Roland S-550 Service Notes

JAN. 1988
S-550
S-B5D
SERVICE
NOTES
First
Edition
SPECIFICATIONS
DISK DRIVE
3.5" Micro Floppy
Disk Drive
:
Double density Double Track (2DD)
SAMPLING SYSTEM
Sampling Rate
:
30KHz/15KHz
Data
Format
:
12bits Linear
D/A Converter
:
16 bits
Sampling
Time
:
7.2sec x
4 (lA, IB, IIA, IIB)
@30KHz
Sampling
rate
:
14.4sec X 4 (lA, IB, IIA, IIB)
@15KHz
Sampling
rate
Wave
memory
:
384K
byte x 4
bank
INPUT MIC
:
-48dBm
LINE
:
— lOdBm
Recording Start Jack
:
OFF— SHORT
ON-OPEN
OUTPUT
MIX, 1—8
:
+2dBm
1
Voice
max
DISPLAY OUT
RGB TTL LEVEL HORIZONTAL
FREQ. 15.75KHz
MONOCHROME COMPOSITE
IV
P-P
EXT CONTROLLER
TTL LEVEL
DIMENSIONS
482 (W)
x400
(D)
x88
(H)
mm
19"
X 15-3/4" X
3-7/16"
WEIGHT
7.7Kg/17
lb.
POWER CONSUMPTION
32W
ACCESSORIES
Connection Cord (PJ-1)x
1
MIDI
Cable
1m
x
1
System Disk x 2\
in a set
Utility
Disk x
1
j
two
Mouse (MU-1)
Owner's manual
Guide Book
for
MIDI
(Part No. 23430675S0)
(Part No.
23485167)
(Part No.
22403129)
(Part No. 22433515)
OPTION
Remote
Controller
;
RC-100
RGB
Connection
Cable:
RGB
251 For 9 pin sub
RGB
Connection Cable:
RGB 25N
For 8 pin square
Pedal
Switch
DP-2,
BOSS FS-5U
3.5" Micro Floppy Disk
MF2DD
Sound
Library Disks L-501 to 509
I
Roland
(2nd
Printing
Nov.
1
988
B-2)
Printed
in
Japan BA-2LH
1
