HOMCOM 370-287V90 Manual page 11

1. Slide the rear wheel onto the rear axel, and keep the rear wheel match up with the gear
box.
2. Slide the M8X1.3 washer onto the rear axel.
3. Tighten a M8 screw nut to the end of the rear axle with a socket tool, take the same
precedure on the other side at the same time.
4. Snap the hub caps to the rear wheel, do the same procedure for the other rear wheel.
Front Wheels Assembly
1.Slide the M8X1.3 washer onto the front axle.
2.Slide the front wheel onto the axle.
3.Slide the M12X1.5 washer onto the front axle.
4.Tighten a M8 screw nut to the end of the front axle with a socket tool, take the same
precedure on the other side.
5.Snap the hub caps to the front wheel, do the same procedure for the other front wheel.
Seat Assembly
11
Front Wheel
