- Page 1 S202491G User manual...
-
Page 3: Table Of Contents
Contents 01. Important information ..................02 02. Safety instruction - overview ................03 Application scope....................03 Instruction on driving safety................03 Instruction on safety precaution................. 04 Instruction on practice..................04 03. Specification of design and function ..............05 General overview of product................05 Description of structural composition and diagram........... -
Page 4: Important Information
Important information Dear users, Thank you for selecting the Mobifree electric scooter! You must read and understand this operating instruction fully, especially the “safety instruction” part before you use it. The main purpose of going through this operating instruction is to be familiar with the functions and char- acters of the electric scooter and how to operate it smoothly. -
Page 5: Safety Instruction - Overview
Safety instruction - overview 2.1 Application This scooter is used as a mobility aid for people who are disabled or feeble, and patients or seniors who need mobility supports or assists. The maximum safe loading of the electric scooter is 125 kg. 2.2 Instructions of safe driving 01) The user must be familiar with the operation of this scooter before driving. -
Page 6: Instruction On Safety Precaution
16) Do not drive on the escalators to avoid overturning. 17) Do not make a S or U turn suddenly to avoid overturning. 18) Charge the electric scooter fully before using for the first time. Instruction for safety precaution 01) Do not operate the scooter before the user does not fully read and understand this operating instruction. -
Page 7: Specification Of Design And Function
Specification of design and function General overview of the product Working principle: The electric scooter is a power scooter powered by battery and controlled and driven by electronic devices. The user can drive the scooter through the working of control devices. Its main components are the motor, battery, control system, wheels, seat, armrests, etc... -
Page 8: Main Technical Parameters
Main technical parameters Model Total length 960 mm 530mm Total width Total height 830mm Folded length 440mm 505mm Folded width Folded height 680mm Weight of entire vehicle 23.9KG 22.6KG Weight of vehicle (excluding battery) Quality of battery 1.8KG Front wheel 6 inches Tire size Rear wheel 7 inches Maximum driving speed... -
Page 9: Operating Instruction
Operating instruction Necessary abilities of the operator(driver) 01) The electric scooter is controlled by the user by fingers to move forward and backward and turn left or right and folds and unfold, also control the speed.So the user must be capable of: -Reading and understanding the operating instruction -Distinguishing and evaluating danger -Having the safety awareness or following the traffic rules of local laws... -
Page 10: Power Switch
The control panel is an operation control module which mainly controls the power on and off, moving forward and backward during driving and display of battery power level. Notice: Do not place the control panel in the wet areas. If the control panel is damped, please operate and use it after being fully dried. -
Page 11: Horn Button
c. After the direction control lever is fully released, it will automatically stop in the “central” position, and the electromagnetic brake will automatically stop the scooter. Figure 7 Figure 8 Horn button In order to prevent from accident and damage, please use the horn button properly. -
Page 12: Controller And Motor
Controller and motor The controller is fixed in the bottom to receive the signal from the control panel and send it to the motor, brake, charging port and other systems； The motor / transmission modules, which are electromechanical devices. convert the electric energy of battery to the driving energy of rear wheels. - Page 13 Press down the manual folding handle, and pull towards the seat (the scooter will be automatically unfolded a bit) Figure 13 （2） 1. Hold the tiller by one hand, and （1） grasp the edge of seat cushion by the other hand 2.
-
Page 14: Battery And Charging
b. The user shall firstly press down the manual folding handle and lift upward by hand (as shown in Figure 16), then the front and rear frames will be folding (as shown in Figure 17), after they are folded to a certain degree, the user shall push forcibly by both hands (press the edge of frame by one hand, and press the seat cushion by the other hand) (as shown in Figure 18), until the front and rear frames are fully folded in place. - Page 15 b. Take AC power line and insert one end in the domestic power socket, connect one end to the charging socket of the charger, then the red light is on when the scooter is being charging, and the green light or orange light is on after the scooter is fully charged.
-
Page 16: Description Of Misoperation
4.12 Description of wrong operation 01) The connection of battery electrode is not tight. 02) The manual electromagnetic brake levers are not locked. 03) The power socket and plug are connected reversely. 04) Wash the scooter directly by faucet. 05) Scrub it with oil or chemical liquid. 06) Fold and unfold the scooter on the slope. -
Page 17: Maintenance And Care
Maintenance and care Maintenance 01) Place the scooter in the dry and ventilated places and avoid contacting oil, acid, alkaline and other corrosive chemical substances. 02) Keep the body clean: The control panel, covers, etc., are made of the durable ABS plastics, and the surface is pain coated. - Page 18 Electric wire connectors: regularly check all exposed electric wire connectors; (Monthly) Regularly check the insulations of all exposed electric wires, including the power plug of charger (Monthly); repair or replace the damaged fittings and connectors (Yearly). All major screws or nuts Regularly check if all exposed screws or nuts are loosened (Monthly).
-
Page 19: Instruction And Precaution Of Battery
Instruction and precaution of the battery 25.2V 10AH * 1 PC lithium battery is used. Before the batteries are used for the first time, the power in the batteries must be fully charged. 01) To ensure smooth driving, the scooter must be fully charged before travelling; 02) The scooter is charged according to the voltage of the country and region and plugs. -
Page 20: Transportation Condition And Storage
Transportation and storage The scooter is packaged with the kraft box to prevent it from water, pressing. It can be transported by air, sea or ground. The product can be stored in: (-20°C to 45°C, 10%-80% humidity) shady, cool, dry, ventilated and corrosive gas free places. -
Page 21: Circuit Diagram And Key Component List
Circuit diagram and key component list 10.1 Consult the manufacturer about the component list. 10.2 If the circuit failure occurs, the user shall immediately stop using the scooter and contact the after-sales service personnel for professional judgment and maintenance in order to ensure the safe operation. Packaging and accessories 11.1 The product is packaged with the kraft carton, and the accessories includes:... -
Page 22: Troubleshooting Guideline
Troubleshooting Guideline 12.1 When turn on the power switch, but the power indicator is not on, please check whether the power line and the control line are correctly connected or not; if the contacts are loosened, and the battery’ s power. 12.2 When the user drives the electric scooter, if the speed is inconsistent and the scooter stops and goes, the user shall check if the motor is overheated, noisy or... -
Page 23: Warranty Card And Warranty Specification
Warranty card and warranty specification 14.1 The warranty card is shown in Appendix C 、 14.2 Warranty scope specification: If the quality problem occurs to the parts on the material, manufacturing or assembly under normal use, the agent is responsible for maintaining or replacing the parts. -
Page 24: Interpretations Of Graphics, Symbols, Abbreviations And Other Contents Used For The Labels Of Medical Devices
Interpretations of graphics, symbols, abbreviations and other contents used for the labels of medical devices Type B application part Separate treatment sign of waste electrical and electronic equipment (Please follow the local laws and regulations) Note, refer to the attached documents Battery Warning on clamping hands Keep away from the sunlight... -
Page 25: Appendix-Warranty Card
Appendix-Warranty Card User name ID card No. Address Contact number Model Vehicle number Purchase date year month Warranty period 12 months from the date of purchase (battery 6 months) Manufacturer Guangdong Prestige Technology Co., Ltd. Agent name (seal or signature) Contact number (or address) Packing list...
