THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
USER'S MANUAL
Treadmill
SP37681US
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Costway SuperFit SP37681US
Summary of Contents for Costway SuperFit SP37681US
- Page 1 AU office: Truganina DE office: Hamburg FR office: Saint Vigor d'Ymonville PL office: Gdańsk USER’S MANUAL Contact Us! Treadmill SP37681US US:cs.us@costway.com Do NOT return this item. UK:cs.uk@costway.com AU:cs.au@costway.com THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
-
Page 2: Before You Start
1. Safety precautions warning instructions NOTE: Please read the instruction carefully before using and pay attention to the following safety precautions. ★ The treadmill is suitable to be placed indoors, to avoid moisture, splash water on the treadmill and place any foreign matter. ★... - Page 3 Warning: Please observe the following 5. Having difficulty in breathing. regulations in order to reduce accidents 6. Using artificial pacemakers or implantable medical electronic devices. or injuries to others. 7. Having malignant tumors. 8. Having thrombosis or serious dynamic environment tumor, acute ★Please check your clothing or zipped before using the treadmill.
- Page 4 Avoid touching with water Prohibition ◆ Do not spray water or other conductive liquid on main body or ◆ ◆Do not use in the state of shell cracked, detached (internal structure exposed) or weld detached. operation part. -It may cause electric shock and fire. -Otherwise, it's easy to cause accident or injuries.
-
Page 5: Product Introductions
2. Product introductions Pull out the power plug ◆ Please pull out the power plug from socket when you don't use it. -Dust and moisture make its insulation deteriorate and lead to electricity Electronic Display leakage and fire. ◆ Please be sure to pull the power plug from the socket during maintenance. -
Page 6: Technical Parameters
3. Installation procedure Technical parameters AC-110V 60Hz Operating Voltage Maximum Load 189.5 lbs Outline Dimension L44.5*W23*H37 inch Running Area 37.4*14.2 inch Motor Power 2.25HP Speed Range 0.6-7.5 mph 1. Take the machine out of the box and put it flat on the carpet or soft cushion, Product Weight 56.2 lbs and then put the machine on the ground. -
Page 7: Folding Instruction
4. Sports advice and guidelines 3. As shown in step ⑨, "safety lock" is warm-up exercise sucked into the yellow square box of the digital console and installed; Switch on the warm up for 5-10mins before each operation. power, then turn on the power switch below the front end of the machine to enter the Breathe standby state. -
Page 8: Hamstring Stretch
5. Instructions How to use the treadmill 1. Turn on the power and check if the machine is normal. 2. Set the running speed of the running belt from 0.6-7.5 MPH. 3. Clip the safety lock on the placket on the chest of the athlete. 4. - Page 9 1. LED window shows the following functions: 3. The starting speed is: 0.6mph. At this time, you can press the speed +, -keys to adjust the speed and the 3 mph speed direct selection button. Time / speed / distance / calorie / pulse window: 5 seconds to switch display time, speed, distance, calorie data, heart rate.
-
Page 10: Product Maintenance
7. Product maintenance Questions Possible causes Maintenance methods 1. Lubrication not connected put plug to insert socket When the running machine is used for a period of time, it must be put the power switch in power is not turned on position "ON”... - Page 11 5. Adjustment of motor belt (as shown in the right picture) 3. Adjust tightness of running belt. All treadmills shall be adjusted for tightness before delivery and after installation. All treadmills have been adjusted for the motor belt before and after However, the running belt may be loosened after a period of use.
-
Page 12: Functions Overview
Gymax App Instruction Manual Retrieve Password v1.0.5 If E-mail users forget Passwords, users can click "Forget Password" on the mailbox login interface to jump to the Password retrieval interface, This document is applicable to the Android version and iOS version of the and then reset Passwords. -
Page 13: Starting Exercise
Starting exercise Sports Scenes Selecting the device page, such as "Start" on the "Treadmill" interface, Connecting services users enter the running free, as shown below: On the home page, users can freely choose the device type to connect. 1. Waiting for Gymax to automatically connect to the treadmill. After connecting successfully, then user can select the device page, such as the "Treadmill"... -
Page 14: Setting Goals
4. When users finish the exercise, the Gymax App will show users' total Sports Plan running distance. Users can click "Add More Training Plans" to add users' own sports plans. 5. Users can share the sports data to the community or save it to the phone album. - Page 15 2. And then start training with a fitness coach. 2. When the goal is reached, the exercise automatically ends. Exercise Record Training Course The user can view the exercise data record in the device page. 1. Users can select courses in the interface of training course. (me-exercise data)
- Page 16 Sports Mall Users can purchase satisfied sports devices. Community dynamic 1. In sports community, users can share dynamic communication with each other. 3. Users can post 4. Users can remove 2. Users can comment dynamics in dynamics. the released dynamics community.
-
Page 17: Clear Cache
Unit settings (metric or imperial standard) Feedback Users can submit suggestions and the problem for improving the product. Clear Cache Users can clean up the system cache according to users' needs, including Gymax App H5 web page load cache and image load cache.
Need help?
Do you have a question about the SuperFit SP37681US and is the answer not in the manual?
Questions and answers
Come associare a tablet ndroid
To connect the Costway SP37681US to an Android tablet using the Gymax App:
1. Open the Gymax App on your Android tablet.
2. Sign in using Facebook or Email.
3. On the home page, select the treadmill device type.
4. Wait for the app to automatically connect to the treadmill.
5. When the connection status sign is lit, the app is successfully connected.
6. You can now control the treadmill and view exercise data such as distance, time, calories, and speed.
This answer is automatically generated
How to put oil
The manual states that the treadmill must be lubricated with special methyl silicone oil after a period of use. Lubrication frequency depends on usage:
- 1 hour or less per week: Lubricate once every 6 months.
- Less than 3 hours per week: Lubricate once every 3 months.
- 3-6 hours per week: Lubricate once every 2 months.
- More than 6 hours per week: Lubricate once a month.
To apply the oil, follow these steps:
1. Ensure the treadmill is powered off.
2. Lift the running belt slightly to access the underside.
3. Apply methyl silicone oil evenly under the belt.
4. Lower the belt and start the treadmill at a slow speed to distribute the oil.
5. Do not over-lubricate, as excess oil is unnecessary.
This answer is automatically generated
