The G62 is a compact 4G GPS tracking device with a variety of inputs and outputs to cater for the most demanding applications.
The 4G modem allows for operation on both Cat-M1 and NB-IoT networks. Its rugged housing is IP67 rated to withstand the harshest environments, without sacrificing tracking and
communications performance. With the internal GPS and cellular antennas installation is a breeze. The internal backup battery provides alerts and tracking operations even when
external power is removed.
See the G62 product page
(https://www.digitalmatter.com/devices/g62/)
running with the G62.
Datasheet & High Resolution Images
G62 Downloads
View the tech-specs
(https://www.digitalmatter.com/devices/g62/tech-specs/)
(https://www.dropbox.com/sh/neqb9zz4x678r0n/AABEpapZ0897E4_3NLwNBJq9a?dl=0)
In the Box
You'll get a compact box containing the G62 and a small packet containing the 6 housing screws.
Setting it Up
Sim Card installation
The G62 takes a 3FF Micro SIM card. The G62 may be damaged by electrostatic discharge if not handled correctly so ensure adequate static precautions are taken. Consider wearing
an anti-static wrist guard and avoid touching the antennae and any of the electronic components on the PCB. Take special care not to touch the ceramic GPS antenna as static can
damage the sensitive GPS circuitry.
The SIM holder is located on the top side of the main PCB.
1. Unplug the battery and remove any external power connections.
2. Slide the locking mechanism on the SIM holder to the "unlock" position, and lift the hinged portion of the SIM holder.
3. Insert the micro SIM into the holder with the keyed corner orientated away from the hinge and the SIM contacts orientated down to the PCB (see example above).
4. Close the SIM holder and slide the locking mechanism to the "lock" position.
on digitalmatter.com
(https://www.digitalmatter.com)
and
high resolution device images
for the G62
Getting Started Guide
for more specifications. This guide will help you get up and
G62
1/3
Advertisement
Related Manuals for Digital Matter G62
Summary of Contents for Digital Matter G62
- Page 1 Sim Card installation The G62 takes a 3FF Micro SIM card. The G62 may be damaged by electrostatic discharge if not handled correctly so ensure adequate static precautions are taken. Consider wearing an anti-static wrist guard and avoid touching the antennae and any of the electronic components on the PCB. Take special care not to touch the ceramic GPS antenna as static can damage the sensitive GPS circuitry.
- Page 2 Although the G62 will work in these locations it is always advisable to install the G62 where it is able to get signals from the GPS satellites, with the optimum position being a location with a clear 180-degree view of the sky.
- Page 3 Hourly Heartbeats: the device will log a heartbeat record, connect to the server, and refresh its GPS data every 60 minutes. Wired AND Emulated Ignition: by default, the G62 will track a trip if either the ignition wire is pulled high or movement is detected. The setting can be changed to do one or the other, or continue to use both.
