User manual
Dishwasher
GS643D60W
GS643D60X

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GS643D60W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gorenje GS643D60W

Summary of Contents for Gorenje GS643D60W

  • Page 1 User manual Dishwasher GS643D60W GS643D60X...

  • Page 2: Table Of Contents

    Contents Your dishwasher ........................Safety instructions ........................Automatic child lock - CL ......................Child lock - CL ......................... Installation ..........................Overflow guard ......................... Packaging ..........................Disposal ............................ Symbols on the appliance ......................Before washing for the first time ................... 1. Water hardness ........................2.
  • Page 3 Troubleshooting ........................Installation ..........................Safety instructions ........................Transport protection for the door ..................... Placing the dishwasher ......................Adjust the height and slide the dishwasher into place ............. Drainage connection ......................... Connection to water supply ...................... Electrical connection ......................... Fit the sound insulation ......................Remove dishwasher worktop ....................

  • Page 4: Your Dishwasher

    Your dishwasher Install the dishwasher, see the chapter Installation. Press The first time the dishwasher is switched on, it is important that you choose the right settings to ensure good dishwashing results. See the chapter Before washing for the first time. On/Off Start/Pause/Stop Select program...

  • Page 5: Safety Instructions

    Safety instructions Read the user manual and keep it in a safe place! Number of standard place settings: 16 Never use the dishwasher for any purpose other than that specified in these operating instructions. Do not load the dishwasher door or dishwasher baskets with anything other than dishes.

  • Page 6: Automatic Child Lock - Cl

    WARNING! Children must be supervised – dishwasher detergent is corrosive! Automatic child lock - CL You can activate the Automatic child lock setting to prevent children from starting the dishwasher. See the chapter Settings. CL (Child Lock) will be shown on the display when pressing the control panel.

  • Page 7: Symbols On The Appliance

    Symbols on the appliance Read the user manual. Recycle as electrical waste. Approved in accordance with the relevant EU directives. Approved in accordance with the relevant UK legal requirements.

  • Page 8: Before Washing For The First Time

    Before washing for the first time 1. Water hardness In order to achieve good dishwashing results, the dishwasher needs soft water (water with low mineral content). Hard water leaves a white coating on dishes and the dishwasher. Checking water hardness Water hardness is specified using German degrees of water hardness (°dH), French degrees of water hardness (°fH), English degrees of water hardness (°eH) or millimoles per litre (mmol/l).

  • Page 9: Basic Settings

    2. Basic settings The first time the dishwasher is switched on, it is important that you choose the right settings to ensure good dishwashing results. See page 19. Set up: Rinse aid Water hardness TAB (All-in-one detergent) Top up with rinse aid Drying is faster and a better result is achieved Lift up to open if you use rinse aid.

  • Page 10: Greener Dishwashing

    Greener dishwashing Save energy and water When using a dishwasher in a residential setting, less energy and water are generally used compared to washing the dishes by hand. Do not rinse under running water Do not rinse the dishes under running water as this will lead to increased energy and water consumption. Simply scrape off large food particles before loading the dishwasher.

  • Page 11: Loading The Dishwasher

    Loading the dishwasher Fragile dishes Some cookware is not dishwasher safe. This can be for several reasons. Some materials cannot withstand high heat, others can be damaged by dishwasher detergent. Exercise caution with, for example, handmade items, fragile decoration, crystal/glassware, silver, copper, tin, aluminium, wood and plastic.

  • Page 12: Upper Basket

    Upper basket Place glasses, cups, bowls, side plates and saucers in the upper basket. All dirty surfaces should face inwards and downwards! Wine glasses are placed on the wine glass shelf and knives are placed in the knife stand on the right. 3 positions Knife stand Raising and lowering the upper basket...

  • Page 13: Lower Basket

    Lower basket Place plates, side plates, serving dishes and pots in the lower basket. Cutlery can be placed in the cutlery holder. Fit the cutlery holder to achieve maximum loading capacity. (Found inside the enclosed plastic bag.) Adjustable plate supports The adjustable plate supports can be folded down to make it easier to load pots and bowls.

  • Page 14: Using The Dishwasher

    Using the dishwasher Add detergent Follow the instructions on the detergent packaging. This dishwasher is fitted with a water softener, so use detergent and rinse aid doses suitable for soft water. Too much detergent can result in less effective dishwashing and also entails greater environmental impact.

  • Page 15: On/Off

    On/Off Start/Pause/Stop Select program Display NOTE! The control panel only reacts to use when the door is closed. On/Off Close the door properly, otherwise the dishwasher will not start. Press . Also turn on the water tap if it is turned off. Select program Select a program to suit the type of dishes and how dirty they are.

  • Page 16: Select Option

    Intensive 70° A program with a high temperature for dissolving grease on very dirty dishes, such as pans, casserole dishes and oven dishes. If these dishes do not completely fill the dishwasher, you can add plates and other dishes. Glass 40° A gentle dishwashing program with a low temperature for washing fragile items made of crystal/glass.

  • Page 17: If You Want To Load More Dishes

    Stopping or changing a program Press and hold for three seconds to pause the program. If you want to interrupt or change the program after starting the dishwasher, press and hold for another five seconds. Open the door and top up with new detergent if the lid of the detergent dispenser has opened. Close the door.

  • Page 19: Settings

    Settings 1. Press 2. To open the dishwasher's settings menu, press and hold until SEt is shown on the display. 3. Press to step through the settings menu. 4. Press to step through the alternatives. 5. Confirm the selected setting by pressing 6.
  • Page 20 Settings Alternatives Water hardness 4:00 - 4:09 Adjusting the water softener. Select a setting depending (4:00 Off) on the hardness of the water supply. It is important that this setting is correct! See 1Water hardness in the chapter Before washing for the first time.

  • Page 21: Care And Cleaning

    Care and cleaning Top up with rinse aid When the rinse aid needs topping up, the above symbol lights on the display. Lift up to open Press to close 1. Open the rinse aid compartment lid. 2. Carefully top up with rinse aid to the level marked MAX. 3.

  • Page 22: Clean The Filter

    Clean the filter The filter traps larger food particles, which cannot get past the drainage pump. Empty the filter when necessary. It should be cleaned at regular intervals depending on how often the dishwasher is used. 1. Turn the locking ring anticlockwise and lift the filter straight up. 2.

  • Page 23: Clean The Outside Of The Dishwasher

    Lower spray arm Pull the lower spray arm straight up to release it. Clean the outside of the dishwasher Door and door seal Open the door. Clean the sides of the door and the door seal regularly with a slightly damp cloth. Clean the door seal at the lower front edge of the dishwasher with a washing-up brush.

  • Page 24: Winter Storage/Transport

    7. Plug the machine in again. Drainage pump stop NOTE! Do not forget to refit the drainage pump stop. Unblocking the inlet hose filter If the water supply contains small particles, the outer filter on the inlet hose may become blocked, which results in the Water inlet fault error message.

  • Page 25: Troubleshooting

    Troubleshooting Error messages Action Overfilling water Unblocking the drainage pump. See the chapter Care and cleaning. If the problem persists, contact your nearest service centre. Water outlet fault See "Water remains in the dishwasher" under "Problem" in the table below. If the problem persists, contact your nearest service centre.
  • Page 26 Problem Possible causes Action The door lock does not click in- Check the door lock. If it does to place and lock. not click into place and lock, open the door. Press and hold until the display starts counting down. Wait until the countdown ends (60 seconds).
  • Page 27 Problem Possible causes Action Dishes loaded incorrectly. Do not cover porcelain with large bowls or the like. Avoid placing very tall glasses in the corners of the baskets. See the chapter Loading the dishwash- Glasses and cups have toppled Place dishes to sit steady. over during the program.
  • Page 28 Problem Possible causes Action The dishes have a sticky Rinse aid dosage setting too Reduce the dosage. See the white/blue film. high. chapter Settings. If you have very soft water, you may want to dilute the rinse aid 50:50 with water.
  • Page 29 Problem Possible causes Action Grease deposits in the dish- Low temperature programs Select a program with a high washer. have been selected for a pro- temperature to dissolve grease longed period. on very dirty dishes, such as In- tensive 70°. Or run a self-clean- ing program.

  • Page 30: Installation

    Installation Nominal dimensions. Actual measurements may vary. [mm] Safety instructions Connections to electricity, water and drainage must be performed by a qualified professional. Always follow applicable regulations for water, drainage and electricity. Take care during installation! Wear protective gloves! There must always be two people! Place a drip tray on the floor beneath the dishwasher to prevent damage from any water leaks.

  • Page 31: Adjust The Height And Slide The Dishwasher Into Place

    Adjust the height and slide the dishwasher into place 24 mm Freestanding Make sure the area on which the dishwasher is to be installed is firm. Adjust the dishwasher's height using the four feet so that the dishwasher is level. Also check that the dishwasher door can be opened freely and is centred in the tub opening.

  • Page 32: Drainage Connection

    Drainage connection min. 14 mm max. 950 mm min. 350 mm The drainage hose may be extended by a maximum of 3 m (the total length of the drainage hose must not exceed 4.5 m). Any joints and connecting pipes must have an internal diameter of at least 14 mm. No part of the drainage hose may be more than 950 mm above the bottom of the dishwasher.

  • Page 33: Electrical Connection

    Connection to hot water supply Connect the dishwasher to the hot water supply (max. 70 °C) if the building is heated using an energy-efficient means such as district heating, solar power or geothermal power. Choosing a hot water connection reduces the dishwasher's energy consumption. NOTE! Do not exceed the permitted water supply temperature.

  • Page 34: Service

    Read the chapter Troubleshooting before contacting the service centre. If you have encountered a problem that you cannot resolve, please contact your nearest service centre for professional help, see www.gorenje.com. Our website also has information about spare part availability and what you can repair yourself.

  • Page 35: Technical Data And Energy Labelling

    2) In accordance with the EN 60436 standard. Information for consumers Information about your appliance can be found at www.gorenje.com. You can also find information in the EU Product Registration database for Energy Labelling, EPREL. Scan the QR code on the energy label supplied with the dishwasher (or go to https://eprel.ec.europa.eu and search for the model name).
  • Page 36 873419-a6 We reserve the right to make changes.
