- Page 1 User Manual HDP43XX/44XX Series programmable DC power supply V 1.1...
-
Page 2: Copyright Statement
Qingdao Hantek Electronic Co., Ltd. Statement Qingdao Hantek Electronic Co., Ltd. reserves the right to amend this document without prior notice. Qingdao Hantek Electronic Co., Ltd. promises that the information provided is correct and reliable, but does not guarantee that this document is infallible. Please make sure that the specifications of relevant technical documents used are the latest and valid version yourself before using this product. -
Page 3: Technical Support
User Manual Technical Support If you have any question or ambiguity in the process of using products of Qingdao Hantek Electronic Co., Ltd., you can get the service and support through the following ways: A: Please contact the local dealer of Qingdao Hantek Electronic Co., Ltd.;... -
Page 4: Summary Of General Safety Matters
User Manual Summary of general safety matters General Safety Summary Read the following safety precautions carefully to avoid injury and prevent damage to this product or any product connected to this product. To avoid possible danger, be sure to use this product as specified. -
Page 5: Safety Terms And Symbols
User Manual Only use fuses specified for this product. Avoid exposed circuits. Do not touch exposed connectors and components after power is turned on. Do not operate the product if you suspect it is malfunctioning. If the user suspects that this product has been damaged, have it inspected by qualified service personnel. -
Page 6: Ventilation Requirements
User Manual Safety Warning Protective Test Ground Shell Earth Terminal Ventilation requirements Make sure that the exhaust area is not blocked and has free flowing air. To ensure adequate ventilation, when using the power supply in a workbench or rack, make sure that there should be a gap of at least 10 cm on both sides, above, and behind it. -
Page 7: Equipment Recycling
User Manual CAUTION To avoid damaging the oscilloscope or probe, do not place it in mist, liquid or solvent. Clean According to the requirements of operating conditions, check the oscilloscope and probe frequently. Please clean the outer surface of the instrument according to the following steps: Use a lint-free cloth to remove dust from the outside of the oscilloscope and probe. -
Page 8: Table Of Contents
User Manual Contents COPYRIGHT STATEMENT ........................2 TECHNICAL SUPPORT ..........................3 SUMMARY OF GENERAL SAFETY MATTERS ................... 4 General Safety Summary ............................4 Safety terms and symbols ............................5 Ventilation requirements ............................6 Working environment ..............................6 Daily maintenance and cleaning ..........................6 Equipment recycling .............................. - Page 9 User Manual Steps to replace the fuse: ............................. 21 CHAPTER 3 FUNCTION INTRODUCTION ....................22 1. Output voltage and current ...........................22 Setting steps: ................................23 2. Over protection ..............................23 3. 2-Wire/4-Wire ...............................23 4. Channel delay ................................24 5. Output coupling ..............................25 6.
- Page 10 User Manual 11.5 Capture ................................43 12. Lock/Unlock .................................44 CHAPTER 4 TROUBLESHOOTING ......................45 CHAPTER 5 PERFORMANCE INDEX ...................... 46...
-
Page 11: Hdp43Xx/44Xx Series Dc Programmable Power Supply Introduction
User Manual HDP43XX/44XX Series DC Programmable Power Supply Introduction HDP43XX/44XX is a programmable DC power supply. It has a user-friendly interface design, excellent performance indicators, a variety of communication interfaces to meet the different needs of users, and a variety of analysis functions to meet the diverse needs of users. -
Page 12: Model List
User Manual Model List minimum Model Chanel 4Wire Interface resolution HDP4324 USB、Digital I/O、LAN 1mV/1mA HDP4424 USB、Digital I/O、LAN 1mV/1mA HDP4324B USB、Digital I/O、LAN、RS232/485 1mV/1mA HDP4424B USB、Digital I/O、LAN、RS232/485 1mV/1mA √ HDP4324S USB、Digital I/O、LAN、RS232/485 0.1mV/1μA √ HDP4424S USB、Digital I/O、LAN、RS232/485 0.1mV/1μA USB、Digital I/O、LAN、RS232/485、 √ HDP4324SH 0.1mV/1μA GPIB USB、Digital I/O、LAN、RS232/485、... -
Page 13: Chapter 1 Quick Start
User Manual Chapter 1 Quick Start Taking the three-channel power supply as an example, this chapter will briefly describe and introduce the front panel, rear panel, user interface, help system, and precautions when using the instrument for the first time. In this way, users can become familiar with this series of power supplies in the shortest possible time. -
Page 14: Front Panel Introduction
User Manual 2. Front Panel Introduction 1. LCD Display screen 2. Restore default settings 3. Help Used to quickly get relevant help on the use of the instrument. 4. USB Host Used for firmware upgrade or external file saving. 5. Auxiliary function soft keys Operate according to the screen display. - Page 15 User Manual 9. Output terminal 10. Output control keys Turn the output on or off. 11. ALL ON/OFF key Turn on all or turn off all output channels. 12. Voltage/current adjustment knob Finely adjust the voltage/current, and the adjustment accuracy is 1mV/1mA. 13.
-
Page 16: Rear Panel Introduction
User Manual 3. Rear Panel Introduction 1. Digital IO interface 2. USB interface 3. LAN interface 4. AC selector 5. Power jack 6. Fuse holder 7. Exhaust fan 8. 4CH 4-wire output 9. Ground reference point 10. 3CH 4-wire output 11. -
Page 17: User Interface
User Manual 14. 1CH and 2CH 4-wire output 4. User Interface 4.1 [Main interface] 1. Output channel indication When an output channel is selected, the background of the corresponding channel is highlighted. 2. 2-wire/4-wire mode display 3. USB device icon display 4. -
Page 18: Meter View]
User Manual OC: Overcurrent protection; OT: Over temperature protection; 7. The actual output voltage and current value of the channel 8. User-set voltage and current values 9. Auxiliary Menu Bar 4.2 [Meter View] 1. The serial number of the currently selected channel 2. -
Page 19: Data Logger View]
User Manual 4.3 [Data logger view] 1. Tracking parameters All parameters of all channels can be tracked and displayed. Press the "Enter" key to turn on or off the tracking display of a single parameter. The display "----" after the parameter indicates that the tracking of the parameter has been turned off. -
Page 20: Help System
User Manual 4.4 Help system The help list can help users quickly understand the instrument. Press "About" to view product information, including product model, serial number, etc. This series of programmable DC power supplies provide help information for any key on the front panel and any menu key. -
Page 21: Chapter 2 Getting Started
User Manual Chapter 2 Getting Started This chapter introduces the items that users need to pay attention to when starting to use this series of programmable DC power supplies in order to carry out subsequent operations smoothly. 1. Check the AC voltage range This series of programmable DC power supplies support various specifications of AC power input, and users can choose the appropriate input gear according to actual needs. -
Page 22: Chapter 3 Function Introduction
User Manual Chapter 3 Function Introduction This chapter will introduce in detail the following functions of this series of programmable DC power supplies: Output voltage and current Over protection Channel delay Output coupling Output inhibit ... -
Page 23: Setting Steps
User Manual Setting steps: 1. Select the output channel Press the digital channel button on the front panel, or continuously press the left "◁" and right "▷" arrows to select the output channel to be set. 2. Set voltage/current: Press the arrow keys to select voltage or current, use the numeric keyboard or knob to set the value, press "×"... -
Page 24: Channel Delay
User Manual When using 4Wire, please connect the rear wiring correctly before turning it on. The internal power supply switches between 2-Wire or 4-Wire modes by connecting or disconnecting the sense end and the corresponding output end through a relay. In 2Wire mode, the sense end is connected to the main line internally. -
Page 25: Output Coupling
User Manual 5. Output coupling Press Source Settings->On/Off Coupling to set the output coupling. After setting the coupling, turn on the output of any one of the channels, and the other coupling channels will be turned on at the same time. If only part of the channel output coupling is set, open the front panel [All On/Off], regardless of whether the channel is set to output coupling, all channels will be turned on. -
Page 26: Operation Mode
User Manual INH: Remote inhibit input, the output status of all channels of the power supply can be controlled through external signals. DINP: Digital input, you can trigger the input by setting the level of Pin3. Note: When the output inhibition mode is selected as "Latched", to turn off the output inhibition, you must first switch the "Output Inhibit"... -
Page 27: Parallel
User Manual 6.3 Parallel In parallel mode, the channels are internally connected in parallel to form a single output. The channel 2 window of the main interface displays "PARALLEL with CH1". Channel 1 is the master and channel 2 is the slave. The "+" and "-" binding posts of channel 1 are the two output terminals of the parallel circuit. -
Page 28: Steps To Set The Output List
User Manual Steps to set the output list: 1. Select the output channel Press the channel button on the front panel to select the output channel, and press "Output List" to enter the output list setting interface. 2. Create a list ◆Add/remove step Press the "Add"... - Page 29 User Manual ◆Voltage/Current After List: Set the output value after the list output is completed. Last list value: After the list output is completed, the last list value is output. Return to DC Value: After the list output is completed, the DC value before the list becomes effective is output.
-
Page 30: Data Logger
User Manual Set the output list to run or stop. During operation, the output value is displayed in the corresponding channel of the main interface. Note: The property cannot be set when the list is "Run". The Run/Stop trigger output is valid only when the trigger source is set to Key. - Page 31 User Manual Vertical: Set the voltage/current/power value represented by the unit grid in the vertical direction of the displayed waveform, the setting range is 10uV～50V/10uA～50A/10uW～ 50W, press "Volts/Div +", "Volts/Div -" or " Amps/Div +", "Amps/Div -" or "Watts/Div +", "Watts/Div -"...
-
Page 32: Remote Control
User Manual Clear All: Clear all characters. Delete Char: Delete the previous character. Previous Char: Move the cursor forward one character. Next Char: Move the cursor one character back. ◆Recall: Recall the wave file. An external storage device must be connected to use this function. -
Page 33: Lan Remote Control
User Manual Open the IO software, find the device, and send an instruction to see if the communication is normal. After normal communication is obtained, SCPI commands can be used to control the power output. E.g: OUTP On, (@1) Set the channel 1 output on. Volt 5, (@1) Set the voltage of channel 1 to 5V. - Page 34 User Manual Set computer Ethernet properties: After the connection is successful, open the IO software and the device will appear in the LAN list. If the device does not appear, you can manually add the device, enter the device's IP address and protocol, test the VISA address, and click OK to add a new device.
- Page 35 User Manual After a successful connection, the network port icon in the upper right corner of the main interface is displayed as follows: As with USB remote control, after obtaining normal communication, you can use SCPI commands to control the power output.
-
Page 36: Rs232/485 Remote Control
User Manual 10.3 RS232/485 remote control Press Enter to set the appropriate baud rate, and other parameters remain unchanged by default. Open the IO software, select to add a device, set the corresponding baud rate, test the VISA address, and click OK to add a new device. As with USB remote control, after obtaining normal communication, you can use SCPI commands to control the power output. -
Page 37: Gpib Remote Control
User Manual 10.4 GPIB remote control Utility ->I/O Config ->GPIB Access GPIB Window. Use the numeric keypad to set the GPIB address and press Enter to confirm. -
Page 38: Utilities
User Manual 11. Utilities 11.1 Store/recall Store/Recall can store and recall settings as volatile settings, such as: voltage and current values, OVP, OCP, output coupling, output status, operation mode, list output, trigger settings, data recording, key tone, Help language etc. 11.1.1 Store setting Store Settings: Used to select internal storage or external storage. -
Page 39: I/O Setting
User Manual 11.1.2 Recall setting Used to select to recall from internal or from external. Same as store settings: select the location, state name or external .csv setting file of the file to be recalled, press "Enter" to confirm, and press "Recall" to execute recall. 11.1.3 Power-on setting Press "Power On Setting"... - Page 40 User Manual In input: display the state applied to Pin (binary bit 0 or 1). Out output: binary bit 0 or 1 can be set. 11.2.2 Digital input Select Digital In, Pin 1-Pin3 can be set as digital input. Polarity: Set the Pin polarity to positive or negative. In: display the state applied to Pin (binary bit 0 or 1).
-
Page 41: Setup
User Manual 3. Trigger input Turn on the channel output, execute the list output "Run/Stop", set the Pin1 external input signal 0 or 1 to change, and the list output will be triggered at this time. 11.2.5 Coupling off/on Select Couple Off/Couple On, Pin1-Pin3 can be set as coupling off/on. Only one Pin can be set as coupling off or coupling on, and the polarity of Pin is fixed to negative. - Page 42 User Manual 11.3.5 Firmware upgrade 11.3.6 Calibration The instrument has been calibrated before leaving the factory, and the user does not need to calibrate again. If you really need to calibrate, you can use SCPI commands to recall the calibration program. Calibration requires the use of a six and a half or seven and a half digit high-precision multimeter, and low accuracy of the multimeter can lead to inaccurate power output.
-
Page 43: Error Message
User Manual 3. Use Utilities ->Setup ->Calibration to calibrate. 4. Follow the prompts to connect the multimeter, input the multimeter reading into the "Input DMM measurement value", press the Enter key to confirm, and proceed to the next step. 1）Channel: When the calibration channel changes, the corresponding channel wiring needs to be changed. -
Page 44: Lock/Unlock
User Manual Long press the "Meter View" button for 3 seconds to perform the screenshot operation, and the screenshot file is automatically saved to the external storage device. 12. Lock/Unlock Long press the "Lock/Unlock" key to lock the front panel, short press this key to cancel the lock. -
Page 45: Chapter 4 Troubleshooting
The following faults may occur during the use of this series of programmable DC power supplies. Users can refer to the following methods to deal with. If the fault still exists, please contact Hantek and provide the equipment information of the instrument (How to obtain: ? ->About). -
Page 46: Chapter 5 Performance Index
User Manual Chapter 5 Performance Index DC output (0℃～40℃) Channel Voltage Current 3.2A HDP43XX 3.2A 3.2A 3.2A HDP44XX 1.5A Series and parallel output Channel Series Parallel 64V,3.2A 32V,6.4A HDP43XX — — 64V,3.2A 32V,6.4A HDP44XX — — — — Load Regulation ±(% of output + offset) Voltage <0.01%+2mV <0.01%+250μA... - Page 47 User Manual 0.1%+5mV 0.1%+10mA 0.1%+5mV 0.1%+10mA Transient response time The output current from full load to half load, or from half load to full load, the time for the output voltage to recover to within 15mV is less than 50μs. Mechanical Size 232*153*392mm...
