Electrical Connector Terminal Wiring and Pinout
4-Pin Bayonet
Environmental Rating IP67, Ordering Code -2
4-20 mA
Voltage
Pin No.
Output
Output
A
V+
V+
B
V-
Common
C
Output
D
6-Pin Bayonet
Environmental Rating IP67, Ordering Code -3
4-20 mA
Voltage
Pin No.
Output
Output
A
V+
V+
B
V-
Common
C
Output
D
E
F
DIN EN 175301-803 Form C
Environmental Rating IP65, Ordering Code -7, -70
4-20 mA
Voltage
Pin No.
Output
Output
1
V+
V+
2
V-
Common
3
Output
4
M12x1 (4-Pin)
Environmental Rating IP67, Ordering Code -25
4-20 mA
Voltage
Pin No.
Output
Output
1
V+
V+
2
3
V-
Common
4
Output
Integral Cable
Environmental Rating IP67: Ordering Code -16, -36
Environmental Rating IP65: Ordering Code -17
4-20 mA
Voltage
Cable Color
Output
Output
Brown
V+
V+
Blue
V-
Common
Black
Output
Drain (bare)
Shield
Shield
