DIGITAL PROPORTIONAL R/CSYSTEM
STANDARD CONFIGURATION LIST
Packaging box * 1, remote control * 1, receiver * 1;
Standard receiver: MC8RE-V2;
Compatible receivers: MC9002,MC6RE-V2,MC7RB-V2,MC3RB,MC4RB,MC6RE,
MC7RB,MC8RE,E6R-E,M-BUS.
MATTERS NEEDING ATTENTION
Beforestartingtousetheremotecontrol,carefullyreadthefollowingprecautions!
1. This product is not a toy and is not suitable for children under the age of 12, Adults should keep this product out of
reach of children and keep it out of reach of children Be careful when operating this product in the field.
2. Please do not use it in harsh weather conditions such as evenings, thunderstorms, snows, low energy levels, etc.
3. Do not use the remote control in snowy or watery places, if rainwater enters the remote control, the circuit will be
short-circuited and cannot be used.
4.Signal interference may cause the remote control to go out of control,places where interference affects more than
others are as follows:
A. Near the mobile phone signal transmission tower
B. Near high-voltage power lines and communication broadcasting antennas
C. Near the Military Radar Launch Tower
D. The complexity of wireless communication and the commercial path of mobile activities
E. Navigation domain
5. Please do not use this product after feeling tired, uncomfortable, drunk, or excited about drugs, otherwise it will
cause serious injury to oneself or others The value of is.
6. The 2.4G line band is completely different from the low-frequency line radio band previously used, Please ensure
that the model product is within your line of sight when using it Obstacles inside can block the signal from the power
line, causing the remote control and model to lose control.
7. Before using it, it is necessary to ensure that the remote control and model are installed correctly, and that all
steering gear actions and controls are in the same direction, otherwise it may cause damage to the model Severe
damage to the engine.
8. When the remote control distance continues to be too far, there is a possibility of losing control, Please shorten the
control distance appropriately; The battery voltage of the remote control is insufficient, transmitting The signal from the
machine can cause loss of control; So when the remote control "POWER" flashes and there is an alarm, please
replace the battery as soon as possible.
9. When stopping the remote control, be sure to cut off the power supply of the receiver and then turn off the remote
control; If the power to the remote control is turned off first, the receiver will still be on Operation may cause the model
to lose control or the engine to continue working, leading to serious accidents.
10.Improper use of the remote control may cause serious injury or even death to the operator or others; To ensure the
safety of you, others, and equipment, please be careful Read this guide and follow the instructions.
11.The remote control and receiver required for our company's 2.4G wireless transmission system are used in pairs,
while other company products cannot be connected to our company's products The product is of great value.
2.4GHz
FHSS
www.microzone.cn
