ0741 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/26...
- Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
-
Page 3: Explosive View
EXPLOSIVE VIEW 2PERSONENS 03/26... -
Page 4: Parts List
PARTS LIST 1 04/26... -
Page 5: Hardware List
HARDWARE LIST Ø3*15MM Ø4*20MM 5/32"*16MM Ø3*15MM Ø4*38MM Ø4*39MM 1/4"*15MM 1/4"*32MM TOOL LIST HARDWARE SPARE LIST Ø3*15MM 1/4"*15MM Ø3*15MM 1/4"*32MM 05/26... - Page 6 ASSEMBLY INSTRUCTIONS STEP-1 1.Insert side panel (A1 ＆ A2) into bottom panel (A4),make sure all holes aligned and then tighten it with allen key B17as picture show. 06/26...
- Page 7 ASSEMBLY INSTRUCTIONS STEP-2 1.Use screw B1 to attach magnetic catch B13 to the corresponding hole of panel(A3), tighten screw with screwdriver B18. Ø3*15MM 07/26...
- Page 8 ASSEMBLY INSTRUCTIONS STEP-3 1.Insert panel (A3) into side panel (A1&A2),make sure all holes aligned and then tighten it with allen key B17 as picture show. 08/26...
- Page 9 ASSEMBLY INSTRUCTIONS STEP-4 1.Open the back panel (A5),insert back panel(A5) into the groove of preassembled step 3,make sure all holes aligned and use screw B1 to attach them ， tighten screw #2 with screwdrive B18. B18 x1 Ø3*15MM 09/26...
- Page 10 ASSEMBLY INSTRUCTIONS STEP-5 install part （ A8 A10 ） on of part A11, ensure the & & corresponding holes are aligned and fix with screw B8, then tighten the screw with an Allen key B17. & & B17 x1 1/4"*32MM 10/26...
- Page 11 ASSEMBLY INSTRUCTIONS STEP-6 1.Use screw B7 to attach part B12 to the corresponding hole of panel (A6&A7), tighten screw with Allen key B17. & 1/4"*15MM 11/26...
- Page 12 ASSEMBLY INSTRUCTIONS STEP-7 Use screw B7 to attach part A6 to the corresponding hole of panel (A10&A9&A8), tighten screw with Allen key B17. Insert part (A13) into part (A6),make sure all holes aligned and then tighten it with allen key B17 as picture show. 1/4"*15MM 12/26...
- Page 13 ASSEMBLY INSTRUCTIONS STEP-8 Connect the cabinet to the pre-assembled unit of the 7. 13/26...
- Page 14 ASSEMBLY INSTRUCTIONS STEP-9 1.Use screw B8 to attach side panel A1 to the corresponding hole of side panel A6, tighten screw with Allen key B17. 1/4"*32MM 14/26...
- Page 15 ASSEMBLY INSTRUCTIONS STEP-10 1.Use screw B8&B7 attach the side panel (A2) to the pre-assembled unit from step 9 . 1/4"*15MM 1/4"*32MM 15/26...
- Page 16 ASSEMBLY INSTRUCTIONS STEP-11 1.Use screw# B4 to attach part #A13 to the corresponding hole of bottom panel(A4), tighten screw with screwdriver B18. make sure all holes aligned and then tighten it with allen key #B17 as picture show. Ø4*38MM 16/26...
- Page 17 ASSEMBLY INSTRUCTIONS STEP-12 Attention: Before the next step, adjust the feet of the locker to keep it level. 17/26...
- Page 18 ASSEMBLY INSTRUCTIONS STEP-13 1.Insert shelf pin B9 into Pre-assemble unit at step 2.attach adjustable shelf (A12) to pin B9. Shelf holder can be adjusted up or down 18/26...
- Page 19 ASSEMBLY INSTRUCTIONS STEP-14 1.Use screw B2 to attach the hinges B11 to door panel (A14)&(A15) ， tighten screws with screwdriver B18 & Ø3*15MM 19/26...
- Page 20 ASSEMBLY INSTRUCTIONS STEP-15 Use screw B2 to attach left door A4 and right door A15 to pre-assemble unit at step 14 ,tighten screw B2 with screwdriver B18 . Ø3*15MM 20/26...
- Page 21 ASSEMBLY INSTRUCTIONS STEP-16 1.Use bolt B6 to attach handle B10 to door panel (A15)&(A14) ， tighten bolts with screwdriver B18 5/32"*16MM 21/26...
- Page 22 ASSEMBLY INSTRUCTIONS Concealed hinges are three-way adjustable: Horizontal by screw adjustment! Concealed hinges are three-way adjustable: In-and-out by loosening the hinge arm mounting screw or via cam adjustment! Concealed hinges are three-way adjustable: Vertical via slots in the mounting plate or via cam adjustment! Hinge adjustment method 22/26...
- Page 23 ASSEMBLY INSTRUCTIONS STEP-17 1.Use screw B3 to attach part B15 to preassemble unit at step 16 ,tighten screws with screwdriver B18. Ø4*20MM 23/26...
- Page 24 ASSEMBLY INSTRUCTIONS STEP-18 Ø4*39MM 1.Install the anti-collapse device. 2.Mark the position on the wall, that corresponds to the location of part B15 on the top of panel (A11); Drill and insert the expandable screw B14 by electric drill. 3.Assemble the part B15 to the wall. Align the hole in the part B15 with the expandable screw B14, use screw B5 to attach it and tighten by screwdriver B18.
- Page 25 ASSEMBLY INSTRUCTIONS STEP-19 1.Let the plastic belt B16 pass through the both part B15 and pull tightly. 25/26...
-
Page 26: Warranty
WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
