LOV TO ELECTRIC S.P. .
24020 GORLE (BERG MO) IT LI
VI DON E. M ZZ , 12
TEL. 035 4282111
L
E
E-mail info@
ovato
lectric.com
L
E
Web
www.
ovato
lectric.com
NOTE: THE REL TIVE INSTRUCTIONS M NU L, DEDIC TED TO E CH DEVICE, IS V IL BLE IN V RIOUS L NGU GES IN DOWNLO DS T THE GLOB L WEBSITE WWW.LOV TOELECTRIC.COM.
NOT : IL M NU LE OPER TIVO, DEDIC TO D OGNI DISPOSITIVO, È DISPONIBILE IN DIVERSE LINGUE ONLINE NELL SEZIONE DOWNLO DS LL'INDIRIZZO WEB WWW.LOV TOELECTRIC.COM.
W RNING!
– Carefully read the manual before the installation or use.
– This equipment is to be installed by qualified personnel, complying to current standards, to avoid
damages or safety hazards.
– Remove the dangerous voltage from the product before any maintenance operation on it.
– The manufacturer cannot be held responsible for electrical safety in case of improper use of the
equipment.
– Products illustrated herein are subject to alteration and changes without prior notice. Technical data
and descriptions in the documentation are accurate, to the best of our knowledge, but no liabilities for
errors, omissions or contingencies arising therefrom are accepted.
– Clean the instrument with a soft dry cloth, do not use abrasives, liquid detergents or solvents.

INTRODUCTION

EXP expansion modules are designed and developed to enhance the functions of connectivity, I/O,
memory and analysis of the device to which it is connected.
The EXP10 14 implements the isolated PROFIBUS® serial interface. This module can be connected to a
Lovato Electric device equipped with EXP slot. The connection is done simply by plugging it into the
expansion slot of the base device. Which will automatically recognise it. The EXP parameters setup will
be done directly from the proper device menu in an easy way.

DESCRIPTION

– Compact size
– Direct plug in on the base device
– 2KVrms for 1 minute of insulation from the base module
®
– PROFIBUS
DP slave, up to 12M
– Max number of exchange bytes 18 INPUT 34 OUTPUT
uto Baudrate (9,600-19,200-45,450-93,750-187,500-500,000-1.5M-3M-6M-12M bps)
– Standard 9-pin D-sub female connector
– File .GSD download available (www.lovatoelectric.com).
LOV TO PRODUCTS COMP TIBILITY
EXP10 14 can be connected to a Lovato Electric product fitted by EXP receptacle slot. Verify the
compatibility with the following table:
B SE DEVICE
B SE DEVICE FW REV.
≥ 01
TL610
≥ 01
TL800
≥ 00
DMG7000
≥ 00
DMG7500
≥ 00
DMG8000
≥ 00
DMG9000
≥ 07
DCRG8
GB EXP NSION MODULE PROFIBUS
Installation manual
I
MODULO DI ESP NSIONE INTERF CCI PROFIBUS
Manuale di installazione
EXP10 14
®
DP INTERF CE
®
DP
TTENZIONE!!
– Leggere attentamente il manuale prima dell'utilizzo e l'installazione.
– Questi apparecchi devono essere installati da personale qualificato, nel rispetto delle vigenti normative
impiantistiche, allo scopo di evitare danni a persone o cose.
– Prima di qualsiasi intervento sull'apparecchio, togliere tensione dagli ingressi di alimentazione e dalle
uscite relè dove presenti.
– Il costruttore non si assume responsabilità in merito alla sicurezza elettrica in caso di utilizzo
improprio del dispositivo.
– I prodotti descritti in questo documento sono suscettibili in qualsiasi momento di evoluzioni o di
modifiche. Le descrizioni ed i dati a catalogo non possono pertanto avere alcun valore contrattuale.
– Pulire lo strumento con panno morbido, non usare prodotti abrasivi, detergenti liquidi o solventi.
INTRODUZIONE
I moduli di espansione EXP... sono stati progettati e sviluppati per potenziare le funzioni di connettività,
I/O, memorizzazione ed analisi dello strumento base a cui vengono collegati. In particolare il modulo
EXP10 14 realizza la funzione di interfaccia seriare isolata di tipo PROFIBUS®. Questo modulo può
essere collegato ad un apparecchio Lovato Electric provvisto di slot per EXP. La connessione avverrà
semplicemente inserendo il modulo di espansione nello strumento principale il quale ne effettuerà
automaticamente il riconoscimento.
L'impostazione dei parametri del modulo viene svolta in modo intuitivo e semplice nel menù di
configurazione presente nel dispositivo principale.
DESCRIZIONE
– Dimensioni compatte.
– Inserimento diretto nello slot di espansione dell'apparecchio.
– Isolamento da 2kVrms per 1minuto dall'apparecchio base.
®
– PROFIBUS
DP slave fino a 12M.
– Massimo numero di byte di scambio 18 INPUT 34 OUTPUT.
uto Baudrate (9.600-19.200-45.450-93.750-187.500-500.000-1.5M-3M-6M-12M bps)
– Connettore standard D-sub 9 poli femmina.
– Download del file .GSD disponibile (www.lovatoelectric.com).
COMP TIBILITÀ CON I PRODOTTI LOV TO
Il modulo EXP10 14 può essere abbinato ad un prodotto Lovato Electric provvisto di alloggiamento per
espansione EXP. Verificare la compatibilità secondo la seguente tabella:
PP RECCHIO B SE
REV. SW PP RECCHIO B SE
≥ 01
TL610
≥ 01
TL800
≥ 00
DMG7000
≥ 00
DMG7500
≥ 00
DMG8000
≥ 00
DMG9000
≥ 07
DCRG8
1
