Summary of Contents for Stairville BEL1 IP
- Page 1 BEL1 IP LED Spotlight...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 29.09.2022, ID: 550522...
-
Page 3: Table Of Contents
Operating..............................26 7.1 Starting the device........................... 26 7.2 Main menu............................27 7.2.1 DMX address..........................28 7.2.2 DMX mode............................29 7.2.3 Preprogrammed automatic show..................30 7.2.4 Sound control..........................31 7.2.5 Colour macros..........................32 7.2.6 Manual colour settings....................... 34 BEL1 IP LED Spotlight... - Page 4 7.7 Functions in 4-channel DMX mode................... 43 7.8 Functions in 5-channel DMX mode................... 44 7.9 Functions in 6-channel DMX mode................... 44 7.10 Functions in 8-channel DMX mode..................45 Technical specifications........................47 Troubleshooting............................50 Cleaning............................... 51 Protecting the environment......................52 BEL1 IP LED Spotlight...
-
Page 5: General Information
Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. BEL1 IP LED Spotlight... -
Page 6: Further Information
Personal consultation For personal consultation please contact our technical hotline. If you have any problems with the device the customer service will Service gladly assist you. 1.2 Notational conventions This manual uses the following notational conventions: BEL1 IP LED Spotlight... -
Page 7: Symbols And Signal Words
ð Automatic operation is started. Switch off the device. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. BEL1 IP LED Spotlight... - Page 8 This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – high-voltage. Warning – dangerous optical radiation. Warning – suspended load. BEL1 IP LED Spotlight...
- Page 9 General information Warning signs Type of danger Warning – danger zone. BEL1 IP LED Spotlight...
-
Page 10: Safety Instructions
Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and choke! Never let children unattended use electrical devices. BEL1 IP LED Spotlight... - Page 11 NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. BEL1 IP LED Spotlight...
- Page 12 50 % of their capacity and then switch off the device. Store the device at room temperature or cooler in an envi‐ ronment as dry as possible. If the batteries are stored for a longer period, recharge them to 50 % every three months. Fully charge the batteries only shortly before use at room temperature. BEL1 IP LED Spotlight...
-
Page 13: Features
(first code number). They are also protected against splash water from any angle (second code digit). That is why this equipment can also be used outdoors. Event technology equipment is generally only designed for temporary use however (event lighting) and not for permanent use outdoors. BEL1 IP LED Spotlight... - Page 14 (resistance to changing ambient conditions as well as against the effects of sun‐ light and UV rays). The seals and screw connections of the equipment must be checked regularly to ensure a fault-free operation. In cases of doubt, consult a specialist workshop in due time. BEL1 IP LED Spotlight...
-
Page 15: Installation
NOTICE! Risk of overheating Always ensure sufficient ventilation. The ambient temperature must not exceed the limits stated in the chapter Tech‐ nical Specifications of the User Manual. BEL1 IP LED Spotlight... - Page 16 Always work from a stable platform whenever installing, moving or servicing the unit. In doing so, the area underneath the unit must be cordoned off. The safety cable must be threaded through the openings in the bracket. BEL1 IP LED Spotlight...
- Page 17 Please note that this device must not be connected to a dimmer. Infrared sensor for the remote The infrared sensor for the remote control signals is located on the front panel of the device. control Make sure it is not obstructed. BEL1 IP LED Spotlight...
- Page 18 Ensure that proper polarity is observed when inserting batteries. NOTICE! Possible damage by leaking batteries Leaking batteries can cause permanent damage to the device. Take batteries out of the device if it is not going to be used for a longer period. BEL1 IP LED Spotlight...
-
Page 19: Dealing With Lithium Batteries
Before disposing of the device remove the lithium batteries. Protect used lithium batteries against potential short circuits, e.g. by covering the poles with adhesive tape. BEL1 IP LED Spotlight... - Page 20 Installation Only use powder extinguishers or other suitable extinguishing agents to extinguish a burning lithium battery. BEL1 IP LED Spotlight...
-
Page 21: Starting Up
Starting up Starting up Create all connections while the device is off. Use the shortest possible high-quality cables for all connections. Take care when running the cables to prevent tripping hazards. BEL1 IP LED Spotlight... -
Page 22: Connections And Controls
Connections and controls Connections and controls ö & BEL1 IP LED Spotlight... - Page 23 | toggles between the menu items, increases or decreases the displayed value by one. | selects an option of the respective operating mode, confirms the set value. 7 Pressure compensation valve (prevents condensation inside the device) BEL1 IP LED Spotlight...
- Page 24 Connections and controls Remote control & ö BLACK AUTO SOUND SENSI- STROBE SPEED TIVITY MANUAL FADE – BEL1 IP LED Spotlight...
- Page 25 11 [L] / [A] / [C] | sets the intensity of the colours lime, amber and cyan when a constant colour is displayed. 12 [+] / [–] | increases or decreases the set value. 13 Buttons for directly selecting a mixed colour. BEL1 IP LED Spotlight...
-
Page 26: Operating
After a few seconds, the display indicates that a reset is in progress. The device is then ready for use. ð The display shows the operating mode that was selected when the unit was last powered off. BEL1 IP LED Spotlight... -
Page 27: Main Menu
When the display shows the desired value, confirm with . To exit a menu item without making changes, press . All previously made settings are retained even when you disconnect the device from the power grid. BEL1 IP LED Spotlight... -
Page 28: Dmx Address
DMX address for the various DMX modes. Mode Highest possible DMX address 3-channel mode 4-channel mode 5-channel mode 6-channel mode 8-channel mode When the display shows the desired value, confirm with . BEL1 IP LED Spotlight... -
Page 29: Dmx Mode
Press to select the desired DMX mode. Menu level 3 Function ‘3CH’ 3-channel mode ‘4CH’ 4-channel mode ‘5CH’ 5-channel mode ‘6CH’ 6-channel mode ‘8CH’ 8-channel mode When the display shows the desired value, confirm with . BEL1 IP LED Spotlight... -
Page 30: Preprogrammed Automatic Show
Menu level 4 Function ‘Auto’ ‘Prog’ ‘00’ … ‘99’ Programme run‐ ning speed ‘Step’ ‘00’ … ‘99’ Colour change speed ‘Fade’ ‘00’ … ‘99’ Fade effect speed When the display shows the desired value, confirm with . BEL1 IP LED Spotlight... -
Page 31: Sound Control
‘00’ … ‘99’ Sensitivity of the built-in microphone for fade effect When the display shows the desired value, confirm with . ð The device follows the rhythm of the background music or sounds detected by the built-in microphone. BEL1 IP LED Spotlight... -
Page 32: Colour Macros
‘Macro’ and confirm with . The following table shows the setting options. Menu level 2 Menu level 3 Function ‘Macro’ ‘Red’ ‘Green’ Green ‘Blue’ Blue ‘Cyan’ Cyan ‘Lime’ Lime ‘Amber’ Amber ‘Lime G’ Lime Green ‘Yellow’ Yellow ‘Orange’ Orange BEL1 IP LED Spotlight... - Page 33 Select a value between ‘00’ and ‘99’ for the brightness of the selected colour macro and confirm with . Press until the display shows ‘Strobe’ and confirm with . Select a value between ‘00’ and ‘99’ for the strobe speed of the selected colour macro and confirm with . BEL1 IP LED Spotlight...
-
Page 34: Manual Colour Settings
‘Red’ ‘000’ … ‘255’ Intensity red (0 % to 100 %) ‘Green’ ‘000’ … ‘255’ Intensity green (0 % to 100 %) ‘Blue’ ‘000’ … ‘255’ Intensity blue (0 % to 100 %) BEL1 IP LED Spotlight... - Page 35 (0 % to 100 %) ‘Lime’ ‘000’ … ‘255’ Intensity lime (0 % to 100 %) ‘Amber’ ‘000’ … ‘255’ Intensity amber (0 % to 100 %) When the display shows the desired value, confirm with . BEL1 IP LED Spotlight...
-
Page 36: Using Wireless Dmx (W-Dmx)
The device operates as Transmitter. ‘Link’ The device searches for available devices, the con‐ nection is established. ‘Receive Reset’ The device deletes all previously paired devices, the connection is closed. When the display shows the desired value, confirm with . BEL1 IP LED Spotlight... -
Page 37: System Settings
Reverse’ ‘On’ On, display is rotated by 180° ‘Off’ Off, normal display ‘Key Lock’ Key lock ‘On’ Key lock activated ‘Off’ Key lock deactivated ‘Ir Remote’ Enables or disables the remote control ‘On’ Remote control enabled BEL1 IP LED Spotlight... - Page 38 Device behaviour on DMX signal failure ‘Blackout’ Blackout ‘Hold’ Retaining last settings ‘Frequency’ Flash frequency of the strobe effect ‘600Hz’ Flash frequency 600 Hz ‘1200Hz’ Flash frequency 1200 Hz ‘2000Hz’ Flash frequency 2000 Hz ‘2400Hz’ Flash frequency 2400 Hz BEL1 IP LED Spotlight...
- Page 39 ‘Linear’ Linear course ‘Exp’ Exponential course ‘Log’ Logarithmic course ‘S Curve’ S-curve shaped course ‘WIFI Reload’ The device deletes all previously paired devices, the connection is closed. ‘Reset Reload’ The device is reset to factory defaults. BEL1 IP LED Spotlight...
-
Page 40: System Information
Menu level 2 Function ‘Firmware’ Displays the current firmware version. ‘Time Info’ Displays the total running time of the device. ‘Temperature’ Displays the current temperature of the device. When the display shows the desired value, confirm with . BEL1 IP LED Spotlight... -
Page 41: Menu Overview
Lime Receive Reset Auto Amber Prog Lime G Yellow Dimmer Green Step Orange Pale G Strobe Blue Fade Pale B Rose Cyan Sound Pink Step Golden A Lime Light B Fade 2800K Amber 3000K 4000K 5000K BEL1 IP LED Spotlight... - Page 42 Firmware Time Info 600Hz Temperature 1200Hz Display Reverse 2000Hz 2400Hz 6000Hz Key Lock 18000Hz 25000Hz Dim Response Ir Remote Fast Standard Halogen Limiter Dimmer Curve Linear Emergency S-Curve WIFI Reload DMX Fail Reset Reload Blackout Hold BEL1 IP LED Spotlight...
-
Page 43: Functions In 3-Channel Dmx Mode
7.7 Functions in 4-channel DMX mode Channel Value Function 0…255 Intensity red (0 % to 100 %) 0…255 Intensity green (0 % to 100 %) 0…255 Intensity blue (0 % to 100 %) 0…255 Intensity lime (0 % to 100 %) BEL1 IP LED Spotlight... -
Page 44: Functions In 5-Channel Dmx Mode
7.9 Functions in 6-channel DMX mode Channel Value Function 0…255 Intensity red (0 % to 100 %) 0…255 Intensity green (0 % to 100 %) 0…255 Intensity blue (0 % to 100 %) 0…255 Intensity lime (0 % to 100 %) BEL1 IP LED Spotlight... -
Page 45: Functions In 8-Channel Dmx Mode
Intensity lime (0 % to 100 %) Automatic show (when channel 5…4 = 0… 255) 0…10 Without function 11…255 Preprogrammed automatic show with colour change Running speed of automatic show (when channel 5 = 11… 255) 0…255 Running speed increasing BEL1 IP LED Spotlight... - Page 46 Operating Channel Value Function RGBL strobe 0…15 Without function 16…255 Strobe effect (red, green, blue, lime), increasing speed Automatic sound controlled show 0…15 Without function 16…255 Automatic sound controlled show with colour change BEL1 IP LED Spotlight...
-
Page 47: Technical Specifications
142 mm Power consumption 20 W Supply voltage External power adapter, 100 - 240 V 50/60 Hz Operating voltage 8.4 V / min. 1 A Battery Battery type Lithium-ion, chargeable Voltage 7.4 V Capacity 3.5 Ah BEL1 IP LED Spotlight... - Page 48 Dimensions (W × H × D), 109 mm × 192 mm × 142 mm when light beam pointing horizontally Weight 1.2 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20 %…80 % (non-condensing) BEL1 IP LED Spotlight...
- Page 49 Technical specifications Further information Number of LEDs Colour mixture RGBLAC LED type x-in-1 Type Floor Spot Design round Floor housing fanless Remote control included Wireless DMX Housing colour black BEL1 IP LED Spotlight...
-
Page 50: Troubleshooting
Do not attempt to replace the built-in battery yourself. be charged Please contact our service centre. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. BEL1 IP LED Spotlight... -
Page 51: Cleaning
The frequency of cleaning depends on the operating environment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device. Clean with a soft cloth using our lamp and lens cleaner (item no. 280122). Always dry the parts carefully. BEL1 IP LED Spotlight... -
Page 52: Protecting The Environment
Protect used lithium batteries against short circuits, for example by covering the poles with adhesive tape. Permanently built-in lithium batteries must be disposed of together with the device. Please inquire about an appropriate collection point. BEL1 IP LED Spotlight... - Page 53 Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. BEL1 IP LED Spotlight...
- Page 54 Notes BEL1 IP LED Spotlight...
- Page 56 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
