Service Manual
This service information is designed for experienced repair technicians only and is not designed for use by
the general public. It does not contain warnings or cautions to advise non-technical individuals of potential
dangers in attempting to service a product. Products powered by electricity should be serviced or repaired
only by experienced professional technicians. Any attempt to service or repair the product or products dealt
with in this service information by anyone else could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are
marked by
in the Schematic Diagrams, Exploded Views and Replacement Parts List. It is essential
that these critical parts should be replaced with manufacturer's specified parts to prevent shock, fire
or other hazards. Do not modify the original design without the manufacturer's approval.
Please have a static electricity depletion process in place before handling these components.
Please use gloves when handling PCB parts during the repair process.
CONTENTS
1.Specification
2.Parts Identification
3.Wiring Diagram
4.Parts List
FV-0511VQC1
WARNING
IMPORTANT SAFETY NOTICE
PESMX1710002CE
Version:1902
Ventilating Fan
(North America Market)
.
.
PAGE
1
2 ~ 4
5
6 ~ 7
Advertisement
Table of Contents
Related Manuals for Panasonic FV-0511VQC1
Summary of Contents for Panasonic FV-0511VQC1
- Page 1 Service Manual Ventilating Fan (North America Market) FV-0511VQC1 WARNING This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
-
Page 2: Specification
(Hz) (sones) (rpm) lb. (kg) (Inches) (CFM) < 0.3 FV-0511VQC1 Exhaust 4 or 6 < 0.3 9.5 (4.3) < 0.3 10.8 HVI Certified performance based on HVI Procedures 915, 916, and 920. Remark: We divide this model into Version A & Version B, because of different motor and Main PCB Section, please put attention with identification of parts when you request a service parts. -
Page 3: Parts Identification
2. Parts Identification FV-0511VQC1 Main Body Section Name Plate 22 A 22 B 80501 80501M New Motor New PCB (3pcs) 7 A / 7 B (5pcs) (2pcs) 12 A / 12 B Main PCB Section (2pcs) - Page 4 2. Parts Identification FV-0511VQC1 Main PCB Section (3pcs) Main Label Part for Version A Part for Version B 80501 80501M 8 Means Year: 2018 8 Means Year: 2018 05 Means Month 05 Means Month 01 Means Day 01 Means Day...
- Page 5 2. Parts Identification FV-0511VQC1 Packing Section...
- Page 6 Fan body Junction box White Neutral Main control circuit AC120V 60Hz Live (Fan) Black (Power supply) Motor Main control Humidity sensor circuit Selector (Ground wire) Green Motion sensor Humidity Timer setting WHITE Conduit BLACK GREEN Junction Ground wire Wire nuts Switch box Neutral 120 VAC...
-
Page 7: Parts List
4. Parts List FV-0511VQC1 Main Body Section Part No. Part Name Q'ty Remark FFV11QCL1900C Frame Assembly FFV11VQC1910 Adapter Assembly FFV08VKS3M915 Connector Plate FFV11QCL1331 Earth Lead Wire FFV11QCL1301A Connector Assy FFV11QCL1912A Junction Cover 7A FFV11QCL1M20A Motor Version A 7B FFV11QCL1M21AX Motor... -
Page 8: Main Label
4. Parts List FV-0511VQC1 Main Label Part No. Part Name Q'ty Remark 20 FFV11QCL1011A Switch Label 21 FFV11QCL1012A CFM Label 22A FFV11VQC1050 Name Plate Version A 22B FFV11VQC1050M Name Plate Version B 23 FFV0810011S Caution Label 1 24 FFV0810010S Caution Label...
