Technical Practice
Optional music and/or promotional announcements will keep the caller assured that
their phone connection is intact and will be answered soon. A pacifier message can
also be recorded to confirm that the call will be answered.
Call statistics as well as the line number of the oldest holding call will be displayed on
the LED. In addition, an optional ring generator, SQRG-12, may be added to provide
complete sequencer automation.
Features
• Compatible with Electronic Key systems, 1A2 Key
systems and PABX systems
• Cascadable to support up to 24 lines
• Automatically change between day and night modes
via a contact closure, timer, remote switch or
remote programming
• Locally recordable with a standard carbon handset
or download announcements directly from a tape
player
• Remotely recordable
• Rechargeable battery back-up included
• Field expandable record time
• Separate recordings for each announcement
• Display for caller priority, inbound call statistics and
record time
• Inbound call statistics:
1. Total inbound calls
2. Total sequenced calls
3. Total abandoned calls
• 19" rack-mount hardware included
• "A" lead control for 1A2 Key Systems
Telecommunication Peripheral Products
Answer up to 12 Lines
http://www.VikingElectronics.com
The T M S - 1 2 A Automatic Call
Sequencer will answer up to 12
inbound lines promptly with a clear,
digitally-recorded voice announce-
ment informing the caller that their
call will be taken by the first
cadgfdll
available representative. The call is then placed on
hold. In addition, two TMS-12A's can be cascaded to
support up to 24 lines.
Applications
• Console operator back-up (eliminates ring - no
answer)
• Multi-line barge-in announcer
• Multi-line remote dial-up access to audio sources
such as radio stations and public address systems
• Statistical tracking of inbound call handling
Sales...(715) 386 - 8861
Made in the U.S.A.

Specifications

Power: 120V AC/13.8V AC, 1.25A UL listed adaptor provided
Dimensions: 483mm x 305mm x 44mm (19" x 12" x 1.75")
Shipping Weight: 3.4 kg (7.5 lbs)
Environmental: 0 C to 32 C (32 F to 90 F) with 5% to 95% non-
condensing humidity
Message Length: 32 seconds (expandable to 2 minutes using the
DRAM-1M)
Sampling Rate: 32 K
Battery Back-up: 2 hours minimum, 8 hours typical
Connections: (1) RJ21X female jack, (2) 3.5mm (1/8") audio
jacks, (2) RJ11 jacks, (1) carbon handset jack
TMS-12A
12 Line Call
Sequencer
November 2, 2005
