Technical Data - Beijer Electronics X2 pro 10 web Hardware And Installation Manual

Technical Data

4. Technical Data
Parameter
Front panel, W×H×D
Cutout dimensions, W×H
Mounting depth
Standalone mounting
Front panel seal
Rear panel seal
Touch screen material
Frame overlay
Touch screen operations
Reverse side material
Frame material
Weight
CPU
Serial ports
Ethernet LAN A
Ethernet LAN B
USB
External storage media
Flash memory
(application memory)
Memory RAM
NVRAM
LED
Real time clock
Battery
2024-01
292 × 194 × 7 mm
275 × 177 mm
45 mm (145 mm including clearance)
VESA 75 × 75
Note: Maximum screw length for VESA mounting is 4 mm. Usage of
longer screws may lead to damage.
IP 65
IP 20
Polyester on glass, ITO film, resistive
Autoflex EBA 180L
1 million finger touch operations
Powder-coated aluminum
Powder-coated aluminum
1.65 kg
i.MX6Quad
Quad ARM Cortex-A9
1.0 GHz
1 MB L2 cache
StandardD-sub (9 Pin, female)
COM1: RS-232 with RTS/CTS
COM2: RS-422/RS-485
COM3: RS-485
1×RS-232 Rx/Tx with RTS/CTS and 1×RS-422 or 2×RS-485 or 1x CAN
2.0B.
10/100 Mbit Base-T (shielded RJ45 with LEDs)
10/100 Mbit Base-T (shielded RJ45 with LEDs)
2 × USB Host 2.0, max output current 500 mA
Supports up to USB 2.0 High Speed
1 × SD card
8 GB SSD (eMMC)
2 GB (DDR3)
N/A
1 × Multi color
Yes
BR 2032 lithium battery
replaceable
14
X2 pro 10 web
Beijer Electronics, MAEN365
