TMG -AJT10 Product Manual

1,000 lb transmission jack low profile

PRODUCT MANUAL

v.2022.09.01

MODEL

TMG-AJT10

1,000 LB TRANSMISSION

JACK LOW PROFILE

• Please read and understand the product manual completely before assembly

• Check against the parts list to make sure all parts are received

• Wear proper safety goggles or other protective gears while in assembly

• Do not return the product to dealer. They are not equipped to handle your requests.

Missing parts or have questions on assembly?

Please call: 1-877-761-2819 or email: cs@tmgindustrial.com

www.tmgindustrial.com

TOLL FREE: 1-877-761-2819

Table of Contents

Need help?

Do you have a question about the TMG-AJT10 and is the answer not in the manual?

Page 1 PRODUCT MANUAL v.2022.09.01 MODEL TMG-AJT10 1,000 LB TRANSMISSION JACK LOW PROFILE WARNING • Please read and understand the product manual completely before assembly • Check against the parts list to make sure all parts are received • Wear proper safety goggles or other protective gears while in assembly •...
Page 2 SPECIFICATION MAXIMUM CAPACITY 500KG RETRACTED HEIGHT 215MM MAXIMUM HEIGHT 565MM WARNING • Read and understand all operating instructions before use. • The vehicle must be properly supported and blocked before starting repairs. • Use a transmission jack of the proper size and capacity to handle the anticipated load.
Page 3 OPERATION Move the jack into position Turn the knob fully clockwise to close the valve Move the pump lever up and down to raise the saddle Adjust the angle screws to align with the shape of the transmission Adjust the angle brackets and the chain to secure the transmission on the saddle Remove the transmission from the vehicle Turn the knob counter clockwise slowly to lower the saddle.
Page 4 MAINTENANCE The hydraulic cylinder assembly contains hydraulic ﬂuid that must be kept within 80% of full at all times for proper operation. To check the level and to ﬁll: Remove the screw Fill with clean hydraulic ﬂuid only Replace the screw Lubricate the shaft threads of the angle screw assembly with tube grease when necessary.
