PRODUCT MANUAL
v.2022.09.01
MODEL
TMG-AJF03L
3 TON FLOOR JACK
LOW PROFILE
WARNING
• Please read and understand the product manual completely before assembly
• Check against the parts list to make sure all parts are received
• Wear proper safety goggles or other protective gears while in assembly
• Do not return the product to dealer. They are not equipped to handle your requests.
Missing parts or have questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
www.tmgindustrial.com
TOLL FREE: 1-877-761-2819
Advertisement
Table of Contents
Related Manuals for TMG TMG-AJF03L
Summary of Contents for TMG TMG-AJF03L
- Page 1 PRODUCT MANUAL v.2022.09.01 MODEL TMG-AJF03L 3 TON FLOOR JACK LOW PROFILE WARNING • Please read and understand the product manual completely before assembly • Check against the parts list to make sure all parts are received • Wear proper safety goggles or other protective gears while in assembly •...
- Page 2 Any structural modifications to the product will void the manufacturer’s warranty! This product is intended for private use only! Technical specifications Description: Garage Jack Model: TMG-AJF03L Nominal load: max. 3 tonnes Lifting height: min. 87 mm to max. 455 mm Total length: ca. 640mm Own weight: ca.
- Page 3 Use wheel chocks Do not overload Warning about to secure the wheel hand injuries DO NOT OVERLOAD General usage instructions Before using the floor jack, check for loss of oil, damage or missing accessories. First time operation: Open the drain valve and insert the enclosed handle (extension) in the pumping arm . To ensure the oil distributes itself completely, carry out approx.
- Page 4 NOTE: The instructions below must not be carried out while the vehicle jack is In use. NOTE: The vehicle jack is equipped with a safety valve (15). It has been configured to allow the vehicle jack to lift loads up to 2 tonnes. The safety valve must not be modified or adjusted in any way! Troubleshooting Problem 1: The lifting arm won‘t raise when pumping under load.
- Page 5 www.tmgindustrial.com P4/5 TOLL FREE: 1-877-761-2819...
- Page 6 REF# PART# DESCRIPTION Lifting arm assembly TZ830018Z-2 Saddle pin TZ830026X-GS-1 Saddle GB894.1-18 C-clip Ø18mm Connecting rod pintle T830018-1 Front wheel Frame assembly Washer M16 Spring washer M16 Nut M16 T830021.5(asm) Rear caster assembly GB859-12 Spring washer M12 Socket head cap screw M12x25mm Back shaft GB6170-M12 Nut M12...
