7.3 ESHIFT

You can select the gear shift manually with the up / down button.
Symbol Description
Current selected speed
Gear recommendation – change up a
gear
Gear recommendation – change down a
gear

7.4 WARNING / ERROR SYMBOLS

Symbol Meaning
Ice hazard
(temperature
Maintenance request
Motor overheat
Battery protection
mode (battery level
and / or temperature
too low)
Low tire pressure
Info
Warning
Error / Critical error
FIT_Manual_Display_Compact_Remote_Basic_EShift_Pinion_V3_en | Version 03 | 24.10.2023
FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION
Action / Limitation
Drive carefully.
4 °C)
Your e-bike should be taken to the FIT specialist dealer for
maintenance as soon as possible.
Reduced ride assistance performance. (This is not an error, but is
meant to protect the motor.)
Reduced ride assistance performance. (This is not an error, but is
meant to protect the battery.)
Check and adjust the tire pressure if necessary. (This function is only
available with optional tire pressure sensors.)
Motor assistance available
The message can be acknowledged by pressing the rocker switch.
(For more information, see section 9.3.1)
Motor assistance available
The message can be acknowledged by pressing the rocker switch.
(For more information, see section 9.3.1)
No motor assistance
Motor assistance is only available once the error has been rectified
and the system has been restarted (only in the case of a critical error).
(For more information, see section 9.3.1)
