NOSHOK King-Gage 5800 Series Installation And Operation Instruction Manual

"intelligent" pressure & level transmitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ES3 Installation and Operation
Instructions Manual
"Intelligent" Pressure & Level Transmitter
EX-1861
58 Series
WARNING
Read the recommendations and warnings in this manual before the instrument is
installed. For personal safety, optimal use and maintenance of the KING-GAGE 5800
Series ES3 Transmitter, these instructions should be studied carefully.
KING-GAGE, A NOSHOK Company I 1010 West Bagley Road, Berea, Ohio 44017 I Ph: 855-367-2494 I www.king-gage.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the King-Gage 5800 Series and is the answer not in the manual?

Questions and answers

Related Manuals for NOSHOK King-Gage 5800 Series

Summary of Contents for NOSHOK King-Gage 5800 Series

  • Page 1 Read the recommendations and warnings in this manual before the instrument is installed. For personal safety, optimal use and maintenance of the KING-GAGE 5800 Series ES3 Transmitter, these instructions should be studied carefully. KING-GAGE, A NOSHOK Company I 1010 West Bagley Road, Berea, Ohio 44017 I Ph: 855-367-2494 I www.king-gage.com...
  • Page 2 ES3 "Intelligent" Pressure and Level Transmitter EX-1861 KING-GAGE, A NOSHOK Company The information contained in this manual was accurate at the time of release. Specifications are subject to change without notice. Warranty - All King Engineering products are guaranteed to be free from defects in material and workmanship for one year from the date of purchase.

  • Page 3: Table Of Contents

    ES3 "Intelligent" Pressure and Level Transmitter EX-1861 TABLE OF CONTENTS SECTION PAGE Introduction....................3 Dimensional Drawings ................3 Installing The Transmitter ................4 3.1 Mounting position ..................4 3.2 Mounting position effect ................4 3.3 Calibration ....................4 3.4 Connection Terminal ..................4 3.5 Wiring ......................4 Remaining ....................5 4.1 CE / EMC - Rules ..................5 4.2 Display and push buttons ................5 4.3 Display read out ..................5...

  • Page 4: Introduction

    EX-1861 1. INTRODUCTION KING-GAGE 5800 Series ES3 Transmitters are solid-state pressure and level transmitters using a piezoresistive silicon sensor with a very high burst pressure. The sensor element is mounted in a Stainless Steel foot. Inside the foot a temperature sensor is also mounted to provide active temper- ature compensation at the point of measurement, to minimize temperature and position error.

  • Page 5: Installing The Transmitter

    ES3 "Intelligent" Pressure and Level Transmitter EX-1861 3. INSTALLING THE TRANSMITTER The transmitter’s diaphragm is protected with a special protection cap. Protect the diaphragm until installation takes place. Do not damage the diaphragm. 3.1 MOUNTING POSITION When the transmitter is mounted horizontally, the cable gland must be pointed downwards. 3.2 MOUNTING POSITION EFFECT All transmitters are calibrated in vertical position (diaphragm points downwards).

  • Page 6: Remaining

    4.2 DISPLAY AND PUSH BUTTONS The KING-GAGE 5800 Series ES3 Transmitter has a high contrast display for optimal readout. The menu is controlled by 3 push buttons. Navigate with the up and down buttons through menus and measuring values.

  • Page 7: Explanation Programming Points

    ES3 "Intelligent" Pressure and Level Transmitter EX-1861 5 PUSH BUTTON FUNCTIONS PROGRAM NAME FUNCTION POINT P100 Menu-Exit menu Start and exit P101 ZERO value Zero adjustment (ZERO 4 mA) with or without test pressure P102 SPAN value Span adjustment (SPAN 20 mA) with or without test pressure P103 MOUNT correction Cancel mounting position effect...
  • Page 8 ES3 "Intelligent" Pressure and Level Transmitter EX-1861 3. Adjust the SPAN with the push buttons to 29 psi and push the button until save appears on the display. 4. The transmitter will return to the home screen. The span can also be adjusted to a real process situation. The transmitter will measure the pressure in an actual process.
  • Page 9 ES3 "Intelligent" Pressure and Level Transmitter EX-1861 OUTPUT SELECTION 4-20 mA or 20-4 mA Factory setting = 4 - 20 mA 1. Navigate to program point P105, and push the menu button to enter the menu. 2. Two choices appear on the screen: 4-20 and 20-4 3.
  • Page 10 ES3 "Intelligent" Pressure and Level Transmitter EX-1861 • The transmitter will return to the home screen. • Choosing Reset will put the transmitter back to factory setting (0.0 seconds). READOUT In this menu, the type of readout on the display can be adjusted. Factory Setting = Unit 1.
  • Page 11 ES3 "Intelligent" Pressure and Level Transmitter EX-1861 9. Five choices appear on the screen: Continuous = The Burst message is send continuously. Windowed = The Burst message is triggered when the measured value deviates more than the specified trigger value. Rising The Burst message is triggered when the measured value rises above the triggered value.
  • Page 12 ES3 "Intelligent" Pressure and Level Transmitter EX-1861 Page 12...
