- Page 1 ECOFLEX MINI VRF R-32 SERIES One-way Cassette Owner’s Manual Model Numbers MOC-018CS MOC-022CS MOC-028CS MOC-036CS MOC-045CS MOC-056CS MOC-071CS CAUTION: The system is charged with flammable refrigerant, safety checks are necessary to ensure that the risk of ignition is minimised.
-
Page 2: Table Of Contents
05. Cleaning and Maintenance ......................14 05.01. Safety Warning 05.02. Cleaning the Air Filter 05.03. Cleaning Air Outlets and Exteriors Panels 05.04. Maintenance 06. Maintenance Frequency Checklist ...................17 Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819... -
Page 3: Preface
• Please retain this manual for future reference. Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819... -
Page 4: Safety Warning
No Acid or No Strong Current No Strong Current No Open Fire No Acid or Materials Materials Alkali Materials Alkali Materials Safety Precautions Safety Precautions Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819... -
Page 5: Safety Precautions
Safety Warning this International Standard. Safety Warning Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819... -
Page 6: Electric Safety Requirements
The area shall be checked with an appropriate refrigerant detector prior to and during work, to ensure the technician is aware of potentially flammable atmospheres. technician is aware of potentially flammable atmospheres. Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Safety Warning Doc. No.9590-4028-02 Ver. 1 230819... -
Page 7: Appendix
Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819... - Page 8 • the recovery process is supervised at all times by a competent person; • recovery equipment and cylinders conform to the appropriate standards. 4. Pump down refrigerant system, if possible. Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819...
- Page 9 • These units are partial unit air conditioners, complying with partial unit requirements of this International Standard, and must only be connected to other units that have been confirmed as complying to corresponding partial unit requirements of this International Standard. Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819...
-
Page 10: Operation Precautions
When the air conditioner needs to be moved and re-installed, please entrust the local dealer or a professional technician to operate it. technician to operate it. Operation Operation Operation Operation Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819... -
Page 11: Optimum Operation
Long-term air outlet at an angle of 30 ° may cause condensation on the surface of the air guide bar. It is recommended to turn on the anti-condensation function through the remote controller to alleviate this situation. Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Operating Range... -
Page 12: Symptoms That Are Not Faults
The following phenomena are normal during operation of the air conditioner. They can be solved according to the instructions below or do not need to be solved. Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819... - Page 13 In this case, the mode setting is unavailable, and other Indoor Units operate in the same mode as the master Indoor Unit. Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819...
-
Page 14: Display Panel
Improper installation by yourself may result in water leakage, electric shock or fire. Do not wash the air conditioner with water; otherwise, it may cause an electric shock. Use a stable standing platform. Operation Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819... -
Page 15: Cleaning The Air Filter
• If the filter is heavily soiled, use a soft brush and neutral detergent to clean it, then shake off the water and dry it in a cool place. • Non-professionals should not disassemble, replace or repair the filter. Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819... -
Page 16: Cleaning Air Outlets And Exteriors Panels
• Check the return air inlet and outlet of the outdoor Unit and Indoor Unit after long periods of use to see if they are blocked; if an inlet/outlet is blocked, clean it immediately. Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819... -
Page 17: Maintenance Frequency Checklist
Inspect duct works for air Duct Works Re-tape any loose ducts. gaps. * Service period for filter cleaning may vary depending on operating time and surrounding environment. Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE Doc. No.9590-4028-02 Ver. 1 230819... - Page 18 THIS PAGE WAS INTENTIONALLY LEFT BLANK...
- Page 19 THIS PAGE WAS INTENTIONALLY LEFT BLANK...
- Page 20 ©Copyright 2023 Actron Engineering Pty Limited ABN 34 002767240. ®Registered Trade Marks of Actron Engineering Pty Limited. ActronAir is constantly seeking ways to improve the design of its products. Therefore, specifications are subject to change without notice. Owner’s Manual ECOFLEX MINI VRF R-32 SERIES - 1 WAY CASSETTE...
