- Page 1 VPW4200 VPW4210 User Guide Guide de l'utilisateur Guía del usuario 42'' PLASMA DISPLAY...
-
Page 2: Table Of Contents
Reproduction of this manual in whole or in part without our prior written permission is prohibited. The product names mentioned in this manual may be trademarks or registered trademarks of their respective owners..17 ... 29 ... 23 ViewSonic VPW4200/4210... -
Page 3: For Your Records
Image Optimization files are also available free of charge at our web site. Go to www.viewsonic.com and select "Support. "If you do not have a ccess to the internet or if you require further assistance, contact "Customer Support" on page 37 Important : If this product will be wall mounted, be sure to record the serial number prior to mounting. -
Page 4: Important Safety Instructions
Please read it carefully and apply the knowledge you obtain from it to the proper operation of your ViewSonic Plasma monitor. Please fill out your warranty card and mail it to ViewSonic. This will enable ViewSonic to notify you promptly in the improbable event that a safety problem should be discovered in your product model. - Page 5 20. An outdoor antenna should not be located in the vicinity of overhead power lines or other electrical circuits. Disposal of this product may require specific instructions pertaining to your resident state. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance: www.eiae.org. ViewSonic VPW4200/4210...
-
Page 6: Features
The included remote control operates all display functions. Further, the on-screen display system, shows the status of the control settings in an easy-to-view fashion. Power saving system When connected to a VESA DPMS-compliant PC, the monitor cuts its power consumption while it is idle. ViewSonic VPW4200/4210... -
Page 7: Safety Instructions
• Do not put the plasma screen side up. • Do not cover the display with a tablecloth, etc. • Do not place the display on a carpet or bedding, or near a curtain. Disconnect the plug from the power outlet. Do not disassemble. ViewSonic VPW4200/4210... - Page 8 • If you observe a leakage of the batteries, wipe out the liquid and then replace the batteries. If you spill the liquid on your body or clothes, rinse well with water. • Obey the local laws when disposing the batteries. Surely connect the ground wire. ViewSonic VPW4200/4210...
- Page 9 Never use acid/alkaline detergent, alcoholic detergent, abrasive cleaner, powder soap, OA cleaner, car wax, glass cleaner, etc. as they could cause discoloration, scratches or cracks. Disconnect the plug from the power outlet. ViewSonic VPW4200/4210...
- Page 10 - Disposal of this product may require specific instructions pertaining to your resident region. - Never guess or take any chances with electrical equipment of any kind - it is better to be safe than sorry! ViewSonic VPW4200/4210...
- Page 11 - Connect the equipment into an outlet on a circuit different from where the receiver is connected. - Consult the dealer or an experienced radio / TV technician for help. Instructions to Users : This equipment complies with the requirements of FCC (Federal Communication Commission) regulations, provided that following conditions are met.
-
Page 12: Image Retention Prevention
écrans pendant de longues années. ViewSonic a pourvu ses écrans Plasma TV et moniteurs de fonctions permettant de réduire la rétention image et les images temporaires. Veuillez s il vous plaît vérifier dans... -
Page 13: Component Names
Handgrips External speaker terminals AUDIO 2 RGB input terminals e -control Remot receiver Power lamp Rear Handgrips terminals DIGITAL INPUT ANALOG AUDIO 1 RGB 2 RGB 1 RS-232C ViewSonic VPW4200/4210 External speaker... -
Page 14: Remote Control
• If the remote control begins to lack responsiveness, replace the batteries. • Strong light, such as direct sunlight, shining on the photoreceptor of the remote control can cause operational failure. Position this unit to avoid direct contact with such light. ViewSonic VPW4200/4210... -
Page 15: Installation Instructions
1) Using wood screws (two), fasten the set to the clamping screw holes on the rear of the stand as shown. 2) Using commercially available wood screws, secure the set firmly in position. 10cm (4 inches) or more Clamp Cord chain Hook Chain cord or chain Wall or Pillar clamp Wood Two places ViewSonic VPW4200/4210... -
Page 16: Connecting To Video Components
D-sub Component PC/STB (O: Available) Display rear panel Pr/Cr Pb/Cb Remarks Refer to P18 Refer to P18 480i Video Signal only 1080i/720P/480P/480i inputs. Refer to P18 Refer to P18 Refer to P18 ViewSonic VPW4200/4210... -
Page 17: Connecting To A Pc
RGB 2 RGB 1 RGB 1 RGB 2 3.5mm Stereo Audio cable DVI-D 15Pin D-Sub Connector connector To Video Output To Audio Output Speaker (L) SPEAKER TERMINAL (6 )10W RS-232C 9-Pin D-Sub RS-232C connector To PC 9-Pin RS-232C connector ViewSonic VPW4200/4210... -
Page 18: Power Cord Connection
(The type of plug is different from this drawing for some countries.) CAUTION • Use only the power cord provided. • Do not use a power supply voltage other than that indicated (AC100-240V, 50/60Hz) as this may cause fire or electric shock. ➀ ➁ ViewSonic VPW4200/4210... -
Page 19: Operating Instructions
ON, and the ON button on the remote control POWER button on the underside of the front of the frame is ON. When the main power switch is (Power Save) ON, and the PC is in power save mode. ViewSonic VPW4200/4210... -
Page 20: Selecting Av Input
• Muting can be cancelled by pressing the VOL+ button or the MUTE button while the audio is muted. AV3 YCbCr RGB2 DVI-D volume Volume setting value VOLUME Adjustment status guide display ) button is pressed ) button is pressed ViewSonic VPW4200/4210... -
Page 21: Use The Menu Screen
SHARPNESS SELECT: ENTER: ADJUST: RETURN: MENU AUDIO SETTING BASS TREBLE BALANCE SURROUND SELECT: ENTER: ADJUST: RETURN: MENU SELECT buttons to select the item to ADJUST buttons BRIGHTNESS CONTRAST COLOR COLOR TEMP FLESHTONE SHARPNESS SELECT: ENTER: ADJUST: RETURN: MENU ViewSonic VPW4200/4210... -
Page 22: Picture Parameters
Normally set to Cool. USER G USER B WARM NORMAL Set to ON for richer skin color. Normally set to the center position. Sharpens picture BRIGHTNESS CONTRAST COLOR TINT COLOR TEMP FLESHTONE SHARPNESS Setup hint imum visibility to suit the ambient ViewSonic VPW4200/4210... -
Page 23: Pc Parameters
Adjust the horizontal and vertical display positions. Increases bass. Adjust as desired. Increases treble. Adjust as desired. Increases left volume Adjust as desired. level. Creates a surround sound effect. BASIC ENHANCED AUTO CLOCK PHASE POSITION Setup hint BASS TREBLE BALANCE SURROUND Setup hint ViewSonic VPW4200/4210... -
Page 24: Picture In Picture
SMALL MEDIUM LARGE SPLIT PIP POSITION Setup hint Change PIP display position. Change PIP display Size. use the buttons to select the PIP setting. ViewSonic VPW4200/4210 PIP SIZE MULTI PIP... -
Page 25: Aspect
Note: For RGB1 VGA, RGB 2 DVI and AV4, you can select 4:3 and 16:9 aspect mode. ZOOM Each time the ZOOM button of the remote control is pressed, the image on the screen will be enlarged. There are 10 selections, Zoom 0(=Normal size) to Zoom 9. ASPECT ZOOM ViewSonic VPW4200/4210... - Page 26 PIP SOURCE AV1 VIDEO AV1 S-VIDEO AV2 VIDEO AV2 S-VIDEO AV3 YCbCr AV4 YPbPr/YCbCr RGB1 VGA RGB2 DVI-D (continued) SELECT SMALL MEDIUM LARGE select keys on the remote control. Then, press the LARGE SPLIT SPLIT PIP-OFF ENTER button. ViewSonic VPW4200/4210 SOURCE...
- Page 27 ADJUST button and press ENTER button, then following menu will appear. Sub Source RGB2 VIDEO S-VIDEO VIDEO PIP SOURCE AV1 VIDEO AV1 S-VIDEO AV2 VIDEO AV2 S-VIDEO AV3 YCbCr AV4 YPbPr/YCbCr RGB1 VGA RGB2 DVI-D YPbPr/ YCbCr S-VIDEO YCbCr ViewSonic VPW4200/4210...
-
Page 28: Multi Pip
PIP(1+12) ADJUST button. ADJUST buttons. PICTURE IN PICTURE PICTURE IN PICTURE ADJUST button. SELECT buttons. PIP(1+8) PICTURE IN PICTURE PIP POSITION PIP SIZE MULTI PIP PIP POSITION PIP SIZE MULTI PIP PIP (1+12) PIP (1+8) PIP (1+3) PIP(1+3) ViewSonic VPW4200/4210... -
Page 29: General Setting
Setup hint Display Registration condition PIP POSITION 1 setting is registered. PIP SIZE MULITI PIP OSD POSITION OSD TIMEOUT OSD LANGUAGE SLEEP TIMER I/P INFO 1 setting is registered. FACTORY RESET SCREEN SAVER SCREEN WIPE STANDBY WHITE INVERSE ViewSonic VPW4200/4210... -
Page 30: Signal Check
Recheck the personal computer power switch status and the connection status. Recheck the input signal specifications. Active (normal display) Blank (no display) Lights green Lights orange 310W 3W or less (RGB1,RGB2) RGB2 DVI-D ! No Sync. Signal ! Invalid Scan Freq. ViewSonic VPW4200/4210... -
Page 31: Image Retention Of Plasma Display
Also, plasma displays are made of finely processed glass. A reinforced glass filter is installed over the pa nel surface but avoid strong impact because there is still danger of glass breakage. Fig. A Fig. a Fig. B Fig. b ViewSonic VPW4200/4210... -
Page 32: Troubleshooting
Adjust the clock phase till the desired clarity is obtained. (RGB input) Ensure that the batteries in the remote control are inserted with the correct polarity. Check to see that the batteries in the remote control are functional. Page ViewSonic VPW4200/4210... - Page 33 When set to PC mode, the luminance is lowered by about 10% than when set as Movie mode. This is not a malfunction. If you do not mind flicker on the display, please switch to Movie mode. ViewSonic VPW4200/4210 Page...
-
Page 34: Abnormal Displays Corrections Rgb1 Only
Some characters are blurred. After adjustment All characters appear crisp now. After adjustment All characters are blurred. Before adjustment Figure 3 After adjustment 9) Press without flickering. Before adjustment After adjustment ADJUST buttons to make the text appear ViewSonic VPW4200/4210... -
Page 35: Product Specifications
AV4 : 480i , 480p , 1080i/60 , 720p/60 Video output Signal OUTPUT (MONITOR): composite video monitor-output terminal (RCA) OUTPUT (MONITOR): L/R audio monitor- output terminal (RCA) Recommended signal 5 modes • It takes at least 30 minutes to attain the maximum picture quality. ViewSonic VPW4200/4210... -
Page 36: Component Connection
Remarks Received Data Transmit Data Singal Ground 15 14 13 12 11 Priority H/V separate sync. H/V composite sync. sync.on Green * 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 ViewSonic VPW4200/4210... -
Page 37: Recommended Signal List
57.28 80.00 100.00 81.00 94.760 89.50 Dot clock frequency (MHz) 31.47 25.18 31.47 25.18 31.47 34.24 37.86 31.50 37.50 31.50 43.27 36.00 35.16 36.00 37.88 40.00 48.08 50.00 46.88 49.50 53.67 56.25 48.36 65.00 56.48 75.00 60.02 78.75 ViewSonic VPW4200/4210... - Page 38 59.94 60.00 60.00 Horizontal Vertical frequency (kHz) frequency (Hz) 59.94 15.734 Horizontal Vertical frequency (kHz) frequency (Hz) 15.734 Horizontal Vertical frequency (kHz) frequency (Hz) 15.734 31 .47 33.75 44.96 31.47 27.00 45.00 74.25 33.75 74.25 Remarks Remarks Remarks ViewSonic VPW4200/4210...
-
Page 39: Appendi X
F: +61 2 9906 6377 viewsonic.com T: 65 273 4018 service@sg. F: 65 273 1566 viewsonic.com T: 886 2 2246 3456 service@sd. F: 886 2 8242 3668 viewsonic.com T: 886 2 2246 3456 service@hk. F: 886 2 8242 3668 viewsonic.com ViewSonic VPW4200/4210... -
Page 40: Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will at its sole option repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components. -
Page 41: Power Cord Safety Guidelines
If you have any questions concerning which proper power cord to use, please consult with the dealer from whom you have purchased the product. Switzerland ...SEV Britain...BASE/BS Japan...Electric Appliance Control Act Maximum Current Rating of Unit 10 Amps 12 Amps 12 Amps 10 Amps 12 Amps ViewSonic VPW4200/4210... -
Page 42: Cleaning And Maintenance
Trademark Credits VGA is a trademark of IBM Corporation. Macintosh is a registered trademark of Apple Computer Corporation. SVGA is a registered trademark of the Video Electronics Standard Association. All other trademarks are the properties of their respective owners. ViewSonic VPW4200/4210... -
Page 43: Fcc Information
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Warning To assure continued FCC compliance, the user must use grounded power supply cord and the provided shielded video interface cable with bonded ferrite cores. - Page 44 ViewSonic Corporation...
