Commercial Electric 569021111 Use And Care Manual

Package contents
Part Description
A Fixture Body
B Electrical Box
HarDware IncluDeD
Part Description
AA Mounting Screw
BB Drywall Anchor
CC U Bracket
DD V Clip*
EE Cord Grip
FF Chain*
GG S Hook*
* For suspension mounting only.
NOTE: Keep your receipt and these instructions for proof of purchase.
WARNING: RISK OF ELECTRIC SHOCK. Ensure the electricity to the wires you are working on is shut off. Either remove the
fuse or turn off the circuit breaker before removing an existing light fixture or installing the new one.
If you are unfamiliar with electrical installations, we recommend you contact a qualified electrician to do the installation.
InstallatIon PreParatIon
Select a suitable location that can support the weight of the fixture.
Determine the method for mounting the fixture before drilling, based on the
type of ceiling.
1. Remove the electrical box (B) from one end of fixture body (A) that will be
connect to electrical source.
Remove the nut from the end of the cord grip (EE) and insert the threaded end
into the knock out hole on the end of the fixture body (B).
2. Feed the wires from the electrical source through the cord grip (EE) and into the fixture body (B). Connect the hot and neutral
(black and white) wires from the electrical source to the same color wires from the fixture body (A) with the wire connector.
Electrical source
3. Adjust the length of wires and tighten the nut onto the
cord grip (EE) to secure the wires. Position the wires back
inside the electrical box (B). Fasten the metal buckle to
cover the electrical box (B) to the fixture body (A).
UsE ANd CARE GUIdE
4fT. LEd VApORTIGhT
Quantity
1
2
B
Quantity
4
4
2
2
2
2
2
EE
A
AA BB
DD EE
Knock out hole
Wire connector
EE
B
EE
B
1
Item # 1009342703
Model # 569021111
CC
FF
B
EE
A
Metal buckle
A
B
GG
A
