HMI Panel Drawings

6. HMI Panel Drawings

6.1. Connectors

1
Pos Connector
1 Power supply
2 USB
3 LAN A
4 LAN B
5 COM

6.1.1. Communication Ports

Pin
COM 1
1
2 RS-232 RxD
3 RS-232 TxD
4
5 GND
6
7 RS-232 RTS
8 RS-232 CTS
9
The connector supports up to three independent communication channels and can be configured for
RS-232 and RS-422 or 2x RS-485 or 1x CAN.
2024-01
2
+24 V DC (18–32 V DC)
USB Host 2.0, max output current 500mA
1×10/100 Base-T (shielded RJ45)
1×10/100 Base-T (shielded RJ45)
Serial communication port
D-sub-9, female
COM 2
RS-422 Tx+
RS-485 Tx+/Rx+
RS-422 Rx+
GND
RS-422 Tx-
RS-485 Tx-/Rx-
RS-422 RX-
18
3 4
Description
COM 3
RS-485 Tx+/Rx+
GND
RS-485 Tx-/Rx-
Beijer Electronics, MAEN365
5
CAN 1
CAN 1-H
GND
CAN 1-L
