PRODUCT SPECIFICATIONS (continued)
Signal Input
RGB1 Input (D-sub 15-pin connector)
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
H. sync or H/V composite sync
14
15
Frame
RGB2 (DVI-D) Input
Pin

Input signal

1 T.M.D.S. Data2-
2 T.M.D.S. Data2+
3 T.M.D.S. Data2/4 Shield
4 T.M.D.S. Data4-
5 T.M.D.S. Data4+
6 DDC Clock
7 DDC Data
8 No Connect
9 T.M.D.S. Data1-
10 T.M.D.S. Data1+
11 T.M.D.S. Data1/3 Shield
12 T.M.D.S. Data3-
13 T.M.D.S. Data3+
S-input connector pin specifications
Pin Input signal
1 Y
2 Y-GND
3 C
4 C-GND
Frame GND
RS-232C connector pin specifications
Input signal
Pin
1 NC
2
RXDO
3 TXDO
4
NC
5
GND
6
NC
7 NC
8
NC
9
NC
GND
Frame
Input signal
R
G or sync on green
B
No connection
No connection
R .GND
G .GND
B.GND
No connection
GND
No connection
[SDA]
V.sync. [V.CLK]
[SCL]
GND
Pin Input signal
+5V Power
14
Ground (for+5V)
15
Hot Plug Detect
16
T.M.D.S. Data0-
17
T.M.D.S. Data0+
18
T.M.D.S. Data0/5 Shield
19
T.M.D.S. Data5-
20
T.M.D.S. Data5+
21
T.M.D.S. Clock Shield
22
T.M.D.S. Clock+
23
T.M.D.S. Clock-
24
Frame GND
Remarks
Received Data
Transmit Data
Singal Ground
5 4
10 9
15 14 13 12 11
• When different kinds of input signals are simultaneously input to
the monitor via a graphics board or the like, the monitor will
automatically select the signals in the following priority order:
Sync signal type
H/V separate sync.
H/V composite sync.
sync.on Green *
*Even in the case of the recommended signals shown on the
following page, there may be instances when correct display is not
possible. In this case, use H/V separate sync, or H/V composite
sync.
1 2 3 4
9 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
3
4
1 2
6
ViewSonic VPW4200/4210
3 2 1
8 7 6
Priority
1
2
3
5 6 7 8
1
2
3 4 5
7 8 9
34
