Mallia
Senses with Netatmo
TM
Connected switches with neutral
2 815 02DS/MB/MW
1. USE
For local or remote control of lighting devices and other controls.
Can be combined with one or more wireless lighting controls.
Can be installed in place of an existing switch in a flush-mounting box 25 mm deep (minimum).
2. RANGE
Product for use in conjunction with the starter pack.
With LED indicator (locator) and RESET button (hidden) used to return to factory
settings.
Locator and indicator modes can be activated from the Home + Control App.
Complete delivered with protection film and 2 screws M3.5 for BS boxes.
3. DIMENSIONS (mm)
B
A
B
86
86
4. CONNECTION
Terminal type : with screws
Terminal capacity: 2 x 1.5 mm
- 2 x 2.5 mm
2
Stripping length: 8 mm
Technical data sheet: F03691EN/00
128, av. du Maréchal-de-Lattre-de-Tassigny - 87045 LIMOGES Cedex
Tel: 33(0)5 55 06 87 87 - Fax: 33(0)5 55 06 88 88
www.legrand.com
2 815 04DS/MB/MW
Description
C
D
C
D
32.5
12
- 1 x 4 mm
2
2
Cat. No(s): 2 815 02DS/MB/MW - 2 815 04DS/MB/MW
Silver
2 815 02DS
1-gang
2 815 04DS
2-gang
2 815 06DS
3-gang
5. OPERATION
1-gang: 2 815 02DS/MB/MW
Updated:
2 815 06DS/MB/MW
2 815 06DS/MB/MW
Black
White
2 815 02MB
2 815 02MW
1-gang
1-gang
2 815 04MB
2 815 04MW
2-gang
2-gang
2 815 06MB
2 815 06MW
3-gang
3-gang
ON/OFF
when press
LED indicator:
- useful during installation
- illumination function can be activated
from the Home + Control app
RESET button
used to return to factory settings
Created: 11/04/2022
1/2

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mallia Senses with Netatmo 2 815 02DS/MB/MW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LEGRAND Mallia Senses with Netatmo 2 815 02DS/MB/MW

  • Page 1 128, av. du Maréchal-de-Lattre-de-Tassigny - 87045 LIMOGES Cedex Tel: 33(0)5 55 06 87 87 - Fax: 33(0)5 55 06 88 88 www.legrand.com Mallia Senses with Netatmo Cat. No(s): 2 815 02DS/MB/MW - 2 815 04DS/MB/MW 2 815 06DS/MB/MW Connected switches with neutral...
  • Page 2 8. STANDARDS AND APPROVALS Compliant with installation and manufacturing standards. See e-catalogue. The undersigned, LEGRAND, declares that the radio-electric equipment RESET button type (2 815 02DS/MB/MW - 2 815 04DS/MB/MW - 2 815 06DS/MB/MW) used to return to factory settings complies with directive 2014/53/EU.
